Introduction
Thank you for purchasing the Craftmade UML-LED-FB-8L Umbrella Light Set. This product is designed to provide ambient lighting for your outdoor umbrella, enhancing your patio or deck area. This manual provides essential information for the safe installation, operation, and maintenance of your new light set. Please read these instructions thoroughly before installation and retain them for future reference.
Safety Information
- Always disconnect power before installing, cleaning, or servicing the light set.
- This product is intended for outdoor use. Ensure all connections are secure and protected from moisture.
- Do not attempt to modify the light set or its components. Unauthorized modifications may void the warranty and create safety hazards.
- Keep children and pets away from the installation area.
- Ensure the umbrella structure is stable and can support the added weight of the light set.
- Use only with a properly grounded outdoor-rated extension cord if needed.
Package Contents
Verify that all components are present before beginning installation:
- 8 x LED Light Fixtures
- Connecting Cables
- Power Adapter
- Mounting Clips/Ties (pre-attached or separate)
- Instruction Manual (this document)
Setup
Follow these steps to properly install your Craftmade Umbrella Light Set:
- Prepare the Umbrella: Ensure your outdoor umbrella is clean, dry, and fully open. Identify the ribs of the umbrella where the lights will be attached.
- Attach Light Fixtures: Starting from the center of the umbrella, attach each LED light fixture to an umbrella rib using the provided mounting clips or ties. Distribute the 8 lights evenly around the umbrella for optimal illumination. Ensure the lights are securely fastened and facing downwards.
- Connect Cables: Connect the cables from each light fixture to the main power cable, ensuring all connections are tight and waterproof. Route the cables neatly along the umbrella ribs towards the umbrella pole, securing them with additional ties if necessary to prevent snagging.
- Connect Power Adapter: Plug the main power cable into the provided power adapter. Ensure the adapter is placed in a dry location or protected from rain.
- Power On: Plug the power adapter into a suitable outdoor-rated electrical outlet.
Note: For best results, ensure cables are not pinched or stressed during installation.
Operating
Operating your Craftmade Umbrella Light Set is straightforward:
- Power On/Off: Once the power adapter is plugged into an electrical outlet, the lights can be turned on or off using the switch located on the power cable (if applicable) or by plugging/unplugging the unit.
- Usage: The LED lights provide consistent illumination. There are no dimming or color-changing functions on this model.
Maintenance
Regular maintenance ensures the longevity and optimal performance of your light set:
- Cleaning: Disconnect power before cleaning. Wipe the light fixtures and cables with a soft, damp cloth. Do not use abrasive cleaners or solvents, as these can damage the finish or electrical components.
- Inspection: Periodically inspect all cables and connections for signs of wear, damage, or corrosion. Ensure all mounting clips are secure.
- Storage: During off-season or extended periods of non-use, it is recommended to remove the light set from the umbrella and store it in a cool, dry place. Ensure cables are neatly coiled to prevent tangling or damage.
- LEDs: The LED lights are integrated and not user-replaceable. If a light fails, the entire fixture may need to be replaced.
Troubleshooting
If you encounter issues with your light set, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Lights do not turn on. | No power to the outlet. Power adapter not fully plugged in. Loose cable connection. | Check the circuit breaker. Ensure the power adapter is securely plugged into a working outlet. Verify all cable connections are tight. |
| Some lights are not working. | Loose connection to a specific light fixture. Damaged light fixture. | Check the connection for the affected light. If the fixture is damaged, contact customer support. |
| Lights flicker. | Unstable power supply. Loose connection. | Ensure the power outlet provides stable power. Check all cable connections for tightness. |
Specifications
- Model: UML-LED-FB-8L
- Brand: Craftmade
- Color: Flat Black
- Number of Lights: 8
- Total Wattage: 96 Watts
- Power Source: Corded Electric
- Batteries Included: No
- UPC: 647881238889
Warranty and Support
Craftmade products are manufactured to high-quality standards and are backed by a limited warranty. For specific warranty details, please refer to the warranty card included with your purchase or visit the official Craftmade website. If you require technical assistance or have questions not covered in this manual, please contact Craftmade customer support:
- Website: www.craftmade.com
- Phone: Refer to the Craftmade website for current contact numbers.
