1. Introduction
Thank you for purchasing the XIWBSY Mini Projector Portable. This device is designed to provide a versatile and immersive viewing experience for home entertainment, presentations, and outdoor activities. Its compact size, wireless connectivity, and high-quality projection capabilities make it an ideal solution for various media needs. Please read this manual thoroughly before operating the projector to ensure proper use and optimal performance.
2. Safety Information
To prevent fire, electric shock, or injury, please observe the following safety precautions:
- Do not expose the projector to rain or moisture.
- Do not open the projector casing. Refer all servicing to qualified personnel.
- Ensure proper ventilation. Do not block ventilation openings.
- Use only the power adapter supplied with the projector.
- Avoid direct eye exposure to the projector lens when the lamp is on.
- Keep the projector away from heat sources and direct sunlight.
- Operate the projector in a clean, dust-free environment.
3. Package Contents
Verify that all items are present in your package:
- XIWBSY Mini Projector Portable (Model: B0DR8PGXYN)
- Power Adapter
- Remote Control
- User Manual
Image: The XIWBSY Mini Projector Portable, shown alongside its remote control and power adapter, illustrating the typical contents of the product package.
4. Product Overview
Familiarize yourself with the various parts of your XIWBSY Mini Projector Portable.
Image: Top view of the projector, highlighting the control panel with power, navigation, and OK buttons.
Image: Rear view of the projector, displaying the HDMI, USB, and AV input ports, along with the power input.
4.1 Front Panel
- Projection Lens: Emits the image onto the screen.
- IR Receiver: Receives signals from the remote control.
4.2 Top Panel
- Power Button: Turns the projector on/off.
- Navigation Buttons: Used to navigate menus.
- OK Button: Confirms selections.
- Return Button: Goes back to the previous menu.
4.3 Rear Panel
- HDMI Port: Connects to HDMI-enabled devices (laptops, game consoles, TV sticks).
- USB Port: Connects to USB storage devices for media playback.
- AV Port: Connects to older devices using an AV cable.
- Power Input: Connects to the power adapter.
4.4 Side Panel
- Focus Ring: Adjusts image sharpness.
- Keystone Correction: Adjusts image distortion.
- Speaker: Built-in audio output.
5. Setup
5.1 Powering On
- Connect the supplied power adapter to the projector's Power Input port.
- Plug the power adapter into a wall outlet.
- Press the Power button on the projector or the remote control to turn on the device.
5.2 Image Adjustment
- Focus: Rotate the focus ring on the side of the projector until the projected image appears clear and sharp.
- Keystone Correction: Use the keystone correction dial on the side of the projector to adjust the image if it appears trapezoidal. The projector also features auto keystone correction for convenience.
5.3 Connecting to Devices
The projector supports multiple connectivity options:
- HDMI: Connect an HDMI cable from your laptop, game console, or streaming device to the projector's HDMI port. Select HDMI as the input source.
- USB: Insert a USB flash drive into the USB port to play media files directly. Select USB as the input source.
- AV: Use an AV cable to connect to devices with AV output. Select AV as the input source.
- Wireless (Wi-Fi):
- Navigate to the Wi-Fi settings on the projector's main menu.
- Select your desired 2.4GHz or 5GHz Wi-Fi network and enter the password.
- Once connected, you can use screen mirroring features from your smartphone or tablet.
- Bluetooth:
- Go to the Bluetooth settings in the projector's menu.
- Enable Bluetooth and search for available devices.
- Select your Bluetooth speaker or headphones to pair for enhanced audio.
6. Operating the Projector
6.1 Main Menu Navigation
Use the navigation buttons on the projector or remote control to move through the main menu options. Press the OK button to select an item and the Return button to go back.
6.2 Screen Mirroring (Wireless Projection)
This feature allows you to display content from your smartphone or tablet wirelessly.
- Ensure your projector and mobile device are connected to the same Wi-Fi network.
- On the projector, select the "Screen Mirroring" or "Wireless Projection" option from the main menu.
- On your mobile device (e.g., iPhone), activate the screen mirroring function (e.g., "Screen Mirroring" for iOS, "Smart View" or "Cast" for Android).
- Select the projector's name from the list of available devices.
- The mobile device's screen will now be projected.
Image: The XIWBSY Mini Projector in operation, projecting a clear image onto a large screen, demonstrating its use in a home setting.
6.3 Media Playback from USB
- Insert a USB flash drive containing media files (videos, photos, music) into the USB port.
- Select "USB" as the input source from the main menu.
- Browse the files and select the one you wish to play.
7. Maintenance
Regular maintenance ensures the longevity and optimal performance of your projector.
- Lens Cleaning: Use a soft, lint-free cloth specifically designed for optical lenses to gently wipe the projector lens. Do not use abrasive cleaners or excessive force.
- Casing Cleaning: Wipe the projector's exterior with a soft, dry cloth. For stubborn marks, slightly dampen the cloth with water. Avoid using chemical cleaners.
- Ventilation: Ensure the ventilation openings are free from dust and obstructions. Periodically clean them with a soft brush or compressed air.
- Storage: When not in use for extended periods, store the projector in a cool, dry place, protected from dust and direct sunlight.
8. Troubleshooting
If you encounter issues with your projector, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| No image projected | Power not connected, incorrect input source, lens cap on. | Check power connection, select correct input source (HDMI, USB, AV, Screen Mirroring), remove lens cap. |
| Image is blurry | Focus not adjusted, projector too close/far from screen. | Adjust the focus ring, reposition the projector for optimal distance. |
| Image is distorted (trapezoidal) | Keystone not adjusted, projector not perpendicular to screen. | Adjust the keystone correction dial. Ensure the projector is placed on a flat surface. |
| No sound | Volume too low, external audio device not connected, incorrect audio output selected. | Increase volume, check Bluetooth connection, ensure internal speaker is selected or external speakers are properly connected. |
| Cannot connect to Wi-Fi/Screen Mirroring | Incorrect Wi-Fi password, devices not on same network, network interference. | Verify Wi-Fi password, ensure both devices are on the same 2.4GHz or 5GHz network, try restarting router and devices. |
9. Specifications
| Feature | Detail |
|---|---|
| Brand | XIWBSY |
| Model | B0DR8PGXYN |
| Display Resolution | 1920 x 1080 (Full HD) |
| Connectivity Technology | Wi-Fi (2.4GHz/5GHz), HDMI, USB, AV, Bluetooth |
| Special Features | Portable, Auto Keystone Correction, Auto Focus, Built-in HiFi Speaker, Screen Mirroring |
| Recommended Uses | Home Cinema, Outdoor Entertainment, Presentations |
| Item Weight | 2.42 pounds |
| Product Dimensions | 7 x 4.72 x 2.75 inches |
10. Warranty and Support
The XIWBSY Mini Projector Portable comes with a standard manufacturer's warranty. Please refer to the warranty card included in your package for specific terms and conditions. For technical support, troubleshooting assistance, or warranty claims, please contact XIWBSY customer service through the official website or your purchase platform.
For additional protection, consider the available protection plans:
- 2-Year Protection Plan
- 3-Year Protection Plan
- Complete Protect (monthly plan)
Note: Protection plans are optional and may be purchased separately.
