LitezAll ULTAC3 Rechargeable Spotlight User Manual

Model: 28332

Introduction

Thank you for choosing the LitezAll ULTAC3 Rechargeable Spotlight. This manual provides important information regarding the setup, operation, maintenance, and troubleshooting of your new spotlight. Please read this manual thoroughly before using the product to ensure safe and optimal performance.

Image: The LitezAll ULTAC3 Rechargeable Spotlight, showcasing its ergonomic design and powerful light source.

Product Features

Powerful Illumination: Features high (1000 lumens), medium (500 lumens), and low (50 lumens) settings for versatile lighting needs.
Extended Runtime: Up to 11.5 hours of operation on a single charge, depending on the selected mode.
Adjustable Stand: Integrated stand with 10 locking positions for hands-free operation.
Durable Construction: Built from high-strength resin with an IPX7 water-resistant rating, suitable for demanding environments.
Rechargeable Battery: Internal 1800mAh battery with USB-C charging capability (cable included).
Portable Design: Ergonomic grip and integrated carry/hanging handle for easy transport and storage.

Image: An infographic highlighting key features: 3 Light Modes, Rechargeable (USB-C Cable Included), Weather Resistant (IPX7), and Adjustable Stand.

Setup

Initial Charging

Locate the USB-C charging port. This port is located under the rear cap of the spotlight. Unscrew the rear cap to access it.
Connect the included USB-C charging cable to the spotlight's port.
Connect the other end of the USB-C cable to a compatible USB power adapter (not included).
Allow the spotlight to charge fully before first use. The integrated LED charge indicator lights next to the USB port will show the battery status.

Note: Ensure the rear cap is securely fastened after charging to maintain the IPX7 water resistance.

Operating Instructions

Powering On/Off and Mode Selection

The spotlight features a trigger-style switch for operation.

To turn on the spotlight to High mode (1000 lumens), pull the trigger once.
To switch to Medium mode (500 lumens), pull the trigger a second time.
To switch to Low mode (50 lumens), pull the trigger a third time.
To turn off the spotlight, pull the trigger a fourth time.

Image: An infographic detailing the three light modes: High (1000 lumens, 3 hr runtime), Medium (500 lumens, 3.5 hr runtime), and Low (50 lumens, 1.5 hr runtime).

Using the Adjustable Stand

The LitezAll ULTAC3 is equipped with a built-in adjustable stand for hands-free operation.

Locate the adjustable stand on the bottom of the spotlight.
Pivot the stand outwards to deploy it.
Adjust the stand to one of the 10 locking positions to achieve the desired angle for illumination.
To retract the stand, fold it back into the spotlight body until it clicks into place.

Image: The LitezAll ULTAC3 spotlight positioned on its adjustable stand in an outdoor setting, demonstrating hands-free operation.

Practical Applications

The LitezAll ULTAC3 is designed for versatility across various scenarios:

Image: An infographic illustrating various practical use cases for the LitezAll ULTAC3 spotlight, including worksite, camping, hunting, and boating.

Image: The LitezAll ULTAC3 spotlight illuminating a dark outdoor area at night, demonstrating its powerful beam.

Maintenance

Cleaning: Wipe the spotlight with a soft, damp cloth. Do not use abrasive cleaners or solvents.
Storage: Store the spotlight in a cool, dry place when not in use. For long-term storage, ensure the battery is partially charged (around 50%) to preserve battery life. Recharge every 3-6 months if stored for extended periods.
Battery Care: Avoid fully depleting the battery frequently. Recharge promptly when the battery indicator shows low charge.
Water Resistance: Ensure the rear cap covering the USB-C port is always securely tightened to maintain the IPX7 water resistance rating.

Troubleshooting

Problem	Possible Cause	Solution
Spotlight does not turn on.	Battery is depleted.	Charge the spotlight using the provided USB-C cable.
Light output is dim.	Battery is low or spotlight is in a lower mode.	Recharge the battery. Cycle through modes by pulling the trigger to select a brighter setting.
Charging indicator lights are not active.	Charging cable not properly connected or power source issue.	Ensure the USB-C cable is securely connected to both the spotlight and the power adapter. Try a different USB power source.
Water ingress after exposure to water.	Rear cap not securely fastened.	Always ensure the rear cap covering the USB-C port is tightly screwed on before exposing the unit to water. If water has entered, discontinue use and allow to dry completely.

Specifications

Model Number	28332
Brand	LitezAll
Light Output (Max)	1000 Lumens
Battery Type	Internal 1800mAh Rechargeable
Charging Port	USB-C
Water Resistance Rating	IPX7
Material	High-strength Resin
Dimensions (L x W x H)	10.16 x 17.78 x 20.32 cm (4 x 7 x 8 inches)
Weight	372 g (0.82 lbs)
Included Components	USB-C Charging Cable

Warranty and Support

Specific warranty information for the LitezAll ULTAC3 Rechargeable Spotlight is not provided in this manual. For warranty details, product support, or to inquire about replacement parts, please refer to the product packaging or contact LitezAll customer service directly through their official website or the retailer where the product was purchased.

Please retain your proof of purchase for any warranty claims.
