SANAG T11 Wireless Earbuds User Manual

Introduction

This manual provides detailed instructions for the proper use, setup, and maintenance of your SANAG T11 Wireless Earbuds. Please read this manual thoroughly before using the product to ensure optimal performance and longevity.

Package Contents

Verify that all items are present in your package:

• SANAG T11 Wireless Earbuds (Left and Right)
• Charging Case
• USB Charging Cable
• User Manual (this document)

Setup

1. Initial Charging

Before first use, fully charge the earbuds and the charging case.

1. Place both earbuds into the charging case. Ensure they are correctly seated.
2. Connect the USB charging cable to the charging port on the case and to a compatible USB power source.
3. The indicator light on the charging case will show charging status. A full charge typically takes approximately 1.5 to 2 hours.
4. Once fully charged, disconnect the charging cable. The earbuds provide up to 5 hours of playback, and the charging case extends total listening time to approximately 40 hours.

Image: SANAG T11 Wireless Earbuds placed inside their charging case, illustrating the charging setup.

2. Bluetooth Pairing

Pair your SANAG T11 earbuds with your device for wireless audio.

1. Open the charging case. The earbuds will automatically power on and enter pairing mode. The indicator lights on the earbuds will flash, indicating they are ready to pair.
2. On your device (smartphone, tablet, etc.), go to the Bluetooth settings.
3. Search for available devices and select "SANAG T11" from the list.
4. Once connected, the earbud indicator lights will stop flashing, and you will hear a confirmation tone.
5. The earbuds will automatically reconnect to the last paired device when removed from the case, if Bluetooth is enabled on the device.

Operating Instructions

Power On/Off

• Power On: Open the charging case, or press and hold the touch control area on both earbuds for 3 seconds.
• Power Off: Place the earbuds back into the charging case and close the lid, or press and hold the touch control area on both earbuds for 5 seconds.

Music Playback

• Play/Pause: Tap the touch control area on either earbud once.
• Next Track: Triple-tap the touch control area on the right earbud.
• Previous Track: Triple-tap the touch control area on the left earbud.
• Volume Up: Double-tap the touch control area on the right earbud.
• Volume Down: Double-tap the touch control area on the left earbud.

Call Management

• Answer/End Call: Tap the touch control area on either earbud once.
• Reject Call: Press and hold the touch control area on either earbud for 2 seconds.

Noise Cancellation

The SANAG T11 earbuds feature Active Noise Cancellation (ANC) for voice calls, designed to reduce background noise for clearer conversations.

• Noise cancellation for calls is automatically active during phone calls.
• This feature focuses on enhancing voice clarity during calls by filtering environmental sounds.

Image: Diagram illustrating the DN Noise Canceling Technology 2.0, showing sound waves being filtered for clearer audio.

Maintenance

Cleaning

• Regularly clean the earbuds and charging case with a soft, dry, lint-free cloth.
• Do not use abrasive cleaners, alcohol, or chemical solvents.
• Ensure charging contacts on both earbuds and case are clean and free of debris to maintain proper charging.

Storage

• When not in use, store the earbuds in their charging case to protect them and keep them charged.
• Store in a cool, dry place, away from extreme temperatures and direct sunlight.

Troubleshooting

• Earbuds not pairing: Ensure both earbuds are charged. Place them back in the case, close the lid, then open it again to re-enter pairing mode. Check your device's Bluetooth settings and try reconnecting.
• Only one earbud working: Place both earbuds back into the charging case, close the lid, and then open it again. This often resets the connection between the two earbuds. Ensure both are charged.
• No sound: Check the volume level on your connected device and on the earbuds. Ensure the earbuds are properly paired and connected. Try restarting your device.
• Charging issues: Ensure the charging cable is securely connected to both the case and the power source. Clean the charging contacts on the earbuds and inside the case. Try a different USB port or charging cable.
• Poor sound quality: Ensure the earbuds are properly seated in your ears. Check for any obstructions in the earbud nozzles. Move closer to your connected device to avoid interference.

Specifications

Image: Infographic detailing key features including 360˚ spatial sound, ACA Acoustic Chamber 5.0, 40H battery life, Patented Bluetooth Flash 6.0, 5.6g lightweight, and compact design.

Image: Infographic highlighting the 40-hour long battery life, with details on 5 hours single battery life, 40 hours with charging compartment, and 180 days standby time.

Warranty and Support

Warranty Information

The SANAG T11 Wireless Earbuds come with a 6-month warranty from the date of purchase. This warranty covers manufacturing defects and workmanship under normal use. It does not cover damage caused by misuse, accidents, unauthorized modifications, or normal wear and tear.

Customer Support

For any questions, troubleshooting assistance, or warranty claims, please contact your retailer or the SANAG customer support channel where you purchased the product.
