Product Overview
The SEAFLO 12V 2000 GPH Portable Submersible Utility Pump is a compact, high-performance solution designed for efficient water removal. It is ideal for various applications including draining bilges on boats, clearing flooded compartments, or emergency water extraction in basements and RVs.
Engineered with a durable motor, this pump features an ergonomic handle for easy portability and a detachable filter screen for convenient maintenance. It delivers a powerful 2000 GPH flow rate and can achieve a maximum head height of 11.5 feet (3.5 meters).
The pump includes two interchangeable outlet fittings (1-1/8” and 1-1/4”) to accommodate different hose setups. A built-in check valve prevents backflow, and motor cooling ribs assist in heat dissipation during operation, ensuring consistent performance and longevity.
Figure 1: SEAFLO 12V 2000 GPH Portable Submersible Utility Pump.
Setup Instructions
The SEAFLO utility pump is designed for straightforward setup. It comes with interchangeable fittings to match your specific hose requirements.
- Select Appropriate Fitting: Choose between the 1-1/8” (29mm) or 1-1/4” (32mm) outlet fittings based on your drainage hose size.
- Attach Fitting: Securely attach the selected fitting to the pump's outlet.
- Connect Hose: Connect your drainage hose to the attached fitting. Ensure a tight connection to prevent leaks.
- Position Pump: Place the pump in the area where water needs to be removed. Ensure the pump is fully submerged for optimal operation in automatic mode.
Figure 2: Included fittings for various hose connections.
Video: Product Overview and Setup
Video 1: This official video from SEAFLO Direct demonstrates the pump's features, included fittings, and basic setup for operation.
Operating Instructions
The SEAFLO utility pump offers both automatic and manual operating modes, along with intelligent protection features.
Operating Modes:
- Automatic Mode: The pump automatically activates when the water level reaches a certain height and shuts off when the water is sufficiently drained. This mode is ideal for continuous monitoring and hands-free operation in areas prone to flooding.
- Manual Mode: For immediate and continuous pumping, the pump can be manually activated. This is suitable for controlled drainage tasks where constant supervision is possible.
Intelligent Protection Features:
- Dry-Run Protection: The pump is designed to automatically shut off if it operates without water for more than 5 seconds, extending its motor life.
- Jam and Blockage Self-Recovery: In case the impeller is jammed or blocked, the pump will attempt to recover periodically to clear the obstruction.
- Airlock Handling: The pump is equipped to handle airlocks, ensuring continuous and efficient pumping.
Figure 3: The pump efficiently draining water from a hot tub.
Figure 4: Demonstrating the strong water discharge from the pump.
Maintenance
Regular maintenance ensures the longevity and optimal performance of your SEAFLO utility pump.
- Clean Strainer: Periodically remove the detachable filter screen (strainer) at the bottom of the pump and clean any debris, leaves, or other particles that may have accumulated.
- Inspect Impeller: After cleaning the strainer, inspect the impeller for any obstructions or damage. Ensure it spins freely.
- Rinse Pump: After use, especially in dirty water, rinse the pump with clean water to prevent buildup.
- Store Properly: When not in use, store the pump in a dry, protected area.
Video: Internal Components and Cleaning
Video 2: This video demonstrates how to access and clean the internal components of a similar SEAFLO 2000 GPH pump, ensuring proper maintenance.
Troubleshooting
- Pump Not Activating: Ensure the pump is properly connected to a 12V DC power source. In automatic mode, verify the water level is above the activation threshold.
- Reduced Flow/No Flow: Check the strainer for blockages and clean if necessary. Inspect the impeller for any obstructions. Ensure the hose is not kinked or blocked.
- Airlock: If the pump stops due to an airlock, try tilting the pump slightly to release trapped air, or switch to manual mode briefly to clear the airlock.
- Dry-Run Protection Activation: If the pump shuts off unexpectedly, it might be due to dry-run protection. Ensure the pump is adequately submerged in water.
Specifications
| Feature | Detail |
|---|---|
| Model | SFBP1-G2000-18 |
| Voltage | 12V DC |
| Flow Rate | 2000 GPH |
| Current Draw | 12.0A |
| Max Head | 11.5 ft (3.5 m) |
| Outlet Sizes | 1-1/8” (29mm) and 1-1/4” (32mm) |
| Material | Acrylonitrile Butadiene Styrene (ABS) |
| Item Weight | 2.5 pounds |
| Package Dimensions | 8.2 x 5.6 x 4.33 inches |
| Batteries Required | No |
Warranty and Certifications
The SEAFLO 12V 2000 GPH Portable Submersible Utility Pump is backed by a 4-Year Limited Warranty, providing peace of mind regarding its performance and durability under various conditions.
The product is also CE & RoHS Certified, ensuring it meets high standards for safety, health, and environmental protection.
