Paruu P10 Hands-Free Electric Breast Pump User Manual

1. Introduction

Thank you for choosing the Paruu P10 Hands-Free Electric Breast Pump. This device is designed to provide a comfortable, efficient, and discreet milk expression experience for mothers. Please read this manual thoroughly before first use to ensure proper operation, safety, and maintenance of your breast pump. Keep this manual for future reference.

2. Safety Information

Important Safeguards:

• Always inspect the pump and its components for damage before each use. Do not use if any part is damaged.
• Ensure all parts are clean and sterilized before initial use and after each subsequent use.
• This product is intended for personal use only. Sharing the pump may pose health risks.
• Do not immerse the pump motor unit in water or other liquids.
• Keep out of reach of children. This is not a toy.
• Use only the provided charging cable and a compatible 5V 1A adapter.
• If you experience pain or discomfort during pumping, stop immediately and consult a healthcare professional.
• Store breast milk according to recommended guidelines to maintain its quality and safety.

3. Product Overview and Components

The Paruu P10 breast pump consists of several key components designed for easy assembly and effective milk expression.

Image: Overview of the Paruu P10 Hands-Free Electric Breast Pump, showing two pump units, charging cables, and various flange inserts (19mm, 21mm, 24mm) alongside the standard 28mm flange.

Main Components:

• Pump Motor Unit: Contains the motor, control panel, and rechargeable battery.
• Milk Collector Cup: Collects expressed milk, with a capacity of up to 150ml (optimal collection 120ml).
• Flange (28mm): The part that comes into contact with the breast.
• Flange Inserts (19mm, 21mm, 24mm): For adjusting the flange size to ensure a comfortable and effective fit.
• Silicone Diaphragm: Creates the vacuum for suction.
• Valve: Directs milk flow into the collector cup and prevents backflow.
• USB Charging Cable: For recharging the pump's battery.

4. Setup and Assembly

Proper assembly is crucial for the pump's performance and hygiene.

4.1. Cleaning Before First Use

Before using your breast pump for the first time, disassemble all parts that come into contact with breast milk (milk collector cup, flange, flange inserts, silicone diaphragm, valve). Wash them thoroughly with warm soapy water, rinse well, and then sterilize them according to the manufacturer's instructions (e.g., boiling for 5 minutes or using a sterilizer).

Image: A woman washing the disassembled components of a breast pump in a kitchen sink, demonstrating the cleaning process.

4.2. Flange Size Selection

Choosing the correct flange size is essential for comfort and efficient milk expression. The pump comes with a 28mm flange and inserts for 19mm, 21mm, and 24mm. Use the provided nipple measurement card to determine your ideal size.

Image: A four-step diagram illustrating how to find the correct flange size: 1. Stimulate the nipple, 2. Find the measuring place (nipple base), 3. Measure nipple diameter with a ruler/card, 4. Get your flange size from the chart.

4.3. Assembly Steps

Assemble the dry and clean parts as follows:

1. Insert the Valve: Gently push the valve into the bottom of the milk collector cup, ensuring there are no gaps.
2. Attach the Flange: Securely push the flange (or flange with insert) into the top of the milk collector cup, ensuring a tight seal.
3. Place the Diaphragm: Attach the silicone diaphragm onto the top of the flange, pressing down firmly around the edges to create a complete seal.
4. Connect the Motor Unit: Align the pump motor unit with the assembled milk collector cup and press down firmly until it clicks into place, ensuring a secure connection without gaps.

Image: A visual guide demonstrating the four steps for correct breast pump assembly: 1. Inserting the valve, 2. Attaching the flange, 3. Sealing the diaphragm, and 4. Assembling the pump motor with the milk collector.

5. Operating Instructions

The Paruu P10 offers intuitive controls and multiple modes for a personalized pumping experience.

5.1. Charging the Pump

Before first use, fully charge the pump for approximately 2 hours. A full charge provides 4-5 uses. The LED display will indicate charging status. Ensure the charging port is clean before connecting the USB cable.

Image: An illustration of the pump's control unit highlighting its 1100mAh battery, 2-hour charging time, 20-minute auto-off feature, and LED display, indicating it provides power for 4-5 uses.

5.2. Wearing the Pump

Once assembled, place the pump inside your nursing bra, ensuring the flange is centered over your nipple. The hands-free design allows for discreet and comfortable use.

Image: A woman sitting comfortably on a couch, wearing the discreet Paruu P10 breast pump under her top, emphasizing its lightweight (240g) and comfortable design.

5.3. Powering On and Mode Selection

Press the power button to turn on the pump. The LED screen will illuminate, showing the current mode and suction level. The Paruu P10 features 4 modes and 9 suction levels:

• Stimulation Mode: Quick and short suction to initiate milk let-down.
• Expression Mode: Slower and longer suction for effective milk expression.
• Two-in-one Mode: Combines 8 shallow suctions with 1 deep suction.
• Dual-frequency Mode: Repeats with low suction-pause-high suction-release, helpful for inverted or flat nipples.

Image: A graphic detailing the four distinct modes of the Paruu P10 breast pump: Stimulation, Expression, Two-in-one, and Dual-frequency, each with a brief description of its suction pattern.

Use the '+' and '-' buttons to adjust the suction intensity within each mode. The pump has a maximum suction of 338 mmHg, providing hospital-grade efficiency.

Image: A woman holding a baby while pouring milk, with an overlay graphic comparing the P10's 338mmHg suction to other pumps at 300mmHg, highlighting its hospital-grade efficiency.

5.4. Pumping Session

Begin with Stimulation Mode to encourage let-down, then switch to Expression Mode or another suitable mode once milk begins to flow. Pump until your breasts feel empty or milk flow significantly slows. The pump operates with low noise, ensuring minimal disturbance.

Image: Two Paruu P10 breast pumps on a nightstand next to a bed where a mother and baby are sleeping, illustrating the pump's low noise level (below 60dB) that does not disturb sleep.

5.5. Pouring Breast Milk

After pumping, carefully remove the pump from your bra. To pour the milk:

1. Remove and Keep Upright: Take off the pump and keep it upright to prevent spills.
2. Remove Pump Motor: Gently remove the pump motor unit from the milk collector cup.
3. Pour Milk: Carefully pour the expressed milk into a storage bottle or bag, keeping the collector aligned to avoid spillage.

Image: A three-step visual guide demonstrating how to safely pour breast milk from the collector cup: 1. Take off the pump and keep it upright, 2. Gently remove the pump motor, and 3. Keep it aligned and pour the milk into a storage container.

6. Maintenance and Cleaning

Regular cleaning and maintenance are vital for hygiene and the longevity of your pump.

6.1. Daily Cleaning

After each use, disassemble all parts that come into contact with breast milk. Wash them immediately with warm water and mild dish soap. Use a soft brush to clean hard-to-reach areas. Rinse thoroughly with clean water. Air dry on a clean rack or use a clean cloth. Ensure all parts are completely dry before reassembling or storing.

6.2. Sterilization

Sterilize all milk-contacting parts at least once a day. Methods include:

• Boiling: Place parts in a pot of boiling water for 5 minutes.
• Steam Sterilizer: Use a microwave or electric steam sterilizer according to its instructions.
• Dishwasher: Some parts may be top-rack dishwasher safe (check product specifications).

Do not sterilize the pump motor unit. Wipe it clean with a damp cloth only.

7. Troubleshooting

If you encounter issues with your Paruu P10 breast pump, refer to the following common problems and solutions:

If the problem persists after trying these solutions, please contact Paruu customer support.

8. Specifications

9. Warranty and Support

Paruu products are manufactured to high-quality standards. For specific warranty details, please refer to the warranty card included with your product or visit the official Paruu website. If you have any questions, concerns, or require technical assistance, please contact Paruu customer support through the retailer where you purchased the product or via the contact information provided on the official Paruu brand store.
