GHB Baby Monitor with Camera (Model GB5200) User Manual

1. Introduction

Thank you for purchasing the GHB Baby Monitor with Camera. This device is designed to provide a secure and reliable way to monitor your baby, offering high-definition video, two-way audio, and various features for peace of mind. Please read this manual carefully before using the product to ensure proper operation and safety.

Figure 1.1: GHB Baby Monitor system, showing the parent unit with a 5-inch HD screen displaying a baby, and the camera unit.

2. Package Contents

Please check the package contents upon unboxing:

• Parent Unit (Monitor)
• Baby Unit (Camera)
• Power Adapters (x2)
• Wall Mount Bracket with adjustable angle
• User Manual

3. Important Safety Information

• Keep the product out of reach of children.
• Do not place the camera or cords within 1 meter of the crib.
• Use only the provided power adapters.
• Do not expose the product to water or moisture.
• Ensure proper ventilation for both units.
• This product is not a substitute for responsible adult supervision.

4. Product Overview

4.1 Parent Unit (Monitor)

• 5-inch HD display (1080P resolution)
• Built-in 4000 mAh battery
• Microphone for two-way talk
• Speaker
• Control buttons (Menu, OK, Navigation, VOX, Talk, Zoom)
• Antenna

4.2 Baby Unit (Camera)

• 1080P HD Camera lens
• Infrared LEDs for night vision
• Microphone
• Speaker
• Temperature sensor
• Pairing button
• Power input
• 1/4 inch screw hole for mounting

Figure 4.1: Overview of GHB Baby Monitor features including 5-inch HD screen, 4000 mAh battery, VOX mode, two-way communication, FHSS connection, night vision, 4x zoom, temperature display, signal loss alert, low power function, battery alert, alarm setting, 4 camera connection, lullaby playback, and pan/tilt rotation.

5. Setup

5.1 Charging the Parent Unit

1. Connect the power adapter to the parent unit and a power outlet.
2. Charge the unit for at least 4 hours before first use. The battery icon on the screen will indicate charging status.

5.2 Powering the Baby Unit (Camera)

1. Connect the power adapter to the baby unit and a power outlet.
2. The baby unit does not have a built-in battery and must be continuously connected to power.

Figure 5.1: The GHB baby camera unit shown with its 1/4 inch screw hole for versatile mounting options, including a wall-mounted bracket. The image emphasizes that the camera requires continuous power connection.

5.3 Positioning the Baby Unit (Camera)

• Place the baby unit on a flat surface or mount it to a wall using the provided bracket.
• Ensure the camera is at least 1 meter away from the baby's crib to prevent entanglement hazards from the power cord.
• Adjust the camera angle to get the best view of your baby. The camera offers 350° rotation and 110° wide-angle view.

5.4 Pairing (If necessary)

The units are pre-paired at the factory. If pairing is lost or you are adding additional cameras (up to 4 cameras supported):

1. Turn on both the parent unit and the baby unit.
2. On the parent unit, navigate to the "Camera" menu.
3. Select "Add Camera" and follow the on-screen instructions.
4. Press the pairing button on the back of the baby unit within 10 seconds.
5. A successful connection will be indicated on the parent unit screen.

Figure 5.2: The GHB Baby Monitor system demonstrating the ability to connect up to 4 cameras simultaneously, displaying views from different rooms on the parent unit. It highlights the use of FHSS technology, no Wi-Fi, and no app requirement.

6. Operating Instructions

6.1 Power On/Off

• Parent Unit: Press and hold the Power button for 3 seconds.
• Baby Unit: Connect to power to turn on. Disconnect from power to turn off.

6.2 Screen Display and Navigation

The 5-inch HD screen displays live video from the camera. Use the navigation buttons (Up, Down, Left, Right) and OK button to navigate menus and adjust settings.

6.3 VOX Mode (Voice Operated Exchange)

The VOX mode conserves battery by turning off the screen when no sound is detected. The screen will automatically turn on when sound is detected from the baby's room.

• Press the VOX button on the parent unit to activate/deactivate VOX mode.
• Adjust VOX sensitivity (Low, Mid, High, Highest) in the menu settings.

Figure 6.1: The GHB Baby Monitor parent unit displaying the VOX mode settings (Low, Mid, High, Highest) and indicating extended battery life of 7x24 hours in VOX energy-saving mode. A baby is shown sleeping in the background.

Figure 6.2: Illustration of the GHB Baby Monitor's VOX Economic Mode. When the environment is quiet, the screen automatically turns off to save energy. When sound is detected, the screen turns on, showing the baby. This mode does not detect movement.

6.4 Two-Way Talk

To speak to your baby:

1. Press and hold the Talk button (microphone icon) on the parent unit.
2. Speak clearly into the microphone on the parent unit.
3. Release the button to hear your baby again.

Figure 6.3: The GHB Baby Monitor demonstrating its clear two-way talk function with low background noise. An adult is shown speaking into the parent unit, and a baby is shown responding from the camera's location.

6.5 Zoom Function

The parent unit supports 2x and 4x digital zoom.

• Press the Zoom button (magnifying glass icon) to cycle through 1x, 2x, and 4x zoom levels.

Figure 6.4: The GHB Baby Monitor parent unit showcasing its 2x and 4x digital zoom capabilities, allowing for closer observation of the baby.

6.6 Night Vision

The baby unit automatically activates infrared night vision in low-light conditions, providing a clear black and white image of your baby.

Figure 6.5: Comparison of GHB 1080P HD Night Vision with other 720P monitors, demonstrating superior clarity. Icons indicate features like low background noise, VOX, lullabies, and temperature alerts.

6.7 Lullabies and Temperature Monitoring

The monitor includes built-in lullabies and a temperature sensor in the baby unit.

• Access the menu to select and play lullabies.
• The current room temperature is displayed on the parent unit screen. You can set temperature alerts in the settings.

Figure 6.6: The GHB Baby Monitor camera unit positioned near a sleeping baby, illustrating its lullaby playback and temperature detection features. The parent unit displays the temperature and sound level.

7. Maintenance

• Clean the units with a dry, soft cloth. Do not use abrasive cleaners or solvents.
• Ensure the camera lens is clean for optimal image quality.
• Keep ventilation openings free from dust and debris.
• Store the monitor in a dry place when not in use.

8. Troubleshooting

9. Specifications

• Model: GB5200
• Screen Size: 5 Inch HD
• Camera Resolution: 1080P
• Battery (Parent Unit): 4000 mAh Lithium Ion
• VOX Mode Battery Life: Up to 7 x 24 hours
• Display Mode Battery Life: Approximately 10 hours
• Wireless Technology: 2.4GHz FHSS
• Number of Channels: 4
• Zoom: 2x, 4x Digital Zoom
• Night Vision: HD Infrared
• Two-Way Talk: Yes
• Temperature Sensor: Yes
• Lullabies: Yes
• Camera Rotation: 350° Pan, 110° Tilt (Wide Angle)
• Mounting Type: Wall Mount
• Product Dimensions: 24 x 17 x 11 cm
• Item Weight: 950 g

10. Warranty and Support

GHB products are designed and manufactured to the highest quality standards. For warranty information, technical support, or customer service, please refer to the warranty card included in your package or visit the official GHB website. Please retain your proof of purchase for warranty claims.

For further assistance, you may contact GHB customer support via their official website: GHB Official Store
