1. Introduction
Thank you for choosing the BEDSURE Heated Blanket, Model BS-EU180200. This electric blanket is designed to provide warmth and comfort with advanced features for safety and ease of use. Please read this manual thoroughly before using the product to ensure proper operation and to maximize your experience. Keep this manual for future reference.
2. Important Safety Instructions
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons.
- Read All Instructions: Read all instructions carefully before using the heated blanket.
- Do Not Use Folded or Bunched: Never operate the blanket when it is folded, bunched, or crumpled, as this can cause overheating.
- Avoid Sharp Objects: Do not use pins or other metallic objects with this blanket. They can damage the heating elements.
- Keep Dry: Do not use the blanket on an adjustable bed unless the blanket can lie flat and is not pinched or bunched.
- Power Source: Connect the blanket only to a 220-240V AC power supply.
- Automatic Shut-Off: The blanket features an automatic shut-off after 8 hours of continuous use (if no timer is set) to prevent overheating.
- Overheat Protection: Equipped with advanced overheat protection technology for enhanced safety.
- Certifications: This product is GS, CE, and RoHS certified, and has passed 74 safety tests exceeding UL standards.
- Children and Persons with Reduced Capabilities: This appliance can be used by children aged 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
- Medical Conditions: Consult a doctor before use if you have a pacemaker, are pregnant, or have any medical conditions that may be affected by heat.
- Storage: When not in use, store the blanket in a cool, dry place.
3. Package Contents
Please check the package contents upon receipt. If any items are missing or damaged, contact Bedsure customer support.
- 1 x BEDSURE Heated Blanket (180 x 200 cm)
- 1 x Detachable Digital Controller
Image: The Bedsure Heated Blanket, neatly folded, with its detachable digital controller and product packaging box.
4. Product Features
- Adjustable Heat: 6 distinct heating levels for personalized comfort.
- Programmable Timer: 10 time settings, allowing you to set the blanket to operate for up to 10 hours.
- Pre-heating Function: Quickly heats to level 6 for one hour, then automatically adjusts to level 2 for sustained comfort.
- Automatic Shut-Off: Automatically turns off after 8 hours if no specific timer is set, enhancing safety.
- Overheat Protection: Integrated safety system to prevent overheating.
- Premium Material: Exceptionally soft flannel and sherpa fabric on both sides for enhanced comfort and durability.
- Machine Washable: Detachable controller allows for easy machine washing.
- Precise Temperature Control: Advanced heating wire technology ensures accurate and safe temperature regulation.
Image: A detailed view of the detachable digital controller, highlighting its intelligent pre-heating function, 10 time settings, and 6 heating levels.
Image: An exploded diagram illustrating the 3-layer heat retention technology, including skin-friendly plush, fast-heating wires, and a heat-retaining sherpa-fleece layer, with a comparison of improved heating wires.
5. Setup
- Unpack: Carefully remove the heated blanket and controller from its packaging.
- Connect Controller: Locate the connector on the blanket and firmly plug in the detachable digital controller. Ensure it clicks securely into place.
- Position Blanket: Lay the blanket flat on your bed or sofa. Ensure there are no folds, creases, or bunched areas that could impede heat distribution or cause overheating.
- Plug In: Plug the power cord of the controller into a standard 220-240V AC electrical outlet.
Image: The Bedsure Heated Blanket draped over a sofa, ready for use, with the controller visible.
6. Operating Instructions
The digital controller allows you to easily manage the blanket's settings.
- Power On/Off: Press the power button (O/I) to turn the blanket on or off. The display will illuminate when on.
- Adjust Heating Level: Press the heat level button (Heat icon) to cycle through the 6 heating levels (1-6). The current level will be displayed.
- Set Timer: Press the timer button (Clock icon) to select a desired operating time from 1 to 10 hours. The display will show the selected hours. If no timer is set, the blanket will automatically shut off after 8 hours.
- Pre-heating Function: To activate the pre-heating function, select heat level 6. The blanket will rapidly heat for one hour, then automatically switch to heat level 2 for gentle, sustained warmth. This mode is set to a 10-hour default timer.
Image: A graphic demonstrating the improved heating comfort and faster, more even warming provided by the Bedsure blanket, with a person comfortably sleeping under it.
7. Care and Maintenance
Proper care ensures the longevity and performance of your heated blanket.
- Before Cleaning: Always unplug the blanket from the wall outlet and detach the controller from the blanket before cleaning.
- Machine Washing: The blanket is machine washable. Use a gentle cycle with cold water. Do not bleach.
- Drying: Tumble dry on low heat or line dry. Ensure the blanket is completely dry before reconnecting the controller and using it.
- Do Not Iron: Do not iron the heated blanket.
- Storage: When not in use, roll or fold the blanket loosely and store it in a cool, dry place. Avoid placing heavy objects on top of it.
8. Troubleshooting
If you encounter issues with your Bedsure Heated Blanket, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Blanket does not heat. | Not plugged in; controller not connected properly; power outage; internal safety shut-off activated. | Ensure power cord is securely plugged into outlet. Check controller connection to blanket. Verify power supply. Unplug for 5 minutes, then plug back in to reset. |
| Controller display is not working. | No power; loose connection. | Check power plug and controller connection. |
| Blanket feels too hot or not warm enough. | Heat setting too high/low; blanket is folded or bunched. | Adjust heat setting. Ensure blanket is spread flat and not folded. |
| Blanket automatically turns off unexpectedly. | Timer expired; 8-hour auto shut-off activated; safety feature triggered. | Check timer setting. This is a normal safety feature. If it happens frequently without a set timer, contact support. |
If the problem persists after attempting these solutions, please contact Bedsure customer support.
9. Specifications
| Feature | Detail |
|---|---|
| Model Number | BS-EU180200 |
| Dimensions | 180 x 200 cm |
| Material | Flannel, Sherpa |
| Heating Levels | 6 |
| Timer Settings | Up to 10 hours |
| Automatic Shut-Off | 8 hours (if no timer set) |
| Special Features | Temperature Regulation, Overheat Protection, Machine Washable, Pre-heating Function |
| Power Supply | 220-240V AC |
| Certifications | GS, CE, RoHS |
| Weight | 2.1 kilograms |
10. Warranty and Support
For warranty information and customer support, please refer to the documentation included with your purchase or visit the official Bedsure website. If you have any questions or require assistance, do not hesitate to contact Bedsure customer service.
You can find more information and contact details on the Bedsure website: www.bedsurehome.com
