GENDOME Portable Solar Panel 36W User Manual

Model: Solar 36

Introduction

The GENDOME Portable Solar Panel 36W is designed to provide efficient and reliable power for your USB-C powered devices. With a high conversion rate and durable construction, it is suitable for various outdoor and portable charging needs.

Key Features:

  • High Efficiency Panel Conversion Rate: Up to 23% solar power conversion.
  • Versatile Charging: Equipped with a USB port (5V/2.4A Max) and an attached USB-C cable.
  • Durable Construction: IP68 Waterproof rating and ETFE insulated astigmatism for high temperature use and anti-corrosion.
  • Wide Compatibility: Works with most USB-C powered devices including cell phones, tablets, power banks, earbuds, games, and cameras.

Setup Instructions

  1. Unfold the Solar Panel: Carefully unfold the GENDOME Portable Solar Panel 36W to its full extent. Ensure all panels are flat and exposed to direct sunlight.
  2. Position for Optimal Sunlight: Place the solar panel in an area with direct, unobstructed sunlight. Angle the panel towards the sun for maximum efficiency. Avoid shaded areas.
  3. Connect Your Device:
    • For USB-C devices: Use the attached USB-C cable to connect your device directly to the solar panel.
    • For USB-A devices: Use the integrated USB-A port (5V/2.4A Max) to connect your device with its compatible USB cable.
  4. Secure the Panel (Optional): Use the included carabiners to secure the solar panel to a backpack, tent, or other stable surface, especially in windy conditions.
Gendome Portable Solar Panel 36W unfolded, showing its solar cells and USB-C cable.

Image: The Gendome Portable Solar Panel 36W fully unfolded, ready for use. This shows the multiple solar cell segments and the integrated USB-C cable for device connection.

Operating Instructions

Once properly set up and connected, the GENDOME Portable Solar Panel 36W will begin charging your device automatically when sufficient sunlight is available. The panel is designed for high efficiency, converting up to 23% of solar power.

  • Charging Indicator: Some devices may have a charging indicator. Refer to your device's manual for details. The solar panel itself does not have an indicator light.
  • Optimal Performance: For best charging speeds, ensure the panel is directly facing the sun and not obstructed by clouds, trees, or other objects.
  • Intermittent Charging: Charging may be intermittent in cloudy conditions or when the panel is not optimally positioned. This is normal for solar charging.
  • Device Compatibility: The panel is compatible with most USB-C powered devices and USB-A devices requiring up to 5V/2.4A.

Maintenance

To ensure the longevity and optimal performance of your GENDOME Portable Solar Panel 36W, follow these maintenance guidelines:

  • Cleaning: The ETFE insulated astigmatism material makes the panels easy to clean. Use a soft, damp cloth to wipe away dust, dirt, or debris from the solar cell surfaces. Avoid abrasive cleaners or harsh chemicals.
  • Storage: When not in use, fold the solar panel and store it in a cool, dry place away from direct sunlight and extreme temperatures.
  • Water Resistance: The panel has an IP68 waterproof rating, meaning it is protected against continuous immersion in water. However, it is recommended to dry the panel and its ports thoroughly after exposure to water to prevent corrosion or damage to connected devices.
Close-up of the Gendome Portable Solar Panel 36W partially submerged in water, with 'IP68 WATERPROOF' text visible on the panel surface.

Image: A close-up view of the Gendome Portable Solar Panel 36W demonstrating its IP68 waterproof rating, partially submerged in water.

Troubleshooting

Problem Possible Cause Solution
Device not charging or charging slowly.
  • Insufficient sunlight.
  • Panel not optimally angled.
  • Panel surface is dirty.
  • Faulty connection cable.
  • Device not compatible or requires more power.
  • Relocate the panel to direct sunlight.
  • Adjust the panel's angle towards the sun.
  • Clean the panel surface with a damp cloth.
  • Try a different, known-good charging cable.
  • Ensure your device's power requirements are within the panel's output (5V/2.4A Max).
Intermittent charging.
  • Passing clouds or partial shading.
  • Movement of the panel or sun.
  • This is normal for solar charging. Try to maintain consistent direct sunlight.
  • Re-position the panel periodically to track the sun's movement.

Specifications

Feature Detail
Brand GENDOME
Model Number Solar 36
Maximum Power 36 Watts
Efficiency Up to 23% Conversion Rate
Connector Type USB-A (5V/2.4A Max), Integrated USB-C cable
Amperage Capacity 3 Amps
Material ETFE, Aluminum
Product Dimensions (L x W x H) 11"L x 1.2"W x 7.79"H (folded)
Item Weight 1.8 Pounds
Waterproof Rating IP68
Included Components 1 USB-A connector, 2x Carabiners, 36W Solar Panel, User Manual
UPC 850048037298

Warranty Information

Specific warranty details for the GENDOME Portable Solar Panel 36W are not provided in this manual. Please refer to the product packaging, the official GENDOME website, or your purchase documentation for comprehensive warranty terms and conditions.

Customer Support

For technical assistance, product inquiries, or support, please contact GENDOME customer service. Contact information is typically available on the product packaging or the official GENDOME website.

Please have your product model number (Solar 36) and UPC (850048037298) ready when contacting support.
