Poliman Móveis Ravena Modular Kitchen 3-Piece 5-Door Instruction Manual

Introduction

This manual provides detailed instructions for the assembly, operation, and maintenance of your Poliman Móveis Ravena 3-Piece 5-Door Modular Kitchen. Please read all instructions carefully before beginning assembly and retain this manual for future reference.

The Ravena modular kitchen is designed for practicality, modern aesthetics, and durability. It features resistant tops, full-extension telescopic drawer slides, and soft-close hinges for doors, ensuring efficient organization and a contemporary look.

Image 1: An overview of the Poliman Móveis Ravena modular kitchen setup, featuring upper and lower cabinets in a modern laundry or kitchen environment.

Setup and Assembly

Assembly of the Poliman Móveis Ravena modular kitchen is required. It is recommended to have at least two people for assembly. Ensure you have adequate space and the necessary tools (e.g., screwdriver, hammer, measuring tape) before starting.

Component Identification

Before assembly, identify all components and hardware using the included parts list (not provided in this manual, refer to product packaging). Verify all pieces are present and undamaged.

Image 2: Overall dimensions of the modular kitchen components. The upper cabinets measure 160 cm in total width, with one section being 80 cm wide and the other 80 cm wide. The upper cabinets have a height of 62 cm and 30 cm respectively. The lower cabinet measures 87 cm in height.

Assembly Steps (General Guidelines)

1. Prepare the Area: Clear a spacious, clean, and level area for assembly.
2. Assemble Cabinet Frames: Follow the instructions provided with your product to assemble the frames of the upper and lower cabinets. Ensure all connections are secure.
3. Install Back Panels: Attach the back panels to the cabinet frames.
4. Attach Adjustable Feet: For the lower cabinet, attach the adjustable PVC feet. Adjust them to ensure the cabinet is level on your floor.
5. Install Internal Shelves: Insert internal shelves into the designated slots.
6. Mount Doors and Drawers:
   • Attach doors using the soft-close hinges.
   • Install drawers with telescopic slides.
   • Attach polymer handles to all doors and drawers.

Image 3: Detail of an upper cabinet door, highlighting the gas piston mechanism for smooth opening and closing, and the black polymer handle.

Image 4: Interior view of a cabinet, showing an internal shelf for storage and the design of the black polymer handles on the exterior.

Image 5: Detail of the lower cabinet, illustrating the 15mm thick top, an internal shelf, black polymer handles, and the adjustable PVC feet for leveling.

Wall Mounting (Upper Cabinets)

For upper cabinets, ensure they are securely mounted to a sturdy wall using appropriate fasteners for your wall type (not included). Consult a professional if unsure about wall mounting procedures.

Operation

The Poliman Móveis Ravena modular kitchen is designed for daily use with features enhancing convenience and durability.

• Doors: The doors are equipped with soft-close hinges, allowing them to close gently and silently. Avoid forcing them shut.
• Drawers: Drawers feature telescopic slides for full extension, providing easy access to contents. Do not overload drawers beyond their weight capacity.
• Tops: The cabinet tops are resistant to scratches, moisture, and high temperatures. While resistant, avoid placing extremely hot items directly on the surface without protection.
• Adjustable Feet: The lower cabinet's adjustable PVC feet allow for perfect leveling on uneven floors. Periodically check and adjust if necessary to maintain stability.

Maintenance and Care

Proper care will extend the life and appearance of your modular kitchen.

• Cleaning Surfaces: Clean all surfaces with a soft, damp cloth and mild soap. Avoid abrasive cleaners, solvents, or harsh chemicals, as these can damage the finish.
• Spills: Wipe up spills immediately to prevent moisture absorption, especially on edges and seams.
• Heat Protection: Always use trivets or heat pads under hot pots and pans to protect the cabinet tops.
• Avoid Excessive Moisture: Do not allow water to stand on surfaces for extended periods. Ensure proper ventilation in the kitchen to prevent humidity buildup.
• Hardware Check: Periodically check all screws, hinges, and drawer slides to ensure they are tight. Tighten any loose hardware as needed.

Troubleshooting

Here are solutions to common issues you might encounter:

• Wobbly Cabinet:

  Check the adjustable PVC feet on the lower cabinet. Rotate them to raise or lower corners until the cabinet is stable and level. Ensure all assembly screws are tightened.
• Misaligned Doors:

  Hinges often have adjustment screws that allow for minor alignment corrections. Refer to the specific hinge instructions (if provided) or gently adjust screws to align doors.

• Drawers Not Sliding Smoothly:

  Ensure the drawer slides are clean and free of debris. Check that the drawer is correctly seated on the slides. Avoid overloading the drawer.

• Loose Handles:

  Tighten the screws that secure the handles from the inside of the door/drawer. Do not overtighten.

If you encounter issues not covered here or require further assistance, please contact Poliman Móveis customer support.

Specifications

Warranty Information

This Poliman Móveis product comes with a supplier warranty of 3 months. This warranty covers manufacturing defects from the date of the invoice issuance. Please retain your purchase invoice as proof of purchase for any warranty claims.

The warranty does not cover damage resulting from improper assembly, misuse, neglect, accidents, or normal wear and tear.

Customer Support

For any questions regarding assembly, missing parts, or warranty claims, please contact Poliman Móveis customer support. Have your product model number (Ravena) and purchase invoice ready when contacting support.

You can typically find contact information on the product packaging or the manufacturer's official website.
