1. Introduction

Thank you for choosing the ONIDA 1.5 Ton 3 Star Inverter Split AC. This manual provides essential information for the safe and efficient operation, installation, and maintenance of your air conditioner. Please read this manual thoroughly before using the appliance and retain it for future reference.

2. Important Safety Information

To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring instructions may cause harm or damage.

• Installation must be performed by qualified personnel only.
• Ensure the power supply matches the rating label.
• Do not insert fingers or objects into the air inlet/outlet.
• Do not attempt to repair the unit yourself. Contact authorized service personnel.
• Keep the remote control out of reach of children.
• Ensure proper grounding to prevent electric shock.

3. Package Contents

Verify that all the following items are included in your package:

• 1 x Indoor Unit
• 1 x Outdoor Unit
• 1 x Remote Control & Batteries
• 1 x Installation Kit (including insulated 3m copper pipe, communication wires, and small accessories)
• User Manual

Image: Components included in the ONIDA AC package.

4. Product Overview

The ONIDA IR193RGS is a 1.5 Ton 3 Star Inverter Split AC designed for efficient cooling in small to medium-sized rooms (111 to 150 sq.ft). It features advanced technologies for enhanced comfort and energy savings.

Key Features:

• Inverter Compressor: Provides variable speed operation for precise temperature control and energy efficiency.
• 5-in-1 Convertible Cooling: Allows the AC to operate at 5 different capacities (40%, 60%, 80%, 100%, 120%) to suit varying cooling needs and save energy.
• AI (Artificial Intelligence): Optimizes cooling performance based on ambient conditions and user preferences.
• 4 Way Swing: Ensures uniform cooling across the room by directing airflow horizontally and vertically.
• Deep Cleaning: An automatic function that cleans the indoor unit coil, preventing dust and mold buildup.
• 100% Hi Grooved Copper Coil: Enhances heat transfer efficiency and durability, requiring low maintenance.
• Cools at 55°C: Designed to provide effective cooling even in extreme ambient temperatures up to 55°C.
• Silent Cool: Operates at a low noise level of 34dB for a peaceful environment.
• Magic Neem Filter: Helps to purify the air by trapping dust and other particles.
• Dual Drain: Offers flexibility in condensate water drainage.

Image: Overview of the ONIDA AC's powerful cooling features.

Image: Physical dimensions of the indoor and outdoor units.

5. Setup and Installation

Installation of this air conditioner requires specialized tools and knowledge. It is strongly recommended that installation be performed by a certified technician to ensure proper functioning, safety, and warranty validity.

General Guidelines:

• Location: Choose a location for the indoor unit that allows for even air distribution and is away from direct sunlight or heat sources. The outdoor unit should be placed in a well-ventilated area, away from obstructions.
• Mounting: Ensure both units are securely mounted on a stable surface.
• Drainage: Confirm proper drainage for condensate water from the indoor unit.
• Electrical Connection: Connect to a dedicated power circuit with appropriate voltage and grounding as per local electrical codes.

6. Operating Instructions

Your ONIDA AC comes with a remote control for convenient operation. Familiarize yourself with the remote's buttons and functions.

Basic Operation:

• Power On/Off: Press the POWER button to turn the unit on or off.
• Mode Selection: Use the MODE button to cycle through operating modes: Cool, Fan, Dry, Auto.
• Temperature Adjustment: Use the TEMP UP/DOWN buttons to set your desired temperature.
• Fan Speed: Adjust fan speed using the FAN button.

Advanced Features:

• 5-in-1 Convertible Mode: Activate this mode via the remote to select different cooling capacities (e.g., 40% for Feather Cool, 60% for Efficient Cool, 80% for Sensi Cool, 100% for Super Cool, 120% for Turbo Cool) based on the number of occupants or desired cooling intensity.
• AI Mode: When activated, the Artificial Intelligence feature automatically adjusts settings for optimal comfort and energy efficiency.
• 4 Way Swing: Press the SWING button to enable or disable the automatic horizontal and vertical airflow direction.
• Sleep Mode: Engages a quiet operation mode and gradually adjusts temperature for comfortable sleep.
• Turbo Cool: Provides rapid cooling to reach the set temperature quickly.

Image: Explanation of the 5-in-1 Convertible Cooling modes.

Image: Visual representation of the 4 Way Swing function.

Image: The Artificial Intelligence feature of the ONIDA AC.

7. Maintenance

Regular maintenance ensures optimal performance and longevity of your air conditioner.

Filter Cleaning:

• The Magic Neem Filter should be cleaned regularly (every 2-4 weeks, depending on usage and air quality).
• Open the front panel of the indoor unit.
• Remove the air filters.
• Clean filters with a vacuum cleaner or wash them with lukewarm water and mild detergent.
• Allow filters to dry completely before reinserting them.

Image: The Magic Neem Filter feature for air purification.

Deep Cleaning Function:

• Your AC is equipped with a Deep Cleaning function that automatically cleans the evaporator coil.
• Refer to your remote control instructions for activating this feature.
• This function helps remove accumulated dust and bacteria, improving air quality and cooling efficiency.

Image: The Deep Frost Clean feature in action.

General Cleaning:

• Wipe the exterior of the indoor and outdoor units with a soft, damp cloth.
• Do not use harsh chemicals or abrasive cleaners.
• Ensure the outdoor unit's coils are free from debris.

8. Troubleshooting

Before contacting service, check the following common issues and solutions:

If the problem persists after attempting these solutions, please contact customer support.

9. Specifications

Image: Energy Efficiency Label for the ONIDA IR193RGS AC.

10. Warranty and Support

Warranty Information:

The ONIDA IR193RGS AC comes with a manufacturer's warranty:

• 1 Year on Product
• 5 Years on Inverter Compressor (Terms & Conditions apply)

Please retain your purchase receipt for warranty claims.

Customer Support:

For any queries, service requests, or technical assistance, please contact:

• Manufacturer: MIRC Electronics Limited
• Customer Care No.: 7490955555
• Email: customer.care@onida.com
• Address: Mahakali Caves Road, Andheri East, Mumbai - 400093.
