1. Introduction
The Daytech 3-in-1 Water Leak Detector and Alarm is designed to provide early warning of water leaks, drips, and rising water levels in various areas of your home or RV. This device helps prevent costly water damage by alerting you with a loud alarm when water is detected. Its versatile design allows for placement in tight spaces, offering peace of mind for areas prone to water issues such as basements, bathrooms, kitchens, and utility rooms.
Figure 1: Prevent water damage with the Daytech Water Leak Detector. The image illustrates common water damage scenarios in a home, such as a flooded floor and a damaged cabinet under a sink, with the water leak detector prominently displayed as a solution.
2. Product Features
- Comprehensive Leak Detection: Detects minor drips, major leaks, and rising water levels. The sensor probe can identify droplets as small as 0.4mm (0.015 inches).
- Extended Detection Cable: Features a 79-inch (2m) cable and a slim 0.3-inch (0.8cm) thick probe, ideal for reaching tight spaces under appliances and in confined areas.
- Loud Audible Alarm: Emits an alarm up to 100dB with 4 adjustable volume levels, ensuring the alert is heard throughout your home.
- Independent Operation: Functions without requiring an internet connection, providing reliable performance.
- Battery-Powered with Low-Battery Alert: Operates on two AAA batteries (included) and provides an audible "Di" sound alert every minute when battery power is low.
- Easy Installation: Simple setup with included adhesive backing, screws, and wall anchors for flexible mounting options.
Figure 2: Versatile placement for water leak detection. The image displays the water leak detector in different household environments such as a laundry room next to a washing machine, under a kitchen sink, near a water heater, inside a sump pump, and next to an outdoor air conditioner unit.
3. Package Contents
Your Daytech 3-in-1 Water Leak Detector and Alarm package includes the following items:
- 2 x Detector Main Units
- 2 x Water Leak/Drip Sensing Probes (with 79-inch cable)
- 4 x AAA Batteries (2 per detector)
- 2 x Adhesive Stickers
- 2 x User Manuals
- 2 x Cable Fixers
- Screws and Wall Anchors for mounting
Figure 3: Contents of the Daytech Water Leak Detector package. The image displays two main detector units, two water leak/drip sensing probes, AAA batteries, adhesive stickers, a user manual, cable fixers, and mounting screws, all neatly arranged.
4. Setup
- Install Batteries: Open the battery compartment on the back of the main detector unit. Insert two AAA batteries, ensuring correct polarity. Close the compartment securely.
- Connect Sensor Probe: Plug the sensor probe's 3.5mm jack into the corresponding port on the main detector unit.
- Position the Main Unit: Choose a suitable location for the main detector unit. It can be mounted on a wall using the provided adhesive sticker or screws and wall anchors. Ensure the unit is easily accessible for battery changes and alarm silencing.
- Place the Sensor Probe: Extend the 79-inch detection cable and place the slim probe in the area where water leaks are most likely to occur. The probe should lie flat on the surface, with its metal contacts facing downwards, to detect water effectively. Use the included cable fixers to secure the cable if needed.
Figure 4: Battery installation and low battery alert. The image shows the back of the main detector unit with the battery cover removed, illustrating the placement of two AAA batteries. A graphic indicates a low battery alert with a 'Di' sound.
Figure 5: Probe placement in a tight space. The image demonstrates the slim design of the water leak detector's probe and its long cable, allowing it to be easily positioned in narrow gaps, such as under a washing machine.
5. Operating Instructions
5.1. Alarm Activation
When the sensor probe detects water, the main unit will emit a loud alarm. The alarm sounds for 4 seconds, then pauses for 4 seconds, and repeats this cycle until the water is no longer detected or the battery is depleted.
Figure 6: Alarm behavior and silencing. The image depicts the water leak detector sounding an alarm upon water detection and the process of temporarily pausing the alarm by pressing its button.
5.2. Silencing the Alarm
To temporarily silence the alarm, press the button on the main unit. The alarm will pause for 10 seconds. If the leak is not addressed within this time, the alarm will resume. This feature allows you to investigate the source of the leak without constant noise.
5.3. Volume Adjustment
The detector features 4 adjustable volume levels, up to 100dB. Use the volume control buttons on the side of the main unit to select your preferred alarm loudness.
Figure 7: Alarm sound coverage in a home. The image displays a house layout with water leak detectors strategically placed in different areas, indicating that the 100dB alarm is audible throughout the entire house.
5.4. Low Battery Alert
When the battery voltage drops below 2.4V, the detector will emit a "Di" sound alert once every minute to indicate low battery. Replace the batteries promptly to ensure continuous protection. If the voltage drops below 1.7V, the unit will power off.
Video 1: Daytech Water Sensor Alarm Leak Detector. This video demonstrates the functionality of the Daytech water leak detector, including its alarm sound, sensor placement, and low battery alert. It shows the device in action, detecting water and alerting the user.
6. Maintenance
- Battery Replacement: When the low battery alert sounds, replace both AAA batteries in the main unit. Always use fresh batteries for optimal performance.
- Sensor Cleaning: Periodically inspect the sensor probe for any dirt, dust, or debris that might interfere with its detection capabilities. Clean the metal contacts with a soft, dry cloth if necessary.
- Regular Testing: It is recommended to test the alarm periodically by placing the sensor probe in a small amount of water to ensure it is functioning correctly.
7. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Alarm does not sound when water is detected. | Dead or low batteries; Sensor contacts not fully immersed; Faulty sensor probe. | Replace batteries. Ensure sensor contacts are fully touching the water. Test with a known working sensor or contact support. |
| Alarm sounds intermittently or falsely. | Sensor contacts are dirty or corroded; High humidity causing condensation; Sensor placed on an uneven surface. | Clean sensor contacts with a dry cloth. Relocate the sensor to a less humid area. Ensure the sensor lies flat on the surface. |
| Low battery alert sounds frequently. | Batteries are nearing end of life; Using non-alkaline batteries. | Replace with fresh, high-quality alkaline AAA batteries. |
| Alarm volume is too low/high. | Volume setting is not adjusted correctly. | Use the volume control buttons on the main unit to adjust to the desired level. |
8. Specifications
| Feature | Detail |
|---|---|
| Model Number | 3in1-2 Pack |
| Power Source | 2 x AAA Batteries (included) |
| Noise Level | Up to 100 Decibels |
| Control Method | Touch (for silencing/volume) |
| Sensor Technology | Contact Sensor |
| Detection Cable Length | 79 inches (2 meters) |
| Probe Thickness | 0.3 inches (0.8 cm) |
| Product Dimensions | 4 x 3 x 2 inches (Main Unit) |
| Item Weight | 6.4 ounces |
| Mounting Type | Tabletop Mount / Wall Mount (adhesive/screws) |
9. Warranty and Support
For warranty information, technical support, or any questions regarding your Daytech 3-in-1 Water Leak Detector and Alarm, please refer to the contact information provided in the packaging or visit the official Daytech website. Keep your purchase receipt for warranty claims.
