Beldray 15-in-1 Steam Cleaner Instruction Manual

1. Important Safety Information

Please read all instructions carefully before using the Beldray 15-in-1 Steam Cleaner. Retain this manual for future reference.

• Always ensure the appliance is unplugged from the mains supply before filling or emptying the water tank, or when not in use.
• Do not direct steam at people, animals, or electrical appliances. Steam is hot and can cause burns.
• Do not immerse the appliance in water or any other liquid.
• Keep the appliance out of reach of children and pets.
• Use only distilled or demineralized water to prevent mineral buildup and prolong the life of the appliance.
• Do not overfill the water tank.
• Ensure all attachments are securely fitted before use.
• Do not use the steam cleaner on unsealed wooden floors, delicate fabrics, or surfaces that may be damaged by heat or moisture.

2. Product Overview and Components

The Beldray 15-in-1 Steam Cleaner is a versatile cleaning tool designed for various household tasks. It can be used as an upright steam mop or a handheld steamer.

Image: The Beldray 15-in-1 Steam Cleaner in its upright configuration, with a detachable handheld unit. Features like 'Ready in 20 seconds' and 'Refill instantly' are visible. Various accessories are shown around the unit.

Main Unit Features:

• Water Tank: 550 ml capacity.
• Power: 1350 Watts.
• Heat-up Time: Approximately 20 seconds.
• Continuous Steam: Up to 16 minutes per fill.
• Form Factor: Portable, convertible between upright and handheld.

Included Components and Accessories:

Image: An infographic detailing six different attachments: Upholstery & Garment Steamer, Cleanse & Freshen Carpets, General Nozzle, Angled Nozzle, Round Brush, and Window & Mirror Cleaner, with descriptions of their functions.

• Extension hose
• Floor mop head with 2 mop pads
• General nozzle
• Angled nozzle
• Round brush
• Window cleaning tool
• Upholstery/garment steamer tool
• Carpet glider

3. Setup Instructions

3.1 Unpacking

1. Carefully remove all components from the packaging.
2. Check that all listed accessories are present and undamaged.
3. Dispose of packaging materials responsibly.

3.2 Filling the Water Tank

1. Ensure the steam cleaner is unplugged from the power outlet.
2. Locate the water tank cap on the handheld unit. Unscrew and remove it.
3. Using a measuring cup or funnel, carefully fill the water tank with up to 550 ml of distilled or demineralized water. Do not use tap water to avoid mineral buildup.
4. Do not overfill. Replace the water tank cap securely.

3.3 Assembling for Use

The steam cleaner can be assembled as an upright mop or used as a handheld unit with various attachments.

For Upright Steam Mop Use:

1. Attach the extension pole to the handheld unit until it clicks into place.
2. Attach the floor mop head to the bottom of the extension pole.
3. Secure a mop pad to the floor mop head.

Image: The Beldray 15-in-1 Steam Cleaner fully assembled as an upright steam mop, ready for floor cleaning.

For Handheld Use with Attachments:

1. Detach the extension pole if it is connected.
2. Select the desired accessory (e.g., general nozzle, round brush, window tool, upholstery tool).
3. Attach the accessory directly to the handheld unit or to the extension hose, then attach the hose to the handheld unit. Ensure a secure fit.

4. Operating Instructions

4.1 Initial Use and Heating

1. Ensure the water tank is filled and the desired attachment is securely in place.
2. Plug the power cord into a suitable mains outlet. The indicator light will illuminate.
3. The steam cleaner will heat up in approximately 20 seconds. The indicator light may change or turn off when ready, depending on the model.
4. Once heated, press and hold the steam trigger to release steam. Release the trigger to stop steaming.

4.2 Using Different Attachments

The Beldray 15-in-1 Steam Cleaner offers versatile cleaning for various surfaces:

• Floor Mop (with mop pad): Ideal for hard floors (sealed surfaces only) and refreshing carpets with the carpet glider. Move the mop slowly over the surface to allow steam to penetrate.


  Image: The steam mop attachment being used to clean a grey carpet, showing steam being released.

• General Nozzle: For concentrated steam cleaning on stubborn dirt, grout, and hard-to-reach areas.


  Image: A handheld steam cleaner with a pointed nozzle directing steam onto tile grout.

• Round Brush: Use with the general nozzle for scrubbing tough stains on surfaces like stovetops, sinks, and bathroom fixtures.


  Image: A handheld steam cleaner with a small brush attachment cleaning around a burner on a stainless steel gas stovetop.

• Angled Nozzle: Designed for reaching awkward corners and tight spaces, such as toilet rims or behind taps.
• Window Cleaning Tool: For streak-free cleaning of windows, mirrors, and shower screens. Use a squeegee motion.
• Upholstery/Garment Steamer Tool: To refresh fabrics, remove wrinkles from clothes, and eliminate odors from upholstery. Hold a short distance from the fabric.


  Image: A handheld steam cleaner with an upholstery attachment being used to clean a light grey sofa.

• Extension Hose: Provides extended reach for handheld cleaning, useful for high areas or inside cabinets.


  Image: A handheld steam cleaner connected to an extension hose, which is being used to clean a high corner of a white cabinet.

• Pet Bed Cleaning: The handheld unit can be used with appropriate attachments to sanitize and refresh pet beds.


  Image: A handheld steam cleaner being used to clean a brown and beige pet bed on a wooden floor.

4.3 Refilling During Use

If the water tank runs empty during use, the steam output will cease.

1. Unplug the appliance from the mains power.
2. Allow the unit to cool for a few minutes before attempting to refill.
3. Carefully unscrew the water tank cap and refill with distilled or demineralized water as described in Section 3.2.
4. Replace the cap, plug the appliance back in, and wait for it to reheat (approx. 20 seconds) before resuming use.

5. Maintenance

5.1 Cleaning the Appliance

1. Always unplug the steam cleaner and allow it to cool completely before cleaning.
2. Wipe the exterior of the unit with a soft, damp cloth. Do not use abrasive cleaners or solvents.
3. Remove and wash mop pads after each use. They are typically machine washable.
4. Clean accessories as needed with water and mild soap, ensuring they are dry before storage.

5.2 Descaling

To maintain optimal performance and prevent mineral buildup, especially if using hard water (though distilled water is recommended), periodic descaling may be necessary.

• Mix a solution of equal parts white vinegar and water.
• Pour the solution into the water tank (do not exceed max fill line).
• Allow the solution to sit in the tank for 30 minutes to an hour.
• Empty the tank and rinse thoroughly with clean water several times.
• Run a tank of clean distilled water through the unit to flush out any remaining vinegar.

5.3 Storage

Store the steam cleaner in a cool, dry place, away from direct sunlight and out of reach of children.

6. Troubleshooting

If you encounter issues with your steam cleaner, refer to the following common problems and solutions:

7. Specifications

• Model Number: BEL01987VDE
• Brand: Beldray
• Power: 1350 Watts
• Water Tank Capacity: 550 Millilitres
• Product Dimensions (L x W x H): 26.6 x 15 x 26.5 cm
• Item Weight: 2.45 Kilograms
• Material: Aluminium
• Color: Grey
• Special Feature: 15-in-1 versatile cleaning and numerous accessories
• Recommended Surface: Hard floors, carpets, surfaces, mirrors, showers, garments, furniture
• Components Included: Brushes, nozzles, hoses, window accessories, mop pads
• Country of Origin: China

8. Warranty and Support

For warranty information, please refer to the documentation provided at the time of purchase or contact Beldray customer support directly.

Spare parts availability information is currently unavailable through general product specifications. For specific spare parts inquiries or technical support, please contact the manufacturer or your retailer.
