Introduction
This manual provides detailed instructions for the AVerMedia Elite Go GC313PRO, a versatile device combining a 1080p60 HDMI video capture card, a 100W GaN USB-C fast charger, and a multi-port USB-C hub with 4K60Hz HDMI output. It is designed for users who require portable solutions for streaming, gaming, and charging multiple devices.
Package Contents
Verify that all items listed below are present in your package:
- AVerMedia GC313 ELITE GO USB-C Fast Charger (Capture Card) x1
- USB Type-C to Type-C Braided Cable (2m/6.56ft) x1
- Changeable AC Plug x1 (Region-specific)
- Quick Start Guide x1 (This document serves as the detailed user manual)
Image: The AVerMedia Elite Go GC313PRO unit, a USB-C to USB-C braided cable, and two interchangeable AC plugs (EU and UK types).
Product Overview
The AVerMedia Elite Go GC313PRO integrates multiple functionalities into a compact form factor:
- 1080p60 HDMI Video Capture: Record or stream Full HD video at 60 frames per second.
- 4-in-1 USB Charging Hub: Provides video output, charging, data transfer, and hardware expansion.
- 4K60Hz HDMI Output: Connect to external displays for high-resolution video.
- 100W GaN USB Charger: Efficiently power up to three devices simultaneously with overload protection.
- Wide Compatibility: Supports devices such as Nintendo Switch, ROG Ally, Steam Deck, MacBook Air/Pro, iPads, and iPhones.
Image: An overview of the AVerMedia Elite Go GC313PRO's main features, including quick charging, GaN technology, video capture, protection, multi-device charging, and 4K HDMI display.
Setup
1. Power Connection
- Select the appropriate AC plug for your region and attach it to the AVerMedia Elite Go GC313PRO.
- Plug the device into a wall outlet.
2. Connecting to a Source Device (e.g., Nintendo Switch, Steam Deck, Laptop)
Use the included USB Type-C to Type-C cable to connect your source device to the USB-C (Video Source) port on the GC313PRO.
Image: The AVerMedia Elite Go GC313PRO positioned next to a Nintendo Switch 2 console and its dock, highlighting its compatibility.
3. Connecting to a Display (TV/Monitor)
Connect an HDMI cable (not included) from the HDMI output port on the GC313PRO to your TV or monitor. The device supports up to 4K60Hz output.
4. Connecting to a PC for Video Capture
To capture video, connect the GC313PRO to your computer using the USB-C (Video Capturing) port and the included USB Type-C to Type-C cable. Your computer will recognize the device as a webcam. Use compatible capture software (e.g., OBS Studio, VLC Media Player) to record or stream.
Image: A detailed diagram illustrating the various input and output connections of the AVerMedia Elite Go GC313PRO, including USB-C for video source, HDMI for monitors, USB-C for video capturing, and USB-A for peripherals.
5. Firmware Update (Recommended)
For optimal performance and compatibility, especially with newer devices like the Nintendo Switch 2, it is recommended to update the device firmware. Firmware updates typically require a Windows PC. Refer to the AVerMedia official website for the latest firmware and update instructions.
Operating Instructions
Video Capture
The GC313PRO captures video at 1080p resolution and 60 frames per second. Once connected to your PC via the USB-C (Video Capturing) port, open your preferred streaming or recording software. Select the GC313PRO as your video input device. Adjust settings within the software as needed for your desired output.
Image: A user playing a game on a handheld device, with the AVerMedia Elite Go GC313PRO connected to capture the gameplay to a laptop, demonstrating 1080p60 video capture.
HDMI Output
When connected to a compatible source device and an external display, the GC313PRO functions as a docking station, providing up to 4K60Hz HDMI output. This allows you to play games or view content from your handheld device or laptop on a larger screen.
Image: Examples of the AVerMedia Elite Go GC313PRO providing HDMI 4K60 display for both handheld gaming and general entertainment on external monitors or TVs.
Charging Functionality
The 100W GaN charger supports fast charging for various devices. Power distribution varies based on the number of connected devices:
- Single-Port Charging: One USB-C port can deliver up to 100W.
- Two-Port Charging: Power is distributed, for example, 45W + 45W or 100W + 5W depending on the ports used.
- Three-Port Charging: Power is distributed, for example, 45W + 5W + 45W.
Refer to the 'Specifications' section for detailed power distribution diagrams.
Image: Fast charging capabilities of the AVerMedia Elite Go GC313PRO, showing devices like iPhone 16 Pro Max, iPad Pro 11, and Samsung S24 Ultra reaching 50% charge in 20-30 minutes.
Image: The AVerMedia Elite Go GC313PRO simultaneously charging a laptop, a tablet, and wireless earbuds, demonstrating its triple-device charging capability.
Hub Functionality
The USB-A port supports connecting peripherals such as microphones, keyboards, mice, and USB drives for data transfer or control.
Maintenance
To ensure the longevity and optimal performance of your AVerMedia Elite Go GC313PRO:
- Keep the device clean and free from dust. Use a soft, dry cloth for cleaning.
- Avoid exposing the device to extreme temperatures, humidity, or direct sunlight.
- Do not attempt to disassemble or repair the device yourself. This may void the warranty and cause damage.
- Ensure proper ventilation when in use, especially during prolonged operation or when charging multiple devices, as the unit may become warm.
Troubleshooting
No Video Output/Capture
- Check Connections: Ensure all cables (USB-C, HDMI) are securely connected to the correct ports on the GC313PRO, source device, display, and PC.
- Power Supply: Verify the GC313PRO is properly plugged into a working wall outlet.
- Source Device Settings: Confirm that your source device (e.g., Nintendo Switch) is configured to output video via USB-C/HDMI.
- PC Software: For capture, ensure your streaming/recording software recognizes the GC313PRO as a video input and that its settings are correct.
- Firmware: Ensure the device firmware is up to date, especially for compatibility with newer consoles.
Charging Issues
- Cable Quality: Use the included USB-C cable or a high-quality, certified USB-C to USB-C cable that supports power delivery.
- Power Distribution: Be aware that the 100W total power is shared across ports. If multiple devices are connected, the power to each device will be lower. Refer to the power output diagrams in the 'Specifications' section.
- Device Compatibility: Ensure your device supports USB Power Delivery (PD) for fast charging.
Device Becomes Warm During Use
It is normal for the GC313PRO to become warm during operation, especially when charging multiple devices or during video capture. The device includes over-heating protection. Ensure adequate ventilation and avoid covering the unit.
Image: An illustration of the safety features built into the AVerMedia Elite Go GC313PRO, including protection against overheating, short circuits, overcurrent, and over-voltage.
Specifications
| Model Number | GC313 Pro |
| Brand | AVerMedia |
| Dimensions | 7.56 x 4.69 x 2.91 inches |
| Item Weight | 1.19 pounds |
| Connector Type | USB Type A, USB Type C, HDMI |
| Total USB Ports | 3 (2x USB-C, 1x USB-A) |
| Input Voltage | 240 Volts |
| Amperage | 5 Amps |
| Video Capture Resolution | 1080p60 |
| HDMI Output Resolution | Up to 4K60Hz |
| Special Features | 1080p60 Video Capture, Fast Charging, Lightweight Design, Multi Device Charging, Short Circuit Protection |
| Compatible Devices | Game Consoles (Nintendo Switch, ROG Ally, Steam Deck), Headphones, Monitors, PC, Tablets, Laptops, iPhones, iPads |
Power Output Distribution
Image: Visual representation of how the 100W power is distributed among the USB-C and USB-A ports when one, two, or three devices are connected simultaneously.
Warranty and Support
The AVerMedia Elite Go GC313PRO is manufactured by AVerMedia Technologies Inc.
For warranty information, technical support, driver downloads, and firmware updates, please visit the official AVerMedia website or contact their customer support directly. Keep your purchase receipt for warranty claims.
Manufacturer: AVerMedia Technologies Inc.
