KEECOON KC-BL-15 Automatic Cooking Pot User Manual

Model: KC-BL-15 | Brand: KEECOON

1. Introduction

Thank you for purchasing the KEECOON KC-BL-15 Automatic Cooking Pot. This versatile appliance is designed to simplify your cooking process, offering 14 different modes for a variety of dishes including soy milk, soups, baby food, and more. Please read this manual thoroughly before use to ensure safe and optimal operation.

2. Safety Information

  • Always ensure the appliance is placed on a stable, flat surface.
  • Do not immerse the main unit (base with motor) in water or other liquids.
  • Keep out of reach of children.
  • Exercise caution when handling hot liquids and steam to prevent burns.
  • Do not operate the appliance if the power cord or plug is damaged.
  • Unplug the appliance from the power outlet when not in use or before cleaning.
  • Ensure the lid is securely closed before starting any cooking program.
  • Do not overfill the pot beyond the maximum fill line to prevent overflow.

3. Product Components

The KEECOON KC-BL-15 Automatic Cooking Pot consists of the following parts:

  • Main Pot (with integrated blades)
  • Power Base (with control panel and power cord)
  • Lid (with sealing ring and filter)
  • Measuring Cup
  • Cleaning Brush
  • Tea Strainer
  • User Manual & Recipe Book
KEECOON KC-BL-15 Automatic Cooking Pot components including main pot, power base, lid, measuring cup, cleaning brush, tea strainer, and manuals.

Image: Overview of the KEECOON KC-BL-15 Automatic Cooking Pot and its accessories.

4. Setup

  1. Unpack: Carefully remove all components from the packaging.
  2. Clean: Before first use, wash the main pot, lid, measuring cup, and tea strainer with warm soapy water. Rinse thoroughly and dry completely. Do not wash the power base.
  3. Assemble: Place the main pot onto the power base, ensuring it is securely seated. Align the handle of the pot with the corresponding slot on the base.
  4. Power Connection: Plug the power cord into a suitable electrical outlet (100V).
Hands placing ingredients into the KEECOON Automatic Cooking Pot, then selecting a mode with the knob, and finally pouring out the finished product.

Image: Simple 3-step operation for the KEECOON Automatic Cooking Pot.

5. Operating Instructions

The KEECOON KC-BL-15 features 14 versatile modes for various preparations. Always refer to the included recipe book for specific ingredient quantities and preparation steps for each mode.

Basic Operation:

  1. Add Ingredients: Place your desired ingredients into the main pot. Ensure the total volume is above the 400ml minimum mark and below the maximum fill line for the selected mode.
  2. Secure Lid: Close the lid firmly, ensuring it is properly aligned and locked.
  3. Select Mode: Turn the knob on the power base to select your desired cooking mode. The LED display will show the selected mode.
  4. Start: Press the knob to start the cooking process. The appliance will automatically begin operation.

Key Features:

  • 14 Modes: Includes modes for soy milk, baby food, various soups (e.g., potage, vegetable soup), porridge, tea, juice, almond milk, and milkshakes.
  • 12-Hour Reservation: Set a delayed start time for up to 12 hours. Prepare ingredients in advance and wake up to freshly made soy milk or a warm soup.
  • 2-Hour Keep Warm: After cooking, the appliance can keep food warm for up to 2 hours. The temperature can be adjusted between 55°C and 90°C in 5°C increments.
  • No Straining Required: The powerful blending action ensures a smooth consistency, eliminating the need for manual straining for most preparations.
A grid showing 9 different food items that can be made with the KEECOON Automatic Cooking Pot, including soy milk, baby food, okara, rice porridge, soup, vegetable soup, fruit tea, almond milk, and milk shake.

Image: Examples of the 14 versatile modes available.

Two images showing the reservation and keep warm functions. One shows adding soybeans at 8 PM, the other shows pouring soy milk at 8 AM.

Image: Illustration of the 12-hour reservation and 2-hour keep warm functions.

Video: An overview of the KEECOON Automatic Cooking Pot's features, including its 14 modes, reservation, keep warm, and ease of use for various recipes like soy milk, soups, and baby food.

6. Maintenance and Cleaning

Regular cleaning ensures the longevity and hygiene of your appliance.

High-Temperature Cleaning Mode:

The appliance features a high-temperature cleaning mode for thorough sanitation.

  1. Add Cleaning Agent: Add 10-20g of sodium percarbonate (oxygen bleach) to the main pot.
  2. Add Hot Water: Pour hot water (approx. 90°C) up to the 800ml mark.
  3. Soak: Let it soak for about 30 minutes.
  4. Discard Solution: Carefully pour out the cleaning solution.
  5. Rinse: Add clean water to the pot.
  6. Run Cleaning Mode: Select the "High-Temperature Cleaning" mode and start.
  7. Scrub (if needed): If stains remain after the cycle, use the provided cleaning brush to gently scrub them off.
  8. Final Rinse: Rinse the pot 2-3 times with clean water to ensure no detergent residue remains.

Lid and Accessories Cleaning:

  1. Remove Lid: Hold the pot handle with one hand and slowly lift the lid with the other to release steam.
  2. Disassemble Lid: Remove the sealing ring. Hold the lid cover with one hand and grasp the protrusion on the inside of the lid with the other hand to pull it apart.
  3. Wash: Use a sponge with diluted kitchen neutral detergent to wash the lid components and tea strainer. Rinse thoroughly with water.
  4. Soak (for stubborn stains): If the lid, sealing ring, or tea strainer are heavily soiled, soak them in a sodium percarbonate solution for a few minutes before scrubbing.
  5. Dry: Ensure all parts are completely dry before reassembling and storing.

External Cleaning:

Wipe the exterior of the power base and main pot with a damp cloth. Do not use abrasive cleaners or immerse the power base in water.

Video: Detailed steps for cleaning the KEECOON Automatic Cooking Pot, including using sodium percarbonate for stubborn stains and disassembling the lid for thorough cleaning.

7. Troubleshooting

ProblemPossible CauseSolution
Appliance does not start.Power cord not plugged in; lid not properly closed; pot not correctly placed on base.Check power connection; ensure lid is securely closed; re-seat the pot on the base.
Food sticks or scorches at the bottom.Insufficient liquid; ingredients too dense; incorrect mode selected.Ensure adequate liquid for the recipe; stir ingredients if necessary; select appropriate mode. Refer to the cleaning section for removing scorched residue.
Loud noise during operation.Normal operation for blending; hard ingredients.Some noise is normal during blending cycles. Ensure no foreign objects are in the pot.
Overflow during cooking.Overfilling the pot.Do not exceed the maximum fill line indicated inside the pot.

8. Specifications

  • Model: KC-BL-15
  • Brand: KEECOON
  • Capacity: 1000 ml
  • Material: Stainless Steel, Plastic
  • Color: Black
  • Voltage: 100V
  • Dimensions: 14.2 cm (Depth) x 18.3 cm (Width) x 30.4 cm (Height)
  • Package Size: 35.2 x 21.2 x 18.4 cm
  • Package Weight: 2.27 kg
  • Features: 12H Reservation & 2H Keep Warm, 14 Modes, Automatic Cooking, Large Capacity
  • Care Instructions: Hand wash only (for removable parts)
The KEECOON Automatic Cooking Pot in a compact size, shown next to a shelf, highlighting its space-saving design and detachable pot for easy storage.

Image: The compact and detachable design for convenient storage.

9. Warranty and Support

For warranty information, product support, or service inquiries, please refer to the warranty card included with your purchase or contact KEECOON customer service through the official website or your retailer. Please have your model number (KC-BL-15) and purchase date available when contacting support.
