Introduction
Thank you for choosing the BRILONER Riffle Cordless LED Floor Lamp. This innovative and stylish lighting solution is designed for both indoor and outdoor use, offering flexibility and elegant illumination. This manual provides comprehensive instructions for the safe and efficient operation, maintenance, and troubleshooting of your new lamp. Please read this manual thoroughly before use and retain it for future reference.
Key Features:
- Cordless operation with a powerful 3600 mAh replaceable battery.
- IP44 water resistance for versatile placement in various environments.
- Stepless touch dimming with memory function for personalized lighting.
- Warm white light (2700K) for a comfortable and inviting ambiance.
- Convenient USB-C charging for easy power replenishment.
- Award-winning German design, recognized with the German Design Award 2025 and Best of Design Award 2025.
Safety Instructions
Please observe the following safety precautions to prevent injury or damage to the product:
- Do not expose the lamp to extreme temperatures or direct sunlight for prolonged periods.
- The lamp has an IP44 rating, meaning it is protected against splashing water from any direction. It is not designed for submersion in water.
- Use only the provided USB-C cable for charging. Ensure the power adapter (not included) meets the required specifications.
- Do not attempt to open or repair the lamp yourself, except for replacing the battery or LED module as instructed. Unauthorized repairs may void the warranty and pose safety risks.
- Keep the lamp away from flammable materials.
- Ensure the lamp is placed on a stable, level surface to prevent it from tipping over.
- The integrated battery complies with European standard EN62133-2. Charge the lamp regularly to prevent deep discharge, which can damage the battery.
Package Contents
Carefully unpack the box and ensure all items are present and in good condition:
- BRILONER Riffle Cordless LED Floor Lamp (124cm, beige)
- USB-C to C Charging Cable (1.5m)
- Mounting Accessories (if applicable for specific assembly steps)
- Instruction Manual (this document)
Setup
Your BRILONER Riffle Floor Lamp is designed for easy setup. Follow these steps to prepare your lamp for use:
- Unpack the Lamp: Carefully remove all components from the packaging. Retain packaging for future storage or transport.
- Assembly (if required): If your lamp requires minor assembly (e.g., attaching the base or shade), use the provided mounting accessories and follow any specific diagrams included with the product. Ensure all connections are secure.
- Initial Charge: Before first use, fully charge the lamp. Connect the supplied USB-C cable to the lamp's charging port and to a compatible USB power adapter (not supplied). Allow sufficient time for a full charge.
Operating Instructions
The BRILONER Riffle Floor Lamp features intuitive touch control for easy operation:
- Power On/Off: Locate the touch control area on the lamp (typically on the top or side of the shade). A short tap will turn the lamp on or off.
- Dimming Function: To adjust the brightness, touch and hold the control area. The light will gradually dim or brighten. Release your finger when the desired brightness level is reached. The lamp offers stepless dimming from approximately 10% to 100%.
- Memory Function: The lamp will remember your last brightness setting when turned off and will resume that setting when turned back on.
Charging and Battery
The BRILONER Riffle Floor Lamp is equipped with a high-capacity, replaceable battery for extended cordless operation.
- Charging: Connect the supplied 1.5m USB-C to C cable to the lamp's USB-C port and to a compatible USB power adapter (not included). A charging indicator (if present) will typically show the charging status.
- Battery Life: A fully charged 3600 mAh battery provides an impressive lighting duration of up to 18 hours, depending on the brightness level used.
- Replaceable Components: Both the battery and the LED module are designed to be replaceable, ensuring a longer product lifespan and sustainability.
- Deep Discharge Protection: The lamp features deep discharge protection. If the lamp has not been used for a long period, this protection prevents charging a potentially damaged battery. To maintain battery health, charge the lamp regularly, even during periods of non-use.
Maintenance
Proper care and maintenance will ensure the longevity and optimal performance of your BRILONER Riffle Floor Lamp:
- Cleaning: To clean the lamp, gently wipe it with a soft, dry cloth. Do not use abrasive cleaners, solvents, or harsh chemicals, as these can damage the finish.
- Battery Care: To maximize battery life, charge the lamp regularly. If storing the lamp for an extended period, ensure it is fully charged before storage and recharge it every few months to prevent deep discharge.
- Storage: Store the lamp in a cool, dry place when not in use.
- Component Replacement: As the battery and LED module are replaceable, consult the manufacturer's guidelines or contact customer support for instructions on how to safely replace these components when necessary.
Troubleshooting
If you encounter any issues with your BRILONER Riffle Floor Lamp, please refer to the following troubleshooting guide:
| Problem | Possible Cause | Solution |
|---|---|---|
| Lamp does not turn on | Battery is depleted. Lamp is not switched on. | Charge the lamp using the USB-C cable. Tap the touch control to turn on. |
| Lamp does not charge | USB-C cable or power adapter is faulty. Battery is in deep discharge protection. | Ensure the USB-C cable is securely connected and the power adapter is functional. If the lamp has been unused for a long time, try charging it for an extended period; if it still doesn't charge, the battery might need replacement. |
| Short battery life | Operating at high brightness. Battery degradation. | Reduce brightness for longer runtime. If battery life significantly decreases, the replaceable battery may need to be changed. |
| Light flickers or is inconsistent | Loose connection or internal component issue. | Ensure all parts are securely assembled. If the issue persists, contact customer support. |
If these solutions do not resolve the issue, please contact BRILONER customer support for further assistance.
Specifications
Detailed technical specifications for the BRILONER Riffle Cordless LED Floor Lamp:
| Feature | Detail |
|---|---|
| Model Number | 1238011 |
| Product Dimensions (L x W x H) | 19 x 19 x 124.1 cm |
| Item Weight | 1.94 Kilograms |
| Material | Metal |
| Shade Material | Metal |
| Shade Color | Beige |
| Finish Type | Textured |
| Light Source Type | LED |
| Wattage | 4.2 Watts |
| Color Temperature | 2700K (Warm White) |
| Control Method | Touch |
| Switch Type | Push Button / Touch |
| Power Source | Battery Powered (USB-C rechargeable) |
| Battery | 3600 mAh (replaceable) |
| Ingress Protection (IP) Rating | IP44 (Splash-proof) |
| Energy Efficiency Class | F |
| Usage | Indoor / Outdoor (Garden, Home, Living Room) |
| Manufacturer | Briloner Leuchten |
| Country of Origin | China |
Warranty and Support
BRILONER Leuchten is a German manufacturer of lighting solutions with a commitment to quality and design since 1978. The BRILONER Riffle Floor Lamp has been recognized for its exceptional design, receiving the German Design Award 2025 and the Best of Design Award 2025 from Schöner Wohnen.
For warranty information, technical support, or to inquire about replacement parts (such as the battery or LED module), please contact your retailer or visit the official BRILONER website. Please have your model number (1238011) and proof of purchase ready when contacting support.
