SANODESK Q1 Electric Standing Desk User Manual

Important Safety Information

This product may present risks if not used or maintained correctly. Please read all safety instructions carefully before use. Failure to follow these instructions may result in injury or damage to the product. Do not expose the desk to water or excessive liquids. Keep children and pets away from the desk during operation.

Product Overview

The SANODESK Q1 Electric Standing Desk is designed to provide a versatile and ergonomic workspace. It features an electric height adjustment system, memory presets, and an anti-collision function for enhanced safety and convenience.

Key Features:

• Wide Height Range: Smooth electric height adjustment from 73.5 cm to 118 cm.
• Smart Control Panel: LED display with 4 memory presets for customized sitting and standing heights.
• Anti-Collision System: Automatically stops and reverses if an obstruction is detected during height adjustment.
• Quiet Operation: Motor operates below 50 dB for a distraction-free environment.
• Reliable Support: Robust construction with a maximum load capacity of 70 kg.
• Useful Accessories: Includes a cup holder, hook, storage shelf, and cable organizer for an optimized workspace.

The SANODESK Q1 Electric Standing Desk, featuring a clean white finish and ergonomic design.

Illustration of the desk's wide height range, allowing smooth adjustment between 73.5 cm and 118 cm.

The desk operates with smooth and quiet movement, maintaining a noise level below 50 dB.

The desk offers reliable support for up to 70 kg of equipment.

Setup Instructions

The SANODESK Q1 Electric Standing Desk is designed for straightforward assembly. Please follow the detailed instructions provided in the separate assembly manual included with your product packaging. It is recommended to have a clear workspace and, if possible, assistance during assembly.

General Assembly Tips:

• Unpack all components and verify against the parts list in the assembly manual.
• Ensure all screws and fasteners are securely tightened, but do not overtighten.
• Connect all electrical cables as indicated in the manual, ensuring they are not pinched.
• Perform an initial test of the height adjustment function after assembly.

The desk features a robust frame design for enhanced stability during use.

Operating Instructions

The SANODESK Q1 features an intuitive control panel for easy height adjustment and memory functions.

Height Adjustment:

• Use the Up (▲) and Down (▼) buttons on the control panel to raise or lower the desk to your desired height. The current height will be displayed on the LED screen.

Memory Presets:

The desk allows you to save up to four preferred heights for quick adjustments.

1. Adjust the desk to your desired height using the Up/Down buttons.
2. Press the Memory (M) button. The LED display will show 'S-'.
3. Immediately press one of the numbered preset buttons (1, 2, 3, or 4) to save the current height to that preset. The display will show 'S-1', 'S-2', etc., to confirm.
4. To recall a saved height, simply press the corresponding numbered preset button (1, 2, 3, or 4). The desk will automatically move to the saved position.

Anti-Collision System:

The desk is equipped with an anti-collision system to prevent damage and ensure safety. If the desk encounters an obstruction while moving up or down, it will automatically stop and reverse slightly. Remove any obstructions before resuming operation.

The smart control panel with LED display and memory functions, including the anti-collision system.

Before and after demonstration of effortless cable organization using the included accessories.

Metal hooks provide convenient storage for frequently used items like headphones.

Maintenance

Proper maintenance ensures the longevity and optimal performance of your SANODESK Q1 Electric Standing Desk.

Cleaning:

• Wipe the desk surface and frame with a soft, damp cloth.
• Avoid using harsh chemicals, abrasive cleaners, or excessive water, as these can damage the finish or electrical components.
• Ensure the desk is unplugged before cleaning any electrical parts.

General Care:

• Regularly check all screws and connections to ensure they remain tight.
• Do not overload the desk beyond its maximum weight capacity of 70 kg.
• Keep the area around the desk clear of obstructions to allow for smooth height adjustments.

Troubleshooting

If you encounter issues with your SANODESK Q1 Electric Standing Desk, refer to the following common problems and solutions.

Desk Not Moving / No Power:

• Check if the power cable is securely plugged into both the desk and a working wall outlet.
• Ensure there are no tripped circuit breakers.

Uneven Movement / Desk Stops Abruptly:

• Check for any obstructions under or around the desk that might be triggering the anti-collision system.
• Ensure the desk is not overloaded beyond its maximum weight capacity.

Error Codes on Display:

• If an error code appears, refer to the specific troubleshooting section in your detailed assembly manual. Often, unplugging the desk for 10-15 minutes and then plugging it back in can resolve minor errors.

Reset Procedure:

If the desk is not functioning correctly, a reset may be necessary:

1. Unplug the power cord from the wall outlet.
2. Wait for at least 10-15 minutes.
3. Plug the power cord back into the wall outlet.
4. Press and hold the Down (▼) button until the desk reaches its lowest position and then slightly rises, indicating a successful reset.

Specifications

Warranty Information

The SANODESK Q1 Electric Standing Desk comes with a Limited Warranty. For detailed information regarding the terms, conditions, and duration of your warranty, please refer to the warranty card included in your product packaging or visit the official SANODESK website. Keep your proof of purchase for warranty claims.

Support

If you require further assistance, have questions not covered in this manual, or need to report an issue, please contact SANODESK customer service. Contact details can typically be found on the SANODESK official website or on the product packaging.

When contacting support, please have your product model (Q1) and purchase information readily available.
