POXURIO 2000W Sump Pump Battery Backup System User Manual

1. Introduction and Overview

The POXURIO 2000W Sump Pump Battery Backup System is an essential device designed to provide continuous power to your sump pump during unexpected power outages. This system ensures your basement remains dry and protected from flooding, offering peace of mind during storms or grid failures. It features a high-performance pure sine wave inverter and a rapid 20A battery charger, making it a reliable solution for emergency power needs.

Figure 1: The POXURIO 2000W Sump Pump Battery Backup System unit, showing its front panel with outlets, switches, and LCD display, along with included cables and fuses.

2. Safety Information

Please read and understand all safety instructions before installing or operating this system. Failure to follow these instructions may result in electric shock, fire, serious injury, or property damage.

• Always disconnect power before performing any maintenance or installation.
• Do not expose the unit to water, rain, snow, spray, or excessive moisture.
• Ensure adequate ventilation around the unit to prevent overheating. Do not block ventilation openings.
• Connect the system only to a compatible 12V deep cycle battery (not included).
• Avoid short-circuiting the battery terminals.
• Do not open the unit's casing. There are no user-serviceable parts inside. Refer servicing to qualified personnel.
• Keep children and pets away from the unit during operation.
• Use appropriate personal protective equipment (PPE) when handling batteries.

3. Package Contents

Verify that all items listed below are included in your package:

• 1 x POXURIO 2000W Sump Pump Battery Backup System Unit
• 1 x Red Battery Cable (Positive)
• 1 x Black Battery Cable (Negative)
• 1 x AC Power Cord
• Several Spare Fuses
• 1 x User Manual (this document)

4. Product Features

The POXURIO Sump Pump Battery Backup System is equipped with advanced features for reliable performance:

• 2000W High Performance: Capable of generating a stable pure sine wave 120 VAC waveform, simultaneously supplying power to multiple sump pumps (up to 3-4 depending on individual pump wattage) within the 2000W limit.
• 20A Fast Charging: Designed for rapid battery replenishment, it can charge a 100AH battery in approximately 5 hours, significantly faster than standard chargers, ensuring quick system readiness.
• Home Backup System: Automatically switches to battery power during grid outages, maintaining continuous operation of your connected sump pump(s).
• LCD Display: Provides real-time monitoring of critical operational parameters including voltage, frequency, working temperature, battery level, and load power.
• Quick Plug Function: Features a convenient 3-pin plug design for quick, secure, and safe installation, minimizing potential safety risks.

Figure 2: Illustration showing the 2000W battery output capacity, capable of powering 2-3 sump pumps simultaneously.

Figure 3: Diagram illustrating the 20A fast charging capability, showing a 100AH battery fully charged in approximately 5 hours.

Figure 4: Depiction of the system's dual power source functionality, showing how it can be powered by AC or automatically switch to battery power for continuous operation.

5. Setup

Follow these steps to set up your POXURIO Sump Pump Battery Backup System:

1. Prepare the Battery: Ensure you have a fully charged 12V deep cycle battery (e.g., marine battery, RV battery). This system does not include a battery.
2. Connect Battery Cables:
   • Connect the RED battery cable to the POSITIVE (+) terminal of the battery.
   • Connect the other end of the RED battery cable to the POSITIVE (+) terminal on the back of the backup system unit.
   • Connect the BLACK battery cable to the NEGATIVE (-) terminal of the battery.
   • Connect the other end of the BLACK battery cable to the NEGATIVE (-) terminal on the back of the backup system unit.
   • Ensure all connections are tight and secure.
3. Connect AC Power: Plug the provided AC power cord into the "Grid Input" socket on the front panel of the unit. Then, plug the other end of the AC power cord into a standard 120V AC wall outlet.
4. Connect Sump Pump(s): Plug your sump pump(s) directly into the "AC Output 120V" sockets on the front panel of the backup system. Ensure the total wattage of connected devices does not exceed 2000W.
5. Initial Power On: Once all connections are secure, flip the "Power" switch on the front panel to the "ON" position. The LCD display should illuminate.

Figure 5: Detailed view of the system's front panel (top) showing output sockets, breaker, power switch, USB, and grid input, and the back panel (bottom) with positive and negative DC input terminals and cooling fans.

6. Operation

Operating the POXURIO Sump Pump Battery Backup System is straightforward:

• Power On/Off: Use the "Power" switch on the front panel to turn the unit ON or OFF.
• LCD Display Monitoring: The integrated LCD display provides real-time operational status:
  • Voltage: Displays the current output voltage (120 VAC).
  • Frequency: Shows the output frequency (60 Hz).
  • Working Temperature: Indicates the internal temperature of the unit.
  • Battery Level: Shows the remaining charge of the connected battery.
  • Load Power: Displays the current power consumption of connected devices in watts.
• Automatic Switchover: When the main AC power supply is interrupted (e.g., during a power outage), the system will automatically and seamlessly switch to battery power to keep your sump pump running.
• Automatic Charging: Once the main AC power is restored, the system will automatically switch back to AC power and begin recharging the connected battery using its 20A fast charger. The "Working/Charge" indicator light will show the charging status.
• Breaker: The unit includes a resettable breaker. If an overload occurs, the breaker may trip to protect the system. Reduce the load and press the breaker button to reset.

Figure 6: Close-up of the LCD display, showing real-time information such as battery voltage, output voltage, load, and temperature.

7. Maintenance

Regular maintenance ensures the longevity and optimal performance of your backup system:

• Battery Inspection: Periodically check the battery terminals for corrosion. Clean them with a wire brush and a baking soda solution if corrosion is present. Ensure connections remain tight.
• Unit Cleaning: Keep the unit's exterior clean and free from dust and debris. Use a soft, dry cloth for cleaning. Do not use liquid cleaners or solvents.
• Ventilation: Ensure that the cooling fans and ventilation openings are not obstructed. Proper airflow is crucial to prevent overheating.
• Battery Charge Level: If the system is not in continuous use, periodically check the battery charge level and recharge it fully every 2-3 months to prolong battery life.
• Storage: If storing the unit for an extended period, disconnect it from the battery and AC power. Store it in a cool, dry place.

8. Troubleshooting

Refer to the table below for common issues and their solutions:

If the problem persists after attempting these solutions, please contact POXURIO customer support.

9. Specifications

10. Warranty and Support

POXURIO is committed to providing high-quality products and customer satisfaction. For any technical assistance, troubleshooting beyond this manual, or warranty inquiries, please contact POXURIO customer support through the retailer's platform or the official POXURIO website. Please have your product model number and purchase date ready when contacting support.

For the most up-to-date warranty information, please refer to the warranty card included with your product or visit the official POXURIO website.
