VIFLYKOO TT202 Turntable Instruction Manual

1. Introduction

Thank you for purchasing the VIFLYKOO TT202 Turntable. This manual provides essential information for the safe and correct operation of your device. Please read it thoroughly before use and retain it for future reference.

2. Safety Instructions

• Read all instructions before operating the turntable.
• Keep the unit away from water, moisture, and direct sunlight.
• Do not place the unit near heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat.
• Use only attachments/accessories specified by the manufacturer.
• Unplug the unit during lightning storms or when unused for long periods.
• Refer all servicing to qualified service personnel.
• Ensure proper ventilation around the unit.

3. Package Contents

Verify that all items listed below are included in your package:

• VIFLYKOO TT202 Turntable Unit
• Power Adapter
• Instruction Manual

Figure 3.1: VIFLYKOO TT202 Turntable main unit.

4. Product Features

• Bluetooth 5.3 Connectivity: Supports both receiving and transmitting Bluetooth signals for versatile audio connections.
• Integrated Stereo Speakers: Two built-in 5W stereo speakers for direct audio playback.
• Multiple Playback Speeds: Compatible with 33-1/3, 45, and 78 RPM records (7, 10, and 12 inches).
• Auto-Stop Function: Automatically stops the platter at the end of a record to prevent stylus wear.
• Belt-Drive System: Features a belt-drive platter with anti-resonance design for stable and smooth playback.
• Vinyl to MP3 Recording: Convert your vinyl records into digital MP3 files.
• Connectivity Options: Headphone jack, AUX input, and RCA output for external audio devices.
• Removable Dust Cover: Transparent cover protects records and the turntable from dust.

5. Product Diagram

Familiarize yourself with the components of your VIFLYKOO TT202 Turntable.

Figure 5.1: Rear Panel Connections (DC 12V, RCA Output)

Figure 5.2: Built-in Stereo Speakers

Figure 5.3: Turntable Top View (Platter, Tonearm, Controls)

Figure 5.4: Stylus (Needle) Detail

6. Setup

6.1 Unpacking

Carefully remove the turntable from its packaging. Retain the packaging for future transport or storage. Remove any protective materials from the unit, including the stylus guard.

6.2 Power Connection

1. Connect the power adapter to the DC 12V input port on the rear of the turntable.
2. Plug the power adapter into a suitable wall outlet.

Figure 6.1: Power Input Location

6.3 Dust Cover Installation

The transparent dust cover can be easily attached or removed. Align the hinges on the dust cover with the slots on the turntable unit and gently push down until it clicks into place. To remove, gently pull upwards.

Figure 6.2: Dust Cover in place.

6.4 External Speaker Connection (Optional)

To connect external speakers, use an RCA cable (not included) to connect the RCA output ports on the rear of the turntable to the input ports on your external amplifier or powered speakers.

Figure 6.3: Connecting to External Speakers via RCA.

7. Operating Instructions

7.1 Playing a Vinyl Record

1. Place a vinyl record on the platter.
2. Select the appropriate speed (33-1/3, 45, or 78 RPM) using the speed selector switch.
3. If playing a 45 RPM record, place the 45 RPM adapter (if included) on the center spindle.
4. Lift the tonearm using the cueing lever.
5. Move the tonearm over the desired track of the record.
6. Gently lower the tonearm using the cueing lever. The record will begin to play.
7. Adjust the volume using the volume knob.
8. The auto-stop function will stop the platter when the record finishes. To stop manually, lift the tonearm and return it to its rest.

Figure 7.1: Speed Selection for Records.

Figure 7.2: Compatible Record Sizes.

7.2 Bluetooth Operation (Receiving)

The turntable can receive audio wirelessly from your Bluetooth-enabled devices.

1. Turn on the turntable.
2. Switch the function mode to Bluetooth (BT) if available, or ensure it's in a discoverable state.
3. On your smartphone or other Bluetooth device, enable Bluetooth and search for available devices.
4. Select "TT202" (or similar name) from the list to pair.
5. Once paired, you can stream audio from your device to the turntable's built-in speakers.

Figure 7.3: Bluetooth Pairing Example.

7.3 Bluetooth Operation (Transmitting)

The turntable can also transmit audio to external Bluetooth headphones or speakers.

1. Ensure your Bluetooth headphones or speaker are in pairing mode.
2. Start playing a record on the turntable.
3. The turntable will automatically search for and connect to nearby Bluetooth audio devices.
4. Once connected, audio will be transmitted to your external Bluetooth device.

7.4 Vinyl to MP3 Recording

This feature allows you to convert your vinyl records into digital MP3 files. Refer to the specific instructions in the full manual for detailed steps on connecting a USB drive and initiating recording.

7.5 AUX Input

Connect external audio sources (e.g., smartphone, MP3 player) to the turntable using an AUX cable (not included) plugged into the AUX input jack. Switch the turntable to AUX mode to play audio through its speakers.

7.6 Headphone Output

For private listening, plug your headphones into the headphone jack on the turntable. This will mute the built-in speakers.

8. Maintenance

8.1 Cleaning the Stylus

A dirty stylus can affect sound quality and damage records. Use a soft brush (not included) to gently clean the stylus from back to front. Do not use excessive force or harsh chemicals.

Figure 8.1: Stylus for cleaning reference.

8.2 Cleaning the Turntable Unit

Wipe the turntable's surface with a soft, dry, lint-free cloth. For stubborn marks, slightly dampen the cloth with water. Avoid abrasive cleaners or solvents.

8.3 Dust Cover Care

Clean the dust cover with a soft, damp cloth. Avoid using harsh chemicals that could scratch or cloud the plastic.

9. Troubleshooting

10. Specifications

11. Warranty and Support

Warranty information for this product is not explicitly detailed in the provided product data. For specific warranty terms and conditions, please refer to the documentation included with your purchase or contact VIFLYKOO customer support directly.

For technical support or inquiries, please visit the official VIFLYKOO website or contact their customer service department.
