KOKIDO XV410 Rechargeable Medium Duty Pool Leaf Vacuum Cleaner User Manual

1. Introduction

Thank you for choosing the KOKIDO XV410 Rechargeable Medium Duty Pool Leaf Vacuum Cleaner. This manual provides essential information for the safe and efficient operation, assembly, and maintenance of your pool vacuum. Please read these instructions thoroughly before use and retain them for future reference.

The KOKIDO XV410 is designed for light to medium duty cleaning of both inground and above-ground pools, effectively removing leaves and other debris up to 6 inches in size. Its rechargeable, cordless design offers convenience and mobility for maintaining a clean pool environment.

2. Safety Instructions

• Always ensure the vacuum is turned off before assembly, disassembly, cleaning, or charging.
• Do not operate the vacuum if any part is damaged. Contact customer support for replacement parts.
• Keep the charging port dry at all times, especially before connecting the charger. Water ingress can cause electrical hazards.
• Use only the charger supplied with the unit. Using an unauthorized charger may damage the battery and void the warranty.
• Do not attempt to open the battery compartment or replace the battery yourself. This should only be done by authorized service personnel.
• This appliance is not intended for use by persons with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Keep children and pets away from the pool area during operation and charging.
• The vacuum is designed for pool cleaning only. Do not use it for other purposes.
• Not suitable for cleaning algae.

3. Package Contents

Verify that all items listed below are included in your package. If any parts are missing or damaged, please contact KOKIDO customer support.

• 1x KOKIDO XV410 Vacuum Unit with Brush
• 1x 5-Section Extendable Aluminum Pole (up to 5.5 ft)
• 1x Oversized Debris Filter Bag (1.72 Gallons, 250µ filtration)
• 1x Battery Charger
• 1x Charging Cable

4. Assembly

Follow these steps to assemble your KOKIDO XV410 pool vacuum:

1. Attach the Filter Bag: Slide the opening of the debris filter bag over the vacuum's filter collar until it is securely seated. Ensure the drawstring or clip is fastened to prevent debris from escaping.
2. Assemble the Pole: Connect the 5-section aluminum pole pieces by aligning the pins with the holes and pushing them together until they click into place. The pole can be adjusted from 2 to 5.5 feet.
3. Connect the Pole to the Vacuum: Insert the assembled pole into the designated pole connector on the vacuum unit. Ensure it is firmly attached. The vacuum is also compatible with standard telescopic poles (not included) for extended reach.

5. Charging the Battery

Before first use, fully charge the vacuum for approximately 6 hours. A full charge provides up to 75 minutes of run time.

1. Ensure the vacuum unit is dry and turned off.
2. Connect the charging cable to the charging port on the vacuum unit.
3. Plug the charger into a standard electrical outlet.
4. The LED indicator on the charger will show red during charging and turn green when fully charged.
5. Once charging is complete, disconnect the charger from the outlet and then from the vacuum unit.

6. Operation

6.1 Powering On/Off

The KOKIDO XV410 features a magnetic power switch. To turn on, rotate the switch to the 'ON' position. To turn off, rotate it to the 'OFF' position. The unit will automatically shut off when removed from water.

6.2 Using the Vacuum in the Pool

The XV410 is suitable for small to medium inground pools (under 30ft length, under 600 sq. ft. area) and above-ground pools (under 10ft depth). It works in water depths from 25 inches to 6.5 feet.

1. Ensure the vacuum is fully charged and assembled with the pole and filter bag.
2. Submerge the vacuum head into the pool water. Once submerged, turn the magnetic power switch to the 'ON' position. The unit will begin to operate.
3. Slowly guide the vacuum across the pool floor and walls. The built-in soft-bristle brushes provide a 2-in-1 scrubbing and vacuuming action.
4. The Powerblade technology delivers a water flow rate of 30 GPM for efficient cleaning.
5. The vacuum is designed to collect debris such as sand, gravel, small stones, twigs, and leaves up to 8 inches. It is particularly effective for leaves up to 6 inches.
6. Monitor the filter bag for fullness. If suction decreases, the bag may need emptying.
7. When finished, turn the power switch to 'OFF' and carefully remove the vacuum from the pool. Rotate the device 90 degrees when pulling it out to reduce strain on the pole connection.

7. Maintenance

7.1 Cleaning the Filter Bag

After each use, or when suction decreases, the filter bag should be cleaned:

1. Turn off the vacuum and remove it from the pool.
2. Detach the filter bag from the vacuum unit.
3. Empty the collected debris into a waste receptacle.
4. Rinse the filter bag thoroughly with a garden hose to remove any remaining fine particles. Ensure all debris, especially from any sewn-in flotation devices, is cleared.
5. Allow the filter bag to air dry completely before storing or reattaching.

7.2 Post-Use Care and Storage

• Thoroughly hose off the entire vacuum unit to remove any chlorine or salt water residue.
• Ensure the charging port is completely dry before storage.
• Store the vacuum in a cool, dry, temperature-controlled environment, away from direct sunlight and extreme temperatures.
• For optimal battery life, charge the battery every 3-6 months if not in regular use.

8. Troubleshooting

9. Specifications

10. Warranty and Support

For warranty information, technical support, or to purchase replacement parts and accessories, please visit the official KOKIDO website or contact their customer service department. Keep your purchase receipt as proof of purchase.
