Invicta Pro Diver Men's 43mm VD53 Quartz Watch Model 48383 User Manual

Introduction

This manual provides essential instructions for the proper setup, operation, and maintenance of your Invicta Pro Diver Men's 43mm VD53 Quartz Watch, Model 48383. Please read this manual thoroughly to ensure optimal performance and longevity of your timepiece.

Product Overview

The Invicta Pro Diver Model 48383 is a robust 43mm stainless steel quartz watch featuring a gold-tone finish and a gold dial. It is equipped with a VD53 quartz movement, offering precise timekeeping and chronograph functionality.

Image 1: Front view of the Invicta Pro Diver Model 48383 watch, showcasing the gold-tone case, green bezel, gold dial with three sub-dials, and gold-tone bracelet.

Image 2: Angled view of the Invicta Pro Diver Model 48383 watch, displayed on a watch stand. This perspective highlights the watch's profile, the texture of the gold-tone bracelet, and the details of the crown and pushers.

Key Components:

• Crown: Used for setting time and date.
• Pushers: Operate the chronograph functions.
• Bezel: Unidirectional rotating bezel for elapsed time measurement.
• Dial: Gold-colored dial with luminous hands and markers.
• Sub-dials: Chronograph minute, second, and 24-hour indicators.
• Date Window: Displays the current date.

Setup

Setting the Time:

1. Pull the crown out to the second click position.
2. Rotate the crown to move the hour and minute hands to the desired time.
3. Push the crown back into the normal position to start the watch.

Setting the Date:

1. Pull the crown out to the first click position.
2. Rotate the crown to adjust the date. Avoid setting the date between 9 PM and 3 AM, as this can interfere with the date change mechanism.
3. Push the crown back into the normal position.

Bracelet Adjustment:

For proper fit, the watch bracelet may need adjustment. This typically involves removing or adding links. It is recommended to have this procedure performed by a qualified watch technician to prevent damage to the bracelet or watch.

Operating the Chronograph

The VD53 quartz movement includes a chronograph function for measuring elapsed time.

1. Start: Press the upper pusher to start the chronograph. The chronograph second hand will begin to move.
2. Stop: Press the upper pusher again to stop the chronograph. The elapsed time will be indicated by the chronograph hands.
3. Reset: After stopping, press the lower pusher to reset the chronograph hands to their zero positions.

Note: Ensure the crown is fully pushed in before operating the pushers, especially near water, to maintain water resistance.

Water Resistance

Your Invicta Pro Diver Model 48383 watch is water resistant to 100 meters (330 feet).

• This rating makes the watch suitable for recreational surfing, swimming, snorkeling, sailing, and other water sports.
• It is not suitable for diving.
• To maintain water resistance, ensure the crown is always fully pushed in. Do not operate the crown or pushers while the watch is wet or submerged in water.
• Exposure to hot water (e.g., showers, hot tubs) can compromise water resistance over time due to thermal expansion and contraction of seals.

Maintenance

Cleaning:

Regularly clean your watch with a soft, damp cloth. For the stainless steel case and bracelet, a mild soap solution can be used, followed by thorough rinsing with clean water and drying. Avoid harsh chemicals or abrasive materials.

Battery Replacement:

As a quartz watch, the Model 48383 is powered by a battery. When the battery runs low, the watch may stop or the second hand might skip intervals. Battery replacement should be performed by a qualified watch technician to ensure proper sealing and maintain water resistance.

Storage:

When not in use, store your watch in a dry, cool place away from direct sunlight, extreme temperatures, and strong magnetic fields. Keeping it in its original box or a watch case is recommended.

Troubleshooting

• Watch not running:

  Ensure the crown is fully pushed in. If the watch still does not run, the battery may need replacement. Consult a qualified watch technician.

• Date not changing at midnight:

  The watch may be set to PM instead of AM. Advance the time by 12 hours. If the issue persists, consult a technician.
• Chronograph hands not resetting to zero:

  This may require a chronograph reset procedure, which varies by movement. It is best handled by a qualified watch technician.

Specifications

Warranty and Support

Invicta watches typically come with a manufacturer's warranty covering defects in materials and workmanship. For specific warranty details, registration, or to initiate a service request, please refer to the warranty card included with your purchase or visit the official Invicta website.

For further assistance or inquiries, please contact Invicta customer support. Contact information can usually be found on the official Invicta website or in the documentation provided with your watch.
