1. Introduction
This manual provides detailed instructions for the setup, operation, and maintenance of your EWEADN X23Pro Wireless Gaming Mouse. Please read this manual thoroughly to ensure proper use and optimal performance of your device.
2. Product Overview
The EWEADN X23Pro is a versatile gaming mouse designed for various computing environments. It features a lightweight design, multiple connectivity options, and customizable settings.
Key Features:
- Tri-Mode Connection: Supports 2.4G wireless, Bluetooth 5.0, and USB-C wired connections.
- Lightweight Design: Weighs approximately 59g for reduced hand fatigue.
- High-Capacity Battery: Built-in 800mAh rechargeable battery.
- Adjustable DPI: 6 levels (800-1600-2400-3200-6400-12000 DPI).
- Adjustable Polling Rate: 4 levels (125Hz-250Hz-500Hz-1000Hz).
- Programmable Buttons: 6 customizable buttons with macro support.
Package Contents:
- EWEADN X23Pro Wireless Gaming Mouse
- USB-C Charging/Data Cable (1.5m)
- USB Receiver (2.4G)
- Anti-slip Stickers (6 Pcs)
- Instruction Manual
Image: The EWEADN X23Pro Wireless Gaming Mouse in black, shown with its compact USB receiver.
Image: An overview diagram illustrating the X23Pro's main features including tri-mode connection, DPI, lightweight design, battery life, clicks, polling rate, custom macro, and ergonomic design.
3. Setup and Connection
The X23Pro mouse offers three connection modes: 2.4G wireless, Bluetooth 5.0, and USB-C wired. You can switch between modes using the switch button located on the bottom of the mouse.
3.1. Power On/Off
Locate the power switch on the bottom of the mouse. Slide it to the desired position (2.4G, BT, or OFF).
3.2. 2.4G Wireless Mode
- Insert the USB receiver into an available USB port on your computer.
- Slide the switch on the bottom of the mouse to the "2.4G" position.
- Long press the code key (pairing button) on the bottom of the mouse. The top indicator light will flash green, indicating pairing mode.
- The mouse should connect automatically. The indicator light will stop flashing once connected.
3.3. Bluetooth 5.0 Mode
- Slide the switch on the bottom of the mouse to the "BT" position.
- Long press the code key (pairing button) on the bottom of the mouse. The top indicator light will flash blue, indicating pairing mode.
- On your computer or device, go to Bluetooth settings and search for new devices.
- Select "X23Pro" from the list of available devices to pair.
- The indicator light will stop flashing once connected.
3.4. USB-C Wired Mode
- Connect the provided USB-C cable to the mouse and the other end to a USB port on your computer.
- The mouse will automatically switch to wired mode and begin charging.
Image: Visual guide for connecting the mouse via 2.4G wireless and Bluetooth modes, including the location of the on/off switch and code key.
4. Operating Instructions
4.1. Button Functions
Image: A detailed diagram labeling the multi-function buttons on the X23Pro mouse, including Left Button, Right Button, Scroll Wheel, Indicator, Forward Button, Backward Button, Type-C Interface, 2.4G/OFF/BT Button, Code Key, DPI Button, and USB Receiver compartment.
- Left Button: Primary click function.
- Right Button: Secondary click function (context menu).
- Scroll Wheel: Scroll up/down, middle click.
- Forward Button: Navigates forward in web browsers or file explorers.
- Backward Button: Navigates backward in web browsers or file explorers.
- DPI Button (bottom): Cycles through DPI settings.
4.2. Adjusting DPI
The mouse features 6 adjustable DPI levels: 800, 1600, 2400, 3200, 6400, and 12000. The default DPI is 1600.
- To change DPI, press the DPI toggle button located on the bottom of the mouse. Each press will cycle to the next DPI level.
- DPI values can also be set and customized using the dedicated driver software (see Section 5.1).
Image: A visual representation of the six adjustable DPI settings (800-12000) available on the X23Pro mouse, indicating users can change them via the DPI button or custom software.
4.3. Adjusting Polling Rate
The mouse supports 4 adjustable polling rates: 125Hz, 250Hz, 500Hz, and 1000Hz. The polling rate can be adjusted via the driver software to optimize response speed and tracking accuracy.
Image: A diagram comparing mouse trajectories at different polling rates, showing a smooth trajectory at 1000Hz versus slight lag at lower rates.
5. Customization
5.1. Programmable Buttons and Macro Programming
The X23Pro features 6 buttons that can be customized using the dedicated driver software. This allows for macro programming, enabling you to assign complex commands to individual buttons.
- Download the official driver software from the EWEADN website (refer to product packaging or manufacturer's website for download link).
- Install the software on your computer.
- Open the software to access button assignment, macro editor, DPI settings, polling rate adjustments, and other advanced sensor settings.
Image: A screenshot of the mouse's customization software, showing options for key assignment, macro editing, DPI settings, lighting, polling rate, power management, and sensor advanced settings.
6. Charging and Battery
The X23Pro mouse is equipped with an 800mAh rechargeable battery, providing extended usage time. A full charge can last approximately 20 days with 5 hours of daily use.
6.1. Charging the Mouse
- Connect the provided USB-C cable to the mouse's Type-C interface and the other end to a USB power source (e.g., computer USB port, USB wall adapter).
- The mouse can be used in wired mode while charging.
6.2. Power Saving Mode
To conserve battery life, the mouse enters a primary sleep mode after 1 minute of inactivity. It can be woken up by pressing any button or moving the mouse.
Image: A visual emphasizing the 800mAh high-capacity battery of the X23Pro mouse, indicating long-lasting power.
7. Maintenance
7.1. Cleaning
- Use a soft, dry cloth to clean the mouse surface.
- For stubborn dirt, slightly dampen the cloth with water or a mild cleaning solution. Avoid harsh chemicals.
- Do not allow liquids to enter the mouse.
7.2. Anti-slip Stickers
The mouse comes with 6 pieces of anti-slip tape. These can be applied to the mouse surface to enhance grip and prevent slippage, especially during intense use.
Image: A visual demonstrating the lightweight design of the X23Pro mouse and how it accommodates various grip styles (palm, fingertip, claw), along with the mention of anti-slip tape.
8. Compatibility
The EWEADN X23Pro Wireless Gaming Mouse is compatible with a wide range of operating systems and devices:
- Windows 7/8/10/XP/Vista
- Mac OS
- Linux
- Android systems
Suitable for use with PCs, laptops, Macs, and other compatible devices.
9. Troubleshooting
If you encounter issues with your EWEADN X23Pro mouse, please refer to the following common solutions:
- No response: Ensure the mouse is powered on and fully charged. Check the connection mode (2.4G, BT, or wired) and ensure it matches your device's connection.
- Lag or Disconnection: For 2.4G wireless, ensure the USB receiver is securely plugged in and close to the mouse. For Bluetooth, ensure your device's Bluetooth is enabled and the mouse is paired correctly. Reduce interference from other wireless devices.
- DPI/Button issues: Verify that the correct DPI setting is selected. If using custom settings, ensure the driver software is installed and configured correctly.
- Charging issues: Ensure the USB-C cable is properly connected to both the mouse and the power source. Try a different USB port or cable.
If problems persist, please contact customer support.
10. Specifications
| Feature | Detail |
|---|---|
| Model Number | X23Pro |
| Connectivity Technology | 2.4GHz Wireless, Bluetooth 5.0, USB-C Wired |
| Movement Detection Technology | Optical (PAW3311 Flagship Sensor) |
| DPI Levels | 800-1600-2400-3200-6400-12000 |
| Polling Rate | 125Hz-250Hz-500Hz-1000Hz |
| Buttons | 6 Programmable Buttons |
| Battery Capacity | 800mAh Rechargeable |
| Item Weight | 1.76 ounces (approx. 59g) |
| Package Dimensions | 4.6 x 2.4 x 1.85 inches |
| Manufacturer | EWEADN |
11. Warranty and Support
EWEADN products are designed for reliability and performance. For warranty information, please refer to the documentation included with your purchase or visit the official EWEADN website.
Customer Support:
For any questions, technical assistance, or support inquiries, please contact us via email:
Email: eweadnkeyboard@outlook.com
Image: An illustration depicting various customer support services offered, including pre-sales Q&A, troubleshooting, accessories reissue, and returns and exchanges, with an email contact provided.
