1. Introduction
This manual provides essential instructions for the safe and efficient operation of your AFERIY P210S 2400W Portable Power Station. Please read this manual thoroughly before using the product and retain it for future reference.
Safety Guidelines
- Do not disassemble, repair, or modify the unit.
- Keep the unit away from fire or extreme temperatures.
- Avoid exposure to water or high humidity.
- Ensure proper ventilation during use and charging.
- Keep out of reach of children.
2. Package Contents
Verify that all items listed below are included in your package:
- 1x AFERIY P210S 2400W Portable Power Station
- 2x AFERIY 200W Portable Solar Panels
- 1x AC Charging Adapter
- 1x MC4-XT90 Cable (for solar panel connection)
- 1x Storage Bag & Protective Cover
- 1x User Manual
3. Product Overview
The AFERIY P210S is a high-capacity portable power station designed for various power needs, from home backup to outdoor adventures. It features a robust LiFePO4 battery and multiple output options.
Front Panel Controls and Ports
- LCD Display: Shows battery level, input/output wattage, remaining runtime, and status indicators.
- Power Button: Turns the unit on/off.
- Light Button: Activates the integrated LED light with multiple modes.
- DC Output Ports: Includes 12V/10A, 12V/3A (x2), and 12V/25A (car port) for various DC devices.
- USB Output Ports: Features QC 3.0 (x2), PD 20W (x3), and PD 100W (x1) for fast charging mobile devices.
- AC Output Ports: Two standard 110V AC outlets with a total output of 2400W (4800W surge) and pure sine wave output.
Rear Panel Ports
- AC Input: For charging the power station via a wall outlet.
- DC (XT90) Input: For connecting solar panels or car charger.
- Overload Protection Button: Resets the unit in case of overload.
4. Setup
Initial Charging
Before first use, fully charge the AFERIY P210S. This can be done via AC wall outlet or solar panels.
- AC Charging: Connect the AC Charging Adapter to the AC Input port on the rear panel and plug it into a wall outlet. The unit will fully charge in approximately 2 hours.
- Solar Charging: Connect the MC4-XT90 cable to your solar panels and then to the DC (XT90) Input port on the rear panel. Optimal charging time with 500W solar input is approximately 5 hours.
- Dual Charging (AC + Solar): For the fastest charge, combine AC and solar input. This can fully charge the unit in approximately 1.5 hours.
Mobile App Control (BrightEMS)
Download the BrightEMS mobile app to monitor battery status and manage the power station remotely. Follow the in-app instructions for pairing your device.
5. Operating the Power Station
Powering On/Off
Press and hold the Power Button on the front panel for a few seconds to turn the unit on or off. The LCD display will illuminate.
Using Output Ports
- AC Outlets: Press the AC Button to enable/disable AC output. Connect your devices (up to 2400W total, 4800W surge). The pure sine wave output ensures safe power for sensitive electronics.
- DC Outlets: Press the DC Button to enable/disable DC output. Connect your 12V devices.
- USB Ports: USB ports are typically active when the unit is on. Connect your USB-powered devices for charging.
Uninterruptible Power Supply (UPS) Function
The P210S features a built-in UPS system. When connected to an AC wall outlet and powering devices, it can automatically switch to battery power within 10 milliseconds during a power outage, ensuring continuous operation for connected devices.
LED Light Operation
Press the Light Button to cycle through different lighting modes (e.g., low, medium, high, SOS). Press and hold to turn off the light.
Power Adjustment
The unit supports 5-level power adjustment to optimize charging scenarios and battery longevity. Refer to the LCD display for current power settings.
6. Solar Panel Usage
The AFERIY P210S kit includes two 200W portable solar panels for efficient off-grid charging.
Features of AFERIY Solar Panels
- High Efficiency: Monocrystalline cells with 23% conversion rate.
- Durability: Crafted with tough Oxford fabric and advanced ETFE coating for longer lifespan.
- Weather Resistance: IP65 water and dust resistance.
- Portability: Foldable design for easy transport and setup.
7. Maintenance
Battery Care
The AFERIY P210S uses a LiFePO4 battery, known for its longevity and safety. It is rated for over 4000 charge cycles, providing up to 10 years of reliable service.
- For optimal battery life, avoid completely draining the battery frequently.
- Recharge the unit at least once every 3-6 months if not in regular use.
- Do not operate the unit in below-freezing temperatures, as this can affect LiFePO4 battery performance and longevity.
Storage
Store the power station in a cool, dry place, away from direct sunlight and extreme temperatures. Ensure the unit is partially charged (50-80%) before long-term storage.
Cleaning
Use a soft, dry cloth to clean the exterior of the unit. Do not use abrasive cleaners or immerse the unit in water.
8. Troubleshooting
- Unit not turning on: Ensure the battery is charged. If not, connect to an AC outlet for charging.
- No output from ports: Ensure the specific output (AC/DC) is enabled by pressing its respective button. Check if the device connected is within the power station's wattage limits.
- Overload Protection triggered: If an overload occurs, the unit may shut down. Disconnect the overloaded device and press the Overload Protection button on the rear panel to reset.
- Slow charging: Verify that the charging source (AC adapter, solar panels) is functioning correctly and providing adequate power. For solar charging, ensure panels are in direct sunlight and properly angled.
9. Specifications
| Feature | Specification |
|---|---|
| Brand | AFERIY |
| Model Name | AF-P210 |
| Battery Type | LiFePO4 |
| Battery Capacity | 2048Wh |
| AC Output | 2400W (4800W Surge), 110V, Pure Sine Wave |
| Total Power Outlets | 16 |
| Fast Charging (AC + Solar) | 1.5 Hours |
| AC Charging Time | 2 Hours |
| Solar Panel Efficiency | 23% (Monocrystalline) |
| UPS Function | 10ms Switchover |
| Item Weight | 48.5 Pounds |
| Product Dimensions | 15.43"L x 10.98"W x 12.72"H |
| Material | ABS |
| Special Features | Portable, Quick charging, Rechargeable Battery, Solar charging |
10. Warranty and Support
The AFERIY P210S Portable Power Station comes with a 7-year warranty, which can be extended upon online registration. For any product inquiries, technical support, or warranty claims, please contact AFERIY customer service through their official channels or the retailer where the product was purchased.
