Introduction
Thank you for choosing the ABBREE AR-805S Dual Band Mini Ham Radio Antenna. This compact and durable antenna is designed to provide reliable communication for your ham radio. This manual provides essential information for proper setup, operation, and maintenance to ensure optimal performance and longevity of your antenna.
Image: ABBREE AR-805S Mini Antennas (Black and Orange)
Product Features
- High Gain Performance: Designed to enhance communication distance and clarity.
- Technical Specifications: Dual band (144/430MHz), Max Gain 2.15dBi/3.0dBi, Max Power 10W, 50 Ohm Impedance, SMA-Female Connector.
- Compact Design: At 1.96 inches (5cm), its mini size ensures portability and reduces snagging.
- Broad Compatibility: Works with various Ham Radios including Baofeng UV-5R, BF-F8HP PRO, AR-152, K5 PLUS, BF-888S, GM-15 PRO, UV-21R, GM21, UV-K5, TD-H8, TD-H3, and other SMA-Female compatible devices.
Image: High Gain Antenna Features
Package Contents
- Two (2) ABBREE AR-805S Antennas
- Two (2) Rubber Washers (for gap adjustment)
Setup Instructions
- Identify Connector Type: Ensure your radio has an SMA-Female connector. The AR-805S antenna features an SMA-Male connector designed to screw into an SMA-Female port.
- Attach Antenna: Carefully screw the AR-805S antenna onto the antenna port of your ham radio. Turn clockwise until it is finger-tight. Do not overtighten.
- Check for Gaps: If there is a slight gap between the base of the antenna and the radio's housing after tightening, use one of the provided rubber washers. Unscrew the antenna, place the rubber washer over the connector, and then re-attach the antenna. This helps ensure a secure fit and protects the connection.
- Verify Connection: Once attached, gently check that the antenna is firmly seated and does not wobble.
Image: SMA-Female Connector Detail and Antenna Attachment
Image: Antenna Attached to Ham Radio
Video: ABBREE AR-805S Mini Antenna Overview and Compatibility. This video demonstrates the antenna's features, size, and compatible radio models, including how to use the rubber washer for a secure fit.
Operating Instructions
- Power On Radio: After securely attaching the antenna, power on your ham radio.
- Select Frequency: Tune your radio to the desired VHF (144MHz band) or UHF (430MHz band) frequency.
- Communication Range: The AR-805S is a mini stubby antenna, optimized for portability. While it offers stable communication, its range may be more limited compared to longer whip antennas. It is ideal for close-range communication, such as within a quarter-mile, or when a compact antenna is preferred for convenience.
- Optimal Performance: For best results, ensure a clear line of sight between communicating radios. Obstructions like buildings or dense foliage can affect signal quality and range.
Image: Antenna Compatibility with Various Ham Radios
Maintenance
- Cleaning: Wipe the antenna with a soft, dry cloth to remove dust or dirt. Avoid using harsh chemicals or abrasive cleaners.
- Storage: Store the antenna in a cool, dry place when not in use. Protect the connector from damage.
- Inspection: Periodically inspect the antenna for any signs of physical damage, such as cracks or bends, especially around the connector.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Poor reception or transmission |
|
|
| Antenna feels loose after attachment |
|
|
Specifications
| Feature | Detail |
|---|---|
| Model Number | AR-805S |
| Frequency Range | 144/430MHz (VHF/UHF Dual Band) |
| Gain (MAX) | 2.15dBi (VHF) / 3.0dBi (UHF) |
| Max Power | 10W |
| Impedance | 50 Ohms |
| Connector Type | SMA-Female (Antenna has SMA-Male connector) |
| Antenna Length | 1.96 inches (5 cm) |
| Item Weight | 1.41 ounces (per antenna) |
| Manufacturer | ABBREE |
Warranty and Support
ABBREE products are manufactured to high-quality standards. For specific warranty information or technical support, please refer to the official ABBREE website or contact your retailer. Keep your purchase receipt as proof of purchase.
