MONODEAL AI Translator Earbuds User Manual

1. Introduction

Thank you for choosing the MONODEAL AI Translator Earbuds. These innovative earbuds provide seamless real-time language translation, high-quality audio for music and calls, and a comfortable wearing experience. This manual will guide you through the setup, operation, and maintenance of your new device to ensure optimal performance.

Image: The MONODEAL AI Translator Earbuds, showcasing the earbuds and their charging case. The case displays a digital battery percentage.

2. Package Contents

Please check the package for the following items:

• MONODEAL AI Translator Earbuds (Left and Right)
• Charging Case
• USB Charging Cable
• User Manual (this document)

3. Product Features

• Real-time Voice Translation: Supports over 134 languages for seamless communication.
• Multiple Translation Modes: Includes AI Chat, Free Talk, Translation Machine, and Headphone/Phone modes to suit various communication scenarios.
• Comfortable Open-Ear Design: Lighter and more comfortable for extended wear compared to traditional in-ear designs.
• Premium Sound Quality: Equipped with advanced dynamic drivers for crystal-clear stereo sound and HiFi audio.
• Clear Calls: Built-in sensitive microphone with noise reduction for clear voice communication.
• Long Battery Life: Up to 8 hours of playtime on a single charge for the earbuds, and an additional 16 hours with the charging case.
• High-speed Bluetooth 5.4: Ensures fast and stable wireless connectivity.
• IPX7 Waterproof Rating: Provides protection against sweat and light splashes.

Image: An infographic highlighting key features such as 8 hours earphone battery, 16 hours with charging case, IPX7 waterproof, Bluetooth 5.3, and stereo clear audio.

Image: A visual representation of Bluetooth 5.4 technology, emphasizing faster connection and performance.

4. Setup Guide

4.1 Charging the Earbuds and Case

1. Place the earbuds into the charging case. Ensure they are correctly seated.
2. Connect the USB charging cable to the charging port on the case and plug the other end into a USB power source (e.g., wall adapter, computer USB port).
3. The LED indicator on the charging case will show the charging status. A full charge takes approximately 3 hours for the case and earbuds.

4.2 Bluetooth Pairing

1. Open the charging case. The earbuds will automatically enter pairing mode.
2. On your smartphone or device, enable Bluetooth and search for available devices.
3. Select "MONODEAL CTF-C35" (or similar name) from the list of devices to connect.
4. Once connected, you will hear a confirmation tone from the earbuds.

4.3 App Download and Setup

To utilize the full translation capabilities, download the dedicated MONODEAL translation app on your smartphone.

1. Scan the QR code provided in the physical user manual or search for "MONODEAL Translator" in your device's app store (iOS App Store or Google Play Store).
2. Install the app and follow the on-screen instructions to complete the setup.
3. Ensure your earbuds are connected via Bluetooth to your phone before launching the app for translation functions.

Image: A world map background with icons for Android and Apple, indicating where to download the companion app for the earbuds.

5. Operating Instructions

5.1 Basic Controls

The earbuds feature touch controls for various functions:

• Play/Pause: Single tap on either earbud.
• Next Track: Double tap on the right earbud.
• Previous Track: Double tap on the left earbud.
• Answer/End Call: Single tap on either earbud.
• Reject Call: Press and hold either earbud for 2 seconds.
• Activate Voice Assistant: Triple tap on either earbud.

5.2 Translation Modes

The MONODEAL app offers several translation modes:

• AI Chat Mode: For natural, continuous conversation translation.
• Free Talk Mode: Allows two people to speak freely, with the app translating in real-time.
• Translation Machine Mode: Use your phone as a handheld translator, speaking into it and having the translation played through the earbuds or phone speaker.
• Headphone Mode: One person wears the earbuds, the other speaks into the phone.
• Phone Mode: Both parties speak into the phone, with translations displayed on screen.

Image: A visual demonstrating real-time translation with the earbuds, showing text translation on a smartphone screen.

5.3 Audio and Video Call Translation

The earbuds support real-time translation during audio and video calls when used with the compatible app. This feature allows you to communicate with individuals speaking different languages directly through your calls.

Image: A person on a video call, demonstrating the real-time translation feature with speech bubbles showing different languages.

6. Maintenance

To ensure the longevity and optimal performance of your MONODEAL AI Translator Earbuds, follow these maintenance guidelines:

• Cleaning: Regularly wipe the earbuds and charging case with a soft, dry, lint-free cloth. Do not use abrasive cleaners or solvents.
• Storage: When not in use, store the earbuds in their charging case to protect them from dust and damage.
• Avoid Extreme Conditions: Do not expose the earbuds to extreme temperatures, humidity, or direct sunlight.
• Water Resistance: While IPX7 rated, avoid submerging the earbuds in water. Dry them thoroughly if they get wet.
• Charging: Use only the provided charging cable or a certified equivalent.

7. Troubleshooting

If you encounter any issues with your earbuds, refer to the following common problems and solutions:

8. Specifications

9. Warranty and Support

For warranty information and customer support, please refer to the warranty card included in your product packaging or visit the official MONODEAL website. If you have any questions or require assistance, do not hesitate to contact our customer service team.

Manufacturer: MONODEAL

Model Number: CTF-C35
