Devoko SF-0770 Modular Convertible Sofa Bed Instruction Manual

Introduction

This manual provides detailed instructions for the assembly, operation, and maintenance of your Devoko SF-0770 Modular Convertible Sofa Bed. Please read all instructions carefully before beginning assembly and retain this manual for future reference.

The Devoko SF-0770 is a versatile 3-seater modular corner sofa that converts into a bed, featuring integrated storage and cup holders. Its design allows for flexible configuration to suit various living spaces.

Safety Information

• Ensure all components are securely fastened before use.
• Do not exceed the maximum weight capacity of 120 kg.
• Keep small parts away from children during assembly to prevent choking hazards.
• Use caution when converting the sofa to bed mode to avoid pinching fingers or clothing.
• Avoid standing on the sofa or chaise lounge.
• Periodically check all connections and tighten as necessary.

Package Contents

Your Devoko SF-0770 sofa bed is shipped in multiple packages. Please ensure all parts are present before beginning assembly. Refer to the assembly video for a visual guide to components.

• Sofa frame components
• Chaise lounge frame components
• Armrests (Left and Right)
• Backrests (Big and Small)
• Sofa Legs
• Seat Cushions
• Backrest Cushions
• Hardware pack (screws, washers, plugs, tools)
• Instruction Manual

Setup and Assembly

Assembly is required for this product. It is recommended to have two people for assembly. Approximate assembly time is 50 minutes.

Assembly Video Guide

This video demonstrates the step-by-step assembly process for the Devoko Modular Convertible Sofa Bed. It shows how to attach legs, connect sections, and install backrests and cushions.

Step-by-Step Assembly Instructions

1. Prepare the Storage Frame (C): Attach the plastic gaskets (E2) and sofa legs (E1) to the bottom of the storage frame. Secure the male plugs (K2) to the sides using M6x15mm screws (M).
2. Prepare the Left Armrest (B1): Attach the plastic gaskets (E2) and sofa legs (E1) to the bottom. Secure the mother plugs (K1) to the sides using M6x15mm screws (M).
3. Prepare the Right Armrest (B2): Attach the plastic gaskets (E2) and sofa legs (E1) to the bottom. Secure the mother plugs (K1) to the sides using M6x15mm screws (M).
4. Attach Armrests to Storage Frame: Connect the left and right armrests to the storage frame by sliding the mother plugs (K1) onto the male plugs (K2). Secure with M6x60mm screws (O).
5. Install Seat Cushion Mesh Bag (D): Place the seat cushion mesh bag onto the main sofa frame.
6. Attach Backrests: Install the small backrest (A2) and big backrest (A1) onto the main sofa frame. Ensure they are properly aligned.
7. Secure Backrests: Use washers (Q) and M6x40mm screws (L) to secure the backrests to the frame.
8. Connect Backrest Sections: Use M6x30mm screws (R1) and one-hand twisted rubber nuts (R2) to connect the backrest sections together.
9. Install Backrest Cloth Cover (U): Place the backrest cloth cover over the backrests.
10. Attach Pulley Linkages (F1, F2): Secure the left pulley linkage (F1) and right pulley linkage (F2) to the sofa frame using M6x15mm screws (M).
11. Install Rear Pole of Activity Frame (I): Attach the rear pole of the activity frame using M6x30mm screws (N).
12. Attach Front Panel (H1) and Side Panels (H2): Secure the front panel and side panels using corner braces (T) and M6x15mm screws (M).
13. Final Placement of Cushions: Place all seat and backrest cushions onto the assembled sofa.

Operating Instructions

Converting to Bed Mode

The Devoko SF-0770 features an easy pull-out mechanism to convert into a bed. Simply pull the handles located on the front of the main sofa section to extend the bed frame. The chaise lounge section remains in place.

Image: The Devoko sofa fully extended into bed mode, showing ample sleeping space.

Using Integrated Storage

The chaise lounge section of the sofa includes a hidden storage compartment. Lift the seat cushion of the chaise lounge to access the storage space. This area is suitable for storing blankets, pillows, or other household items.

Image: The chaise lounge section with its top lifted, revealing the integrated storage compartment.

Reversible Chaise Lounge

The chaise lounge can be configured on either the left or right side of the sofa to adapt to your room layout. This modular design provides flexibility for various living spaces.

Image: Two configurations of the Devoko sofa, demonstrating the reversible chaise lounge feature.

Cup Holders and Side Pockets

The armrests are equipped with integrated cup holders for convenience. Additionally, side pockets are provided for storing remote controls, phones, or magazines.

Image: Detail view of the sofa's armrest, highlighting the built-in cup holder and side storage pocket.

Product Features and Conversion Demonstration

This video showcases the key features of the Devoko sofa, including its conversion to bed mode, storage options, and overall design.

Maintenance and Care

• Cleaning: For general cleaning, vacuum regularly to remove dust and debris. For spills, blot immediately with a clean, dry cloth. For tougher stains, use a mild fabric cleaner and follow the product instructions. Test on an inconspicuous area first.
• Fabric Care: The high-density anti-scratch fabric with nanotechnology anti-stain barrier simplifies cleaning. Avoid harsh chemicals or abrasive cleaners.
• Sunlight Exposure: Avoid prolonged direct sunlight exposure to prevent fading of the fabric.
• Structural Integrity: Periodically check all screws and connections to ensure they remain tight. Re-tighten if necessary.

Troubleshooting

Difficulty During Assembly

• Misaligned Holes: If screw holes do not align, double-check that you are using the correct parts for each step and that they are oriented correctly. Sometimes, slight adjustments or gentle pressure may be needed.
• Tightening Screws: Do not fully tighten all screws until the entire section is assembled and aligned. This allows for minor adjustments. Once all parts are in place, then fully tighten all screws.
• Missing Parts: If any parts are missing or damaged, contact customer support immediately.

Sofa Not Converting Smoothly

• Ensure no obstructions are blocking the pull-out mechanism.
• Check that the wheels on the pull-out section are clean and free of debris.
• Verify that the sofa is placed on a level surface.

Cushions Appear Flat

• Allow cushions time to expand after unpacking. Fluffing them regularly can help maintain their shape and comfort.

Product Specifications

Warranty and Support

For warranty information, technical support, or to order replacement parts, please contact Devoko customer service through the retailer where the product was purchased. Please have your model number (SF-0770) and purchase date available when contacting support.
