Introduction
The Vamvo 150-inch Portable Projector Screen with Stand is designed for both indoor and outdoor use, providing a large viewing area for movies, presentations, and events. This manual provides essential instructions for the assembly, operation, maintenance, and troubleshooting of your projector screen system. Please read these instructions carefully before use to ensure proper setup and longevity of the product.
Product Components
Before assembly, ensure all components listed below are present in your package. Refer to the diagram for visual identification.
- 150-inch Projector Screen
- Bottom Triangular Tripod (2 units)
- Iron Tubes (for frame assembly)
- Plastic Connecting Tubes (for frame assembly)
- L-shaped Plastic Tubes (for frame assembly)
- Windproof Ropes (2 units)
- Ground Nails (4 units)
- Carrying Handbag
Image: All components included with the Vamvo 150-inch Portable Projector Screen with Stand.
Setup Instructions
The projector screen features a foldable design for quick assembly and disassembly without the need for additional tools. Follow these steps for setup:
- Unpack Components: Carefully remove all parts from the carrying handbag.
- Assemble Tripod Stands: Extend the legs of the two bottom triangular tripods to form stable bases.
- Construct Frame: Connect the iron tubes, plastic connecting tubes, and L-shaped plastic tubes to form the rectangular frame for the screen. Ensure all connections are secure.
- Attach Screen: Carefully attach the 150-inch projector screen fabric to the assembled frame. Ensure the screen is taut and wrinkle-free.
- Mount Frame to Tripods: Securely attach the assembled screen frame to the top of the tripod stands.
- Outdoor Stability (Optional): For outdoor use, enhance stability by attaching the windproof ropes to the screen frame and securing them to the ground using the provided ground nails.
Operating Instructions
The Vamvo projector screen supports both front and rear projection, offering a 160° wide viewing angle for an immersive experience.
- Positioning: Place the assembled screen in your desired viewing location. Ensure there is adequate space for your projector.
- Projector Setup: Position your projector at an appropriate distance and angle to fill the screen. Adjust focus and keystone correction on your projector for a clear, rectangular image.
- Projection Type: The screen material is designed to support both front projection (projector in front of the screen, audience in front) and rear projection (projector behind the screen, audience in front). Choose the method that best suits your setup.
Image: The Vamvo projector screen supports both front and rear projection with a 160° viewing angle.
Maintenance
Proper care and maintenance will extend the life of your projector screen.
- Cleaning: The screen is made from thickened, wrinkle-resistant polyester material and is washable. Use a mild detergent and cold water for cleaning. Do not use harsh chemicals or abrasive materials.
- Wrinkle Removal: If creases appear, the screen fabric is ironable. Use a low heat setting and place a cloth between the iron and the screen to prevent damage.
- Storage: After use, disassemble the screen and frame. Fold the screen compactly and store all components in the provided carrying handbag. Store in a cool, dry place away from direct sunlight.
Image: The screen fabric is washable and ironable for easy maintenance.
Image: The screen and components fold compactly into the carrying bag for easy transport and storage.
Troubleshooting
If you encounter issues with your Vamvo projector screen, refer to the following common problems and solutions:
- Screen is Wrinkled:
Solution: The polyester screen material is ironable. Use a low heat setting with a protective cloth to gently iron out creases. - Screen is Unstable (Outdoor Use):
Solution: Ensure the tripod legs are fully extended and stable. For added security, use the provided windproof ropes and ground nails to anchor the screen frame. - Poor Image Quality:
Solution: Check your projector's focus and keystone settings. Ensure the projector is positioned correctly relative to the screen. Verify that the screen is taut and free of wrinkles. - Missing Parts or Damaged Item:
Solution: Contact Vamvo's after-sales support team immediately for assistance.
Specifications
| Model Number | 150 inch with Stand (WFM5150) |
| Display Dimensions | 150 inches (diagonal) |
| Aspect Ratio | 16:9 |
| Viewing Angle | 160 Degrees |
| Material | Polyester |
| Screen Surface Description | Matte |
| Mounting Type | Tripod Mount |
| Item Weight | 4.55 Kilograms |
| Product Dimensions (Assembled) | 3.51W x 2.36H Meters (approx. 138W x 93H inches) |
| Supported Projection | 4K Ultra HD & 3D, Front & Rear Projection |
Warranty and Support
Vamvo is committed to providing a satisfactory shopping experience. If you encounter any issues with your projector screen, including missing parts or receiving a damaged item, please contact our after-sales support team. We aim to provide a resolution within 24 hours.
For support, please refer to the contact information provided with your purchase or visit the official Vamvo website.
