Introduction
This manual provides essential instructions for the safe and efficient operation, installation, and maintenance of your Kolice Commercial 10-Tray Blast Chiller & Freezer, Model KDF-E10B2. Please read this manual thoroughly before using the appliance and retain it for future reference.
Image: Front view of the Kolice Commercial 10-Tray Blast Chiller & Freezer with its door open, revealing the interior fans and tray racks.
Safety Information
Always follow basic safety precautions when using this appliance to reduce the risk of fire, electric shock, or injury.
- Ensure the appliance is properly grounded.
- Do not operate with a damaged power cord or plug.
- Keep ventilation openings clear of obstructions.
- Only qualified personnel should perform repairs.
- Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
Setup and Installation
1. Unpacking
Carefully remove the unit from its plywood case packaging. Inspect the appliance for any shipping damage. Report any damage immediately to your supplier.
2. Placement
- Place the unit on a flat, stable surface.
- Ensure adequate ventilation around the unit. Maintain at least 6 inches (15 cm) of clearance from walls or other obstructions on all sides, especially where air vents are located.
- Avoid direct sunlight or heat sources.
Image: Diagram illustrating the thick foam insulation layer and internal fan system for efficient cooling and energy saving.
3. Power Connection
Connect the appliance to a dedicated 110V, 60Hz power outlet. The unit requires 1450W. Ensure the power cord (approximately 78 inches long) is not pinched or damaged.
4. Initial Cleaning
Before first use, clean the interior and exterior surfaces with a mild detergent and warm water. Rinse thoroughly and dry completely.
5. Tray Installation
The unit comes with 10 adjustable stainless steel trays. Insert the trays into the designated racks. Each tray measures 23.62" x 15.75" x 1.10" (60x40x2.8cm).
Image: Close-up of the intelligent touch panel and the interior showing adjustable stainless steel trays.
Operating Instructions
1. Control Panel (EVCO Smart AI Controller)
The unit features an EVCO smart AI temperature controller with a user-friendly interface. Multiple languages, including English and Chinese, are available for selection.
- Temperature Setting: Adjust the desired temperature within the range of -40°C to +5°C (-40°F to +41°F).
- Operating Modes: Select between chilling and shock freezing modes.
- Timer Control: Utilize the timer function for precise operation cycles.
Image: Diagram showing internal components like the evaporator fan, probe, and intelligent control panel, alongside a chart explaining the blast chilling process and its benefits for food preservation.
2. Loading Food
Place food items evenly on the stainless steel trays. Avoid overloading to ensure optimal air circulation and efficient freezing. The unit is suitable for various items including frozen dough, seafood, meat, cake, dumplings, and ice cream.
Image: Collage showing various food items such as meat, dumplings, seafood, ice cream, frozen food, and dough, illustrating the versatility of the blast chiller.
3. Using the Food Probe
The appliance is equipped with a food probe to accurately detect the core temperature of food. Insert the probe into the thickest part of the food item to monitor its temperature during the chilling or freezing process.
4. Chilling and Freezing Times
- Fresh food can be frozen within 1-2 hours.
- Hot food can be frozen within 3-4 hours.
- The lowest temperature achievable is -40°C (-40°F).
5. Video Demonstration
Watch this video for a visual guide on the operation of the Kolice Commercial Blast Chiller.
Video: A demonstration of the Kolice Commercial Blast Chiller in operation, showcasing its internal fans and rapid cooling capabilities.
Maintenance
1. Automatic Defrost and Drainage
The unit features automatic defrost and drainage functions, minimizing manual intervention. Ensure the drainage system is not blocked.
2. Cleaning
- Regularly clean the interior and exterior surfaces with a soft cloth and mild, non-abrasive cleaner.
- The "clean reminding function" on the control panel will alert you when cleaning is recommended.
- Ensure the magnetic door seal is clean and free of debris to maintain an airtight closure.
- The food-grade 304 stainless steel construction is designed for easy cleaning and durability.
Image: Illustration of the 360-degree cooling air convection system and the durable, corrosion-resistant food-grade stainless steel material used in the appliance.
Troubleshooting
Refer to the following table for common issues and their solutions. For problems not listed or persistent issues, contact customer support.
| Problem | Possible Cause | Solution |
|---|---|---|
| Appliance not turning on | No power supply; power cord disconnected. | Check power connection; ensure outlet is functional. |
| Temperature not reaching desired level | Door not sealed; overloaded; poor ventilation; compressor issue. | Check door seal; reduce load; ensure proper ventilation; contact support if compressor suspected. |
| HACCP Alarm activated | Temperature deviation outside safe limits. | Review temperature settings and food load; ensure door is closed properly. |
| Door-opening alarm | Door left ajar. | Close the door firmly. Check magnetic seal for obstructions. |
| Overload Protection activated | Electrical overload. | Reduce load on circuit; consult an electrician if persistent. |
Specifications
| Feature | Detail |
|---|---|
| Model Number | KDF-E10B2 |
| Product Dimensions (D x W x H) | 34.25" x 31.5" x 62.6" (87cm x 80cm x 159cm) |
| Net Weight | 220 lbs (100 kg) |
| Net Volume | 250 Liters |
| Voltage | 110V |
| Frequency | 60Hz |
| Wattage | 1450W |
| Temperature Range | -40°C to +5°C (-40°F to +41°F) |
| Material | Food Grade 304 Stainless Steel |
| Insulation | 3 inches thick soft foam |
| Trays | 10 adjustable stainless steel trays |
| Tray Dimensions | 23.62" x 15.75" x 1.10" (60x40x2.8cm) |
| Compressor | French brand quality |
| Controller | EVCO Smart AI Temperature Controller |
| Included Components | Compressor, Fan |
| Certification | ISO 9001 |
Warranty and Support
Warranty
This Kolice Commercial Blast Chiller & Freezer comes with a 1-year warranty for parts. Please retain your proof of purchase for warranty claims.
Customer Support
For technical assistance, troubleshooting, or warranty inquiries, please contact Kolice customer support. You can find more information and contact details on the official Kolice store page: Visit the Kolice Store.
