Xiaomi Semi-Automatic Espresso Machine User Manual

1. Introduction

Welcome to the user manual for your new Xiaomi Semi-Automatic Espresso Machine. This compact and powerful appliance is designed to bring barista-quality espresso and milk-based coffee drinks into your home. Featuring a 20-bar pump system, precise NTC temperature control, and a versatile steam wand, this machine ensures a rich and flavorful coffee experience. Please read this manual thoroughly before first use to ensure proper operation, maintenance, and safety.

2. Safety Instructions

Always follow basic safety precautions when using electrical appliances to reduce the risk of fire, electric shock, and injury.

• Read all instructions before operating the machine.
• Do not touch hot surfaces. Use handles or knobs.
• To protect against fire, electric shock, and personal injury, do not immerse cord, plugs, or the appliance in water or other liquid.
• Close supervision is necessary when any appliance is used by or near children.
• Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning the appliance.
• Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or has been damaged in any manner.
• The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electric shock, or personal injury.
• Do not use outdoors.
• Do not let cord hang over edge of table or counter, or touch hot surfaces.
• Do not place on or near a hot gas or electric burner, or in a heated oven.
• Always attach plug to appliance first, then plug cord into the wall outlet. To disconnect, turn any control to "off", then remove plug from wall outlet.
• Do not use appliance for other than intended use.

3. Product Overview

Familiarize yourself with the components of your espresso machine.

Image 3.1: Front view of the Xiaomi Semi-Automatic Espresso Machine, showing the control panel, portafilter, and steam wand.

Image 3.2: Angled view of the Xiaomi Semi-Automatic Espresso Machine, highlighting the water tank on the right side and the main controls.

Components:

• Water Tank: Removable 0.9L capacity tank located at the back/side of the machine.
• Control Panel: Features illuminated buttons for Power, Single Espresso (40ml), Double Espresso (80ml), and Steam function.
• Portafilter: Handle with filter basket for holding ground coffee. Includes single and double shot filter baskets.
• Steam Wand: For frothing milk for cappuccinos and lattes.
• Drip Tray: Removable tray to collect excess liquids and spills.
• Cup Warming Tray: Located on top of the machine to keep cups warm.
• Measuring Scoop/Tamper: Dual-purpose tool for measuring coffee and tamping it into the portafilter.

4. Setup

Before using your espresso machine for the first time, follow these steps:

1. Unpack: Carefully remove all packaging materials and ensure all components are present.
2. Clean Removable Parts: Wash the water tank, portafilter, filter baskets, and drip tray with warm soapy water. Rinse thoroughly and dry.
3. Fill Water Tank: Fill the water tank with fresh, cold water up to the MAX line. Place it back securely on the machine.
4. First Use / Priming:
   • Plug the machine into a grounded power outlet. The power button will illuminate.
   • Place a large cup or container under the portafilter head (without coffee).
   • Press the power button to turn on the machine. The single and double espresso buttons will flash as the machine heats up.
   • Once the buttons stop flashing and remain solid, the machine is ready.
   • Press the double espresso button (80ml) to run water through the system. Repeat this process 2-3 times to clean and prime the internal components.
   • Turn the steam knob to the steam position and let steam release for 10-15 seconds to prime the steam wand. Turn the knob back to the off position.
5. Your machine is now ready for use.

5. Operating Instructions

5.1 Making Espresso

1. Preheat: Ensure the machine is powered on and the single/double espresso buttons are solid, indicating it's preheated. For best results, attach the empty portafilter and run a short shot of hot water through it to warm it up.
2. Grind Coffee: Use freshly ground coffee. For espresso, a fine grind is essential.
3. Fill Portafilter: Place the desired filter basket (single or double) into the portafilter. Fill with ground coffee using the measuring scoop.
4. Tamp Coffee: Use the tamper to press the coffee grounds firmly and evenly into the basket. Ensure the surface is level. Wipe any excess grounds from the rim of the portafilter.
5. Attach Portafilter: Insert the portafilter into the group head and turn it firmly to the right until it is securely locked in place.
6. Place Cup: Position your espresso cup(s) on the drip tray directly under the portafilter spouts.
7. Brew Espresso: Press the single espresso button (40ml) for a single shot or the double espresso button (80ml) for a double shot. The machine will automatically stop when the programmed volume is dispensed.

Image 5.1: Side view of the machine with the portafilter securely attached, ready for brewing.

Image 5.2: Side view showing the steam wand extended, used for frothing milk.

5.2 Steaming Milk

1. Prepare Milk: Fill a stainless steel milk pitcher with cold milk (dairy or non-dairy) up to just below the spout.
2. Activate Steam: Press the steam button on the control panel. The button will flash as the machine heats up to steaming temperature, then remain solid when ready.
3. Purge Steam Wand: Before inserting into milk, briefly turn the steam knob to release any condensed water. Turn it off immediately.
4. Steam Milk: Insert the steam wand tip just below the surface of the milk. Turn the steam knob to the steam position. Angle the pitcher slightly to create a swirling motion.
5. Froth and Heat: Keep the tip near the surface for frothing, then lower it deeper to heat the milk. Continue until the milk reaches the desired temperature (around 60-65°C or 140-150°F) and texture.
6. Stop Steaming: Turn the steam knob to the off position, then remove the pitcher.
7. Clean Steam Wand: Immediately wipe the steam wand with a damp cloth to remove any milk residue. Briefly purge the steam wand again to clear any milk from the nozzle.

6. Cleaning and Maintenance

Regular cleaning ensures optimal performance and longevity of your espresso machine.

6.1 Daily Cleaning

• Portafilter and Filter Baskets: After each use, remove the portafilter, discard coffee grounds, and rinse the portafilter and filter basket under running water.
• Drip Tray: Empty and rinse the drip tray daily or when the indicator shows it's full.
• Steam Wand: Always clean the steam wand immediately after use as described in Section 5.2.
• Exterior: Wipe the exterior of the machine with a soft, damp cloth. Do not use abrasive cleaners or scourers.

6.2 Descaling

Over time, mineral deposits (limescale) can build up in the machine, affecting performance and taste. Descale your machine every 2-3 months, or more frequently if you have hard water or use it often.

1. Prepare Descaling Solution: Follow the instructions on a commercial descaling solution suitable for espresso machines. Alternatively, you can use a solution of white vinegar and water (1 part vinegar to 2 parts water).
2. Fill Water Tank: Pour the descaling solution into the water tank.
3. Run Solution: Place a large container under the portafilter and steam wand. Run half of the solution through the group head by pressing the double espresso button multiple times. Then, run the remaining half through the steam wand.
4. Rinse: After descaling, rinse the water tank thoroughly and fill it with fresh water. Run several full tanks of fresh water through both the group head and steam wand to remove any descaling solution residue.

7. Troubleshooting

If you encounter issues with your machine, refer to the following common problems and solutions:

8. Specifications

Key technical specifications for the Xiaomi Semi-Automatic Espresso Machine.

• Brand: XIAOMI
• Model Number: BHR9798EU
• Dimensions (L x W x H): 28 x 25 x 35 cm
• Weight: 3.5 Kilograms
• Power: 1350 Watts
• Voltage: 220 Volts
• Pump Pressure: 20 Bars
• Water Tank Capacity: 0.9 Liters
• Material: Stainless Steel
• Special Features: Temperature Control (NTC), Compact Design, Pre-infusion, Powerful Steam
• Automatic Shut-off: Yes

9. Warranty and Support

For warranty information and customer support, please refer to the documentation provided at the time of purchase or contact your retailer. Keep your proof of purchase for any warranty claims.
