Introduction
Thank you for choosing the Hisense Party Storm 1 Portable Party Speaker. This manual provides essential information for the safe and efficient use of your device. Please read it thoroughly before operating the speaker and retain it for future reference.
Safety Information
- Do not expose the speaker to extreme temperatures or direct sunlight.
- Avoid placing the speaker near heat sources or in humid environments.
- Ensure proper ventilation to prevent overheating.
- Do not disassemble or modify the speaker. Refer all servicing to qualified personnel.
- Keep the speaker away from water and liquids, despite its IPX4 rating, to prevent damage.
- Use only the specified charging accessories.
- Dispose of batteries and electronic components responsibly according to local regulations.
Package Contents
Please check that all items are present and in good condition:
- Hisense Party Storm 1 Portable Party Speaker
- 2 Wireless Microphones
- User Manual
- Power Cable (for charging the speaker)
Image: The Hisense Party Storm 1 portable party speaker shown vertically with two wireless microphones positioned in front. The speaker features a black casing with illuminated speaker grilles.
Product Overview
Speaker Design and Features
Image: A vertical view of the Hisense Party Storm 1 speaker, highlighting its black casing, integrated handles, and illuminated speaker grilles.
The Party Storm 1 is designed for portability and powerful audio. It features a robust black plastic casing with integrated handles for easy transport. The speaker grilles are illuminated with dynamic light effects, enhancing the party atmosphere. It is rated IPX4 for water resistance, making it suitable for outdoor use.
Image: The Hisense Party Storm 1 portable party speaker shown in a horizontal orientation, highlighting its robust design and illuminated speaker grilles.
Image: A graphic illustrating the speaker's internal components, indicating two 5.25-inch woofers and two 2.25-inch tweeters, contributing to a maximum audio output of 300 Watts.
Equipped with multiple integrated speakers, the Party Storm 1 delivers up to 300 Watts of maximum audio power, providing a voluminous sound experience with powerful bass. The speaker includes two 5.25-inch woofers and two 2.25-inch tweeters for balanced sound reproduction.
Control Panel
Image: A close-up view of the speaker's top control panel, showing various buttons for EQ, Bass, Vocal Fader, DJ effects, power, light effects, volume, and playback controls, along with a digital display and a wireless charging pad.
The top panel features touch controls for easy operation:
- Power Button: Turns the speaker on or off.
- EQ Button: Adjusts equalization settings.
- BASS Button: Enhances bass output.
- VOCAL FADER Button: Reduces vocal volume for karaoke.
- DJ Effects Button: Activates various DJ sound effects.
- Light Effects Button: Cycles through 5 different light modes.
- Volume +/- Buttons: Adjusts the master volume.
- Playback Controls: Play/Pause, Previous Track, Next Track.
- PAIR Button: Initiates Bluetooth pairing.
- Digital Display: Shows current mode, volume level, or other information.
- Wireless Charging Pad: For compatible smartphones.
Side Panel Connections
Image: A close-up view of the speaker's side panel, showing the USB port, AUX input, AUX output, microphone input with volume control, and guitar input with volume control.
The side panel provides various connectivity options:
- USB Port: For media playback from USB drives or charging external devices.
- AUX IN: 3.5mm audio input for connecting external audio sources.
- AUX OUT: 3.5mm audio output for connecting to another speaker or audio system.
- MIC IN: 6.35mm input for wired microphones, with dedicated volume control.
- GUITAR IN: 6.35mm input for a guitar, with dedicated volume control.
Setup
Charging the Speaker
Before first use, fully charge the speaker. Connect the power cable to the speaker's power input and then to a wall outlet. The charging indicator will show the charging status. A full charge provides up to 15 hours of playback time.
Microphone Setup
The Party Storm 1 includes two wireless microphones. Ensure the microphones have fresh batteries (2 AA batteries required per microphone, not included in speaker package but mentioned in product data). Turn on the microphones; they should automatically pair with the speaker. For wired microphones, connect them to the MIC IN port and adjust the microphone volume knob.
Image: A graphic promoting the karaoke mode, featuring two microphones and the text "Be a singer".
Bluetooth Pairing
- Power on the Hisense Party Storm 1 speaker.
- Press the PAIR button on the control panel to enter Bluetooth pairing mode. The display will indicate pairing status.
- On your smartphone or tablet, enable Bluetooth and search for available devices.
- Select "Hisense Party Storm 1" from the list of devices.
- Once connected, the speaker will confirm the successful pairing.
Operating Instructions
Power On/Off
Press and hold the Power Button on the top panel to turn the speaker on or off.
Audio Playback
- Bluetooth: After successful pairing, play audio from your connected device. Use the speaker's playback controls or your device's controls.
- USB: Insert a USB drive containing audio files into the USB port. The speaker will automatically switch to USB mode and begin playback.
- AUX IN: Connect an external audio source (e.g., MP3 player) to the AUX IN port using a 3.5mm audio cable. The speaker will switch to AUX mode.
Karaoke Mode
To use the karaoke function, ensure microphones are connected and powered on. Play your desired backing track via Bluetooth, USB, or AUX. Press the VOCAL FADER button to reduce the original song's vocals, allowing you to sing along. Adjust microphone volume using the dedicated knob on the side panel.
DJ Effects
Press the DJ Effects Button to cycle through 5 cool DJ effects, including drum, applause, alarm, scratch, and horn sounds, to enhance your party experience.
Light Effects
Press the Light Effects Button to switch between 5 different light modes, creating a dynamic visual display that syncs with your music.
Image: A graphic illustrating the five distinct light effects available on the speaker, depicted as colorful, dynamic patterns.
Wireless Phone Charging
Place your Qi-compatible smartphone on the wireless charging pad located on the top panel of the speaker. Ensure the phone is centered for optimal charging. The charging indicator will illuminate when charging is active.
Maintenance
- Cleaning: Use a soft, dry cloth to clean the speaker's exterior. Do not use abrasive cleaners or solvents.
- Storage: When not in use for extended periods, store the speaker in a cool, dry place.
- Battery Care: To prolong battery life, avoid fully discharging the speaker frequently. Charge it regularly, even if not in use.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Speaker does not power on. | Low battery or no power. | Charge the speaker using the provided power cable. |
| No sound from speaker. | Volume too low, incorrect input source, or device not connected. | Increase volume. Ensure correct input (Bluetooth, USB, AUX) is selected. Re-pair Bluetooth device. |
| Microphones not working. | Microphones off, low battery, or not paired. | Ensure microphones are powered on and have fresh batteries. For wired mics, check connection and volume knob. |
| Bluetooth connection unstable. | Device too far, interference, or obstacles. | Move the connected device closer to the speaker. Avoid obstacles between devices. Disconnect and re-pair. |
| Wireless charging not working. | Phone not Qi-compatible, not centered, or foreign objects. | Ensure your phone supports Qi wireless charging. Re-position the phone on the charging pad. Remove any cases or objects. |
Specifications
| Model Name | Party Storm 1 |
| Brand | Hisense |
| Color | Black |
| Dimensions (D x W x H) | 30 cm x 25.6 cm x 55 cm |
| Weight | 10.12 Kilograms |
| Max Audio Power Output | 300 Watts |
| Frequency Response | 60 Hz |
| Battery Life | Up to 15 hours |
| Power Source | Battery Powered |
| Connectivity Technology | Bluetooth, USB, AUX |
| Control Method | Touch |
| Special Features | LED Light, Lightweight, Integrated Microphone (wireless mics included), USB Port, Portable, IPX4 Water Resistance, Wireless Phone Charging, DJ Effects |
| Material | Plastic |
| Microphone Batteries | 2 AA batteries per microphone (not included) |
Warranty and Support
For warranty information and customer support, please refer to the warranty card included with your product or visit the official Hisense website. Keep your proof of purchase for warranty claims.
Note: Spare parts availability and software updates are not explicitly guaranteed beyond initial purchase. Please check the manufacturer's website for the most current information.
