EVERCROSS 701 Electric Motorcycle User Manual

1. Introduction

Welcome to the EVERCROSS 701 Electric Motorcycle user manual. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new electric motorcycle. Please read this manual thoroughly before operating the vehicle to ensure proper use and to maximize its lifespan.

The EVERCROSS 701 is a high-performance electric motorcycle designed for maximum riding pleasure, featuring a classic chopper design, powerful motor, and advanced suspension system.

2. Safety Instructions

Always prioritize safety when operating the EVERCROSS 701. Failure to follow these instructions may result in injury or damage to the vehicle.

• Always wear a helmet and appropriate safety gear (gloves, knee pads, elbow pads) when riding.
• Do not ride under the influence of alcohol or drugs.
• Familiarize yourself with local traffic laws and regulations regarding electric motorcycles.
• Perform a pre-ride inspection before each use, checking brakes, tires, and battery level.
• Avoid riding in adverse weather conditions (heavy rain, snow, ice).
• Do not exceed the maximum load capacity of 150 kg.
• Keep hands and feet away from moving parts.

3. Product Overview

The EVERCROSS 701 combines timeless design with modern electric vehicle technology. Key features include:

• Classic Chopper Design: Wide tires, high handlebars, and a well-padded seat for comfortable rides.
• Powerful Motor: 1500W brushless motor for strong acceleration and a top speed of 45 km/h.
• Long-lasting Battery: 48V 25AH high-performance lithium battery offering a range of 50-60 km per charge.
• Dual Shock Absorption System: Dampened telescopic fork and two rear shock absorbers for a smooth ride.
• LCD Display: Clear digital display showing speed, mileage, battery range, voltage, and speed gear.
• Remote Control Functions: Lock, unlock, keyless start, and vehicle search.

Figure 3.1: The EVERCROSS 701 Electric Motorcycle, showcasing its classic chopper design and robust build.

Figure 3.2: The EVERCROSS 701 with two riders, highlighting its key specifications like battery, motor power, speed, range, and load capacity.

4. Setup and Assembly

The EVERCROSS 701 comes partially assembled. Follow these steps for final assembly and initial setup:

1. Unpacking: Carefully remove all components from the packaging. Ensure all parts listed in the packing list are present.
2. Handlebar Installation: Attach the handlebars to the steering column. Secure them firmly with the provided bolts. Ensure all cables are routed correctly and not pinched.
3. Front Wheel Assembly: Install the front wheel. This step may require assistance as the motorcycle does not have a main stand. Ensure the brake caliper is correctly positioned over the disc.
4. Mirror Installation: Screw the rearview mirrors into their designated mounts on the handlebars. Adjust for optimal rear visibility.
5. Battery Installation/Charging:


   Figure 4.1: The removable 48V 25AH lithium battery being placed into its compartment under the seat.

   The 48V 25AH lithium battery is located under the seat. It can be charged externally or while installed. Connect the charger to the charging port and a power outlet. The charging indicator on the charger will show the charging status. A full charge takes approximately 8-9 hours. Ensure the battery is fully charged before first use.
6. Pre-Ride Checks: Before your first ride, double-check all bolts and connections for tightness. Verify brake functionality, tire pressure, and light operation.

5. Operating Instructions

Understanding the controls and features of your EVERCROSS 701 is crucial for a safe and enjoyable ride.

5.1 Controls and Display

Figure 5.1: Overview of the handlebar controls and the central multifunction LCD display.

• Multifunction Display: Located centrally on the handlebars. Displays current speed, daily and total mileage, battery range, battery voltage, and selected speed gear. Ensure the display is clear and readable before riding.
• Key Switch: Used to turn the motorcycle on/off.
• Speed Switch: Allows selection between 3 speed gears (25 km/h, 35 km/h, 45 km/h).
• Brakes: Front (butterfly brake) and rear (electronic brake) are controlled by levers on the handlebars.
• Headlight/Taillight: Controls for front headlight (high/low beam) and rear taillight.
• Turn Signals (Blinker): Left and right turn signal controls.
• Horn (Trompete): Activates the horn.
• Rearview Mirrors: Adjustable for optimal rear visibility.

5.2 Remote Control Functions

Figure 5.2: The remote control for the EVERCROSS 701, enabling various functions.

• Lock Button (Sperrtaste): Activates the anti-theft system and puts the vehicle into alarm mode.
• Unlock Button (Entriegeltaste): Deactivates the anti-theft system, making the vehicle ready for use.
• Start Button (Blitzsymbol - Flash Symbol):
  • When off: Press twice to activate keyless start mode.
  • After activation: Press once to exit the mode (turn off the vehicle).
• Vehicle Search Button (Fahrzeugsuch-Taste): Activates the horn within a 30-meter radius to quickly locate the vehicle.

5.3 Riding the Motorcycle

To start, turn the key to the ON position or use the keyless start function. Select your desired speed gear using the speed switch. Gently twist the throttle to accelerate. Use the brake levers to slow down or stop. The dual shock absorption system ensures a comfortable ride even on uneven surfaces.

Figure 5.3: A detailed view of the dual shock absorption system, highlighting the hydraulic shock absorber at the front and spring shock absorbers at the rear, designed for a smooth ride.

Figure 5.4: A close-up of the 1500W brushless motor integrated into the rear wheel, capable of reaching 45 km/h and offering three speed modes.

6. Maintenance

Regular maintenance ensures the longevity and optimal performance of your EVERCROSS 701.

• Battery Care:
  • Charge the battery regularly, even if not in use, to maintain its health.
  • Avoid completely draining the battery before recharging.
  • Store the battery in a cool, dry place when not in use.
• Tires: Check tire pressure regularly. Refer to the tire sidewall for recommended pressure. Inspect tires for wear and tear.
• Brakes: Periodically check brake pads for wear and ensure brake levers provide firm and responsive braking. Adjust if necessary.
• Cleaning: Clean the motorcycle with a damp cloth. Avoid using high-pressure water jets directly on electrical components.
• Fasteners: Regularly check all nuts, bolts, and screws for tightness. Tighten any loose fasteners.

7. Troubleshooting

This section addresses common issues you might encounter with your EVERCROSS 701.

If you encounter issues not listed here or if the suggested solutions do not resolve the problem, please contact EVERCROSS customer support.

8. Specifications

Detailed technical specifications for the EVERCROSS 701 Electric Motorcycle.

9. Warranty and Support

EVERCROSS products come with a standard manufacturer's warranty. Please refer to the warranty card included with your purchase for specific terms and conditions. For technical support, spare parts, or warranty claims, please contact EVERCROSS customer service through the official website or your retailer.

For more information, visit the official EVERCROSS store: EVERCROSS Store
