RecPro RV Stainless Steel Microwave with Trim Kit RPM-7 User Manual

1. Important Safety Instructions

When using electrical appliances, basic safety precautions should be followed, including the following:

• Read all instructions before using the appliance.
• To reduce the risk of fire, electric shock, or injury to persons or exposure to excessive microwave energy:
• Do not operate the oven when empty.
• Do not heat liquids or other foods in sealed containers as they are liable to explode.
• Do not use corrosive chemicals or vapors in this appliance.
• Close supervision is necessary when the appliance is used by or near children.
• Only use utensils that are suitable for use in microwave ovens.
• Do not attempt to service or repair this appliance yourself. Contact qualified service personnel.
• Ensure proper ventilation around the microwave.
• Do not operate the microwave if the door or door seals are damaged.

2. Product Overview

The RecPro RV Stainless Steel Microwave with Trim Kit (Model RPM-7) is designed for RV use, featuring a durable construction to withstand travel vibrations. It offers 1.0 cubic feet capacity and 900 watts of cooking power.

Figure 2.1: Front view of the RecPro RV Stainless Steel Microwave with Trim Kit.

Figure 2.2: Interior view with door open, showing the glass turntable.

Key Features:

• Capacity: 1.0 Cubic Feet
• Power Output: 900 Watts
• Power Levels: 10 adjustable power levels
• Cooking Modes: Express Cooking and Multi-Stage Cooking
• Defrost Options: Defrost by time or weight
• Safety: Child Safety Lock function
• Included: Glass turntable and trim kit for built-in installation

Product Demonstration Video:

3. Installation and Setup

This microwave is designed for built-in installation and includes a trim kit for a finished appearance. Ensure the installation area meets the specified dimensions and ventilation requirements.

Dimensions:

• Product Dimensions (Overall): 13.5"D x 19"W x 11.38"H
• Interior Measurements: Approximately 12"D x 12"W x 8"H

Figure 3.1: Dimensional diagram for installation planning.

Installation Steps (General Guidelines):

1. Prepare Opening: Ensure the cabinet opening matches the required dimensions for the microwave and trim kit.
2. Electrical Connection: Connect the microwave to a grounded 120V AC power outlet. Refer to local electrical codes.
3. Position Microwave: Carefully slide the microwave into the prepared opening.
4. Secure Trim Kit: Attach the trim kit according to the specific instructions provided with the kit, ensuring it is flush and secure.
5. Final Check: Verify that the microwave is stable, level, and that the door opens and closes freely.

Figure 3.2: Rear view of the microwave, illustrating power connection and ventilation requirements.

4. Operating Instructions

This section details the functions and controls of your RecPro RV Microwave.

Figure 4.1: Placing an item inside the microwave for heating.

Control Panel Functions:

• Time Cook: Press to set cooking time.
• Power: Press to select desired power level (1-10).
• Clock: Press to set the current time.
• Kitchen Timer: Functions as a standalone timer.
• Weight Defrost: Defrosts food based on weight input.
• Time Defrost: Defrosts food based on time input.
• Speedy Cook: Initiates cooking at full power for 30 seconds with each press.
• Auto Menu: Pre-programmed settings for common foods (Popcorn, Potato, Pizza, Frozen Vegetable, Beverage, Dinner Plate).
• Stop/Cancel: Stops cooking or clears settings.
• Start/+30 Sec: Starts cooking or adds 30 seconds to cooking time.
• Memory: Stores and recalls custom cooking settings.

Setting the Clock:

1. Press the CLOCK button.
2. Enter the current time using the number pad.
3. Press CLOCK again to confirm.

Basic Microwave Cooking:

1. Place food in a microwave-safe container on the turntable.
2. Close the door.
3. Press TIME COOK.
4. Enter the desired cooking time using the number pad.
5. To adjust power level (optional): Press POWER, then enter a number from 1 to 10. (10 is full power).
6. Press START/+30 SEC to begin cooking.

Child Safety Lock:

To activate the Child Safety Lock, press and hold the STOP/CANCEL button for 3 seconds. The lock indicator will appear on the display. To deactivate, press and hold STOP/CANCEL again for 3 seconds.

5. Maintenance and Cleaning

Regular cleaning and maintenance will ensure optimal performance and longevity of your microwave.

Exterior Cleaning:

• Wipe the exterior with a damp cloth and mild detergent.
• Avoid abrasive cleaners or scouring pads.

Interior Cleaning:

• Clean the interior cavity with a damp cloth and mild soap.
• For stubborn food splatters, place a bowl of water with lemon slices inside and microwave for 2-3 minutes. Let it sit for 5 minutes, then wipe clean.
• Remove and wash the glass turntable and roller ring in warm, soapy water.

Door and Seal Cleaning:

• Keep the door seals and adjacent parts clean to ensure proper door closure.
• Do not use harsh cleaners on the door seals.

6. Troubleshooting

If you encounter issues with your microwave, refer to the following common problems and solutions:

If problems persist after attempting these solutions, please contact RecPro customer support.

7. Specifications

8. Warranty and Support

For warranty information, technical support, or to inquire about replacement parts, please contact RecPro customer service directly. Refer to your purchase documentation for specific warranty terms and contact details.

You may also visit the official RecPro website for additional resources and support information: RecPro Store on Amazon
