COSTAR Cordless Tyre Inflator

1. Introduction

Thank you for choosing the COSTAR Cordless Tyre Inflator. This portable air pump is designed for convenient and efficient inflation of various items, including car tires, motorcycle tires, bicycle tires, and sports balls. Featuring a powerful 4000mAh battery, an accurate LCD display, and multiple inflation modes, it provides a reliable solution for your inflation needs. Please read this manual thoroughly before use to ensure proper operation and safety.

Image: The COSTAR Cordless Tyre Inflator demonstrating its versatility by inflating a car tire, motorcycle tire, bicycle tire, and a basketball.

2. Safety Information

To prevent injury or damage, always observe the following safety precautions:

• Keep the device away from children.
• Do not operate the inflator in wet conditions or near flammable liquids or gases.
• Avoid prolonged continuous operation to prevent overheating. Allow the device to cool down if it becomes hot.
• Ensure the correct pressure setting for the item being inflated to prevent over-inflation, which can cause bursting.
• Do not point the air nozzle at people or animals.
• Store the device in a cool, dry place when not in use.
• Use only the provided charging cable and accessories.

3. Package Contents

Verify that all items are present in the package:

• COSTAR Tyre Inflator (x1)
• Air Tube (x1)
• Type-C Charging Cable (x1)
• Extra Nozzles (x4)
• Storage Bag (x1)

Image: The COSTAR Cordless Tyre Inflator displayed alongside its complete set of accessories, including the air tube, Type-C charging cable, and multiple inflation nozzles.

4. Product Components

Familiarize yourself with the main parts of your COSTAR Tyre Inflator:

• LCD Digital Display: Shows real-time pressure, preset pressure, and battery level.
• Power Button: Turns the device on/off and starts/stops inflation.
• Mode Button: Switches between preset inflation modes (car, motorcycle, bicycle, ball) and manual mode.
• '+' / '-' Buttons: Adjusts preset pressure values.
• LED Light Button: Activates the built-in LED torch.
• Air Hose Port: Connects the air tube.
• Type-C Charging Port: For charging the device.
• USB-A Output Port: For using the device as a power bank.

Image: A detailed view of the COSTAR Cordless Tyre Inflator's LCD screen, highlighting the real-time and preset pressure readings, along with control buttons.

5. Charging the Device

Before first use, fully charge the inflator. The device is powered by a 4000mAh rechargeable battery.

1. Connect the provided Type-C charging cable to the inflator's Type-C port.
2. Connect the other end of the cable to a suitable USB power adapter (not included) or a powered USB port.
3. The battery indicator on the LCD display will show charging status.
4. Charging is complete when the battery indicator shows full.

Image: An illustration highlighting the large 4000mAh battery capacity of the inflator, capable of inflating multiple car, motorcycle, or bicycle tires, and balls on a single charge.

6. Operating Instructions

6.1 Powering On/Off

• To Power On: Press and hold the Power button for 2-3 seconds. The LCD display will light up.
• To Power Off: Press and hold the Power button for 2-3 seconds. The display will turn off. The device will also automatically power off after a period of inactivity.

6.2 Connecting to the Item

1. Remove the valve cap from the tire or item you wish to inflate.
2. Screw the air tube securely onto the valve stem.
3. Connect the other end of the air tube to the inflator's air hose port. Ensure a tight connection to prevent air leakage.
4. Once connected, the LCD display will show the current real-time pressure of the item.

Image: The COSTAR Cordless Tyre Inflator actively connected to a car tire, with its digital display showing the real-time pressure reading.

6.3 Setting Desired Pressure

1. Press the Mode button to cycle through the preset modes: Car, Motorcycle, Bicycle, and Ball. Each mode has a default pressure range.
2. In any mode, use the '+' and '-' buttons to adjust the desired target pressure. The preset value will flash while adjusting.
3. Alternatively, select the Manual mode to set any pressure between 3-150 PSI.
4. The device supports various pressure units. Refer to the manual for how to switch units if needed (e.g., PSI, BAR, KPA).

Image: An illustration emphasizing the high precision of the inflator's cylinder, capable of reaching up to 150 PSI, suitable for cars, motorcycles, bikes, and balls with their respective recommended pressure ranges.

6.4 Starting and Stopping Inflation

1. After setting the desired pressure, press the Power button to start inflation.
2. The inflator will automatically stop when the preset pressure is reached.
3. To manually stop inflation at any time, press the Power button again.
4. Once inflation is complete, carefully disconnect the air tube from the item and the inflator. Replace the valve cap.

Image: A step-by-step visual guide demonstrating the easy operation of the inflator: connecting the hose, selecting a mode, and initiating inflation.

7. Additional Features

7.1 LED Torch Function

The inflator includes a built-in LED light for illumination in low-light conditions.

• Press the LED Light button once to turn on the continuous light.
• Press again to activate the SOS flashing mode.
• Press a third time to turn off the LED light.

7.2 Power Bank Function

The device can serve as an emergency power bank for your mobile devices.

• Connect your device's charging cable to the inflator's USB-A output port.
• The inflator will begin charging your device (5V/1A output).

Image: The COSTAR Cordless Tyre Inflator demonstrating its multi-functional capabilities, including charging a smartphone via its power bank feature and providing illumination with its LED torch.

8. Maintenance

• Cleaning: Wipe the exterior of the inflator with a soft, dry cloth. Do not use harsh chemicals or abrasive cleaners.
• Storage: Store the device and its accessories in the provided storage bag in a cool, dry place, away from direct sunlight and extreme temperatures.
• Battery Care: To prolong battery life, charge the device at least once every three months if not used regularly.

9. Troubleshooting

10. Specifications

11. Warranty Information

This COSTAR product comes with a 1-year product warranty and an 18-month battery warranty from the date of purchase. Please retain your proof of purchase for warranty claims. The warranty covers manufacturing defects and malfunctions under normal use. It does not cover damage caused by misuse, accidents, unauthorized modifications, or normal wear and tear.

12. Customer Support

For any inquiries, technical assistance, or warranty claims, please contact our customer support team:

• Importer and Marketer: E-RISING (INDIA) PRIVATE LIMITED
• Address: Gala No.: 5 to 9, A-8, Opposite Sonadevi Logistics Park, Lonad Pipeline Road, Village-Lonad, Bhiwandi, Thane, Maharashtra, 421302, India
• Customer Service Contact Number: +91 9579514004
• E-mail: Support@costarcosmos.com
• WhatsApp: 9579514004
