AFI Tucson Queen Wood Murphy Bed Chest AC76414T User Manual

Introduction

This manual provides instructions for the assembly, operation, and maintenance of your AFI Tucson Queen Wood Murphy Bed Chest. This versatile furniture piece is designed to offer a space-saving bed solution that converts into a chest, complete with a storage drawer and a built-in USB charging station.

Please read these instructions thoroughly before beginning assembly or operation to ensure safe and proper use of the product. Keep this manual for future reference.

AFI Tucson Murphy Bed Chest in Light Toffee, shown open as a bed in a bedroom setting. — Figure 1: AFI Tucson Queen Wood Murphy Bed Chest in Light Toffee, shown in its open bed configuration within a bedroom setting.

Safety Information

WARNING: Failure to follow these safety instructions could result in injury or product damage.

Ensure all components are securely fastened before use. Regularly check and tighten all connections.
Do not allow children to play on or around the Murphy bed chest without adult supervision.
Do not exceed the maximum weight capacity of 800 lbs (362 kg).
Keep hands and fingers clear of moving parts during conversion to prevent pinching or injury.
Place the unit on a level, stable surface.
Only use the included 6-inch mattress or a mattress of equivalent size and weight designed for this unit.
Do not attempt to modify the product. Any modifications may void the warranty and create safety hazards.
For California residents: This product may expose you to chemicals known to the State of California to cause cancer or birth defects or other reproductive harm.

Package Contents

Verify that all parts are present before beginning assembly. Refer to the separate assembly instructions provided with your product for a detailed list of components and hardware.

Murphy Bed Chest Frame (Light Toffee, Queen Size)
6-inch Fold-A-Way Memory Foam Mattress
Storage Drawer
Built-in USB Charging Station (integrated)
Assembly Hardware Kit

Assembly Instructions

Assembly is required for this product. Detailed, step-by-step assembly instructions and diagrams are included in a separate manual within your product packaging. Please follow those instructions carefully.

General Assembly Tips:

Gather all tools required before starting.
Assemble on a soft, clean surface to prevent scratching.
Do not overtighten screws.
It is recommended to have two adults for assembly.

Dimensional drawing of the AFI Tucson Murphy Bed Chest, showing both closed and open configurations with measurements. — Figure 2: Product Dimensions. This image displays the overall dimensions of the Murphy bed chest in both its closed and open states, including the storage drawer measurements.

Operating Instructions

Converting from Chest to Bed

Clear the Area: Ensure there is sufficient clear space in front of the chest for the bed to extend fully.
Unlock Latches: Locate and release the safety latches on both sides of the top panel of the chest.
Open Top Panel: Gently lift the top panel of the chest. It will hinge upwards.
Pull Out Bed Frame: Grasp the handle on the front panel of the chest and pull it outwards. The bed frame will unfold and extend.
Lower Legs: As the bed frame extends, the support legs will automatically deploy. Ensure they are fully extended and locked into position.
Unfold Mattress: The included 6-inch memory foam mattress is tri-fold. Carefully unfold the mattress sections onto the bed frame.

AFI Tucson Murphy Bed Chest in Light Toffee, partially opened to reveal the bed frame. — Figure 3: Bed Frame Deployment. This image shows the initial stage of converting the chest into a bed, with the bed frame partially extended.

The AFI Tucson Murphy Bed Chest fully open with the included 6-inch mattress in place. — Figure 4: Bed Fully Extended. The Murphy bed chest is shown fully open with the mattress unfolded, ready for use.

Converting from Bed to Chest

Fold Mattress: Carefully fold the 6-inch memory foam mattress into its tri-fold configuration.
Lift Bed Frame: Grasp the front panel of the bed frame and lift it upwards. The support legs will retract automatically.
Push In Bed Frame: Guide the bed frame back into the chest cavity until it is fully recessed.
Close Top Panel: Lower the top panel of the chest until it sits flush.
Secure Latches: Engage the safety latches on both sides of the top panel to secure the chest in its closed position.

The AFI Tucson Murphy Bed Chest in Light Toffee, shown closed as a chest. — Figure 5: Chest in Closed Position. The Murphy bed chest is shown fully closed, appearing as a decorative chest.

Using the USB Charging Station

The Murphy Bed Chest includes a built-in power source with a 9-foot cord and two USB ports. To use:

Plug the power cord from the chest into a standard wall outlet.
Connect your USB-compatible devices to the USB ports for charging.

Close-up of the built-in USB charging station on the side of the AFI Tucson Murphy Bed Chest. — Figure 6: USB Charging Station. A detailed view of the integrated USB charging ports and power outlets.

Using the Storage Drawer

The chest features a spacious storage drawer for blankets, pillows, or other items. Simply pull the drawer handle to open and push to close.

The storage drawer of the AFI Tucson Murphy Bed Chest in Light Toffee, shown open. — Figure 7: Storage Drawer. The large storage drawer is shown pulled out, demonstrating its capacity.

Product Demonstration Video

Video 1: Tucson Murphy Bed Chest - AFI. This video demonstrates the conversion process of the Murphy bed chest from its closed chest form to an open bed, highlighting its features and ease of use.

Maintenance

Cleaning: Wipe the wood surfaces with a dry cloth. Avoid abrasive cleaners or harsh chemicals that may damage the finish.
Hardware: Periodically check all screws and bolts to ensure they remain tight. Retighten as necessary.
Mattress Care: Follow the care instructions provided with the 6-inch memory foam mattress.
USB Ports: Keep USB ports free of dust and debris.

Troubleshooting

Problem	Possible Cause	Solution
Bed does not open/close smoothly.	Obstruction in the mechanism or uneven surface.	Check for any objects blocking the movement. Ensure the unit is on a level surface.
USB charger not working.	Power cord not plugged in, or device issue.	Verify the power cord is securely plugged into a working outlet. Test with a different device or cable.
Drawer is stiff or misaligned.	Debris in drawer slides or loose hardware.	Clear any debris from the drawer slides. Check and tighten drawer slide screws.
Unit feels unstable.	Loose hardware or uneven floor.	Check and tighten all assembly hardware. Relocate the unit to a level surface or use shims if necessary.

If you encounter issues not listed here, please contact AFI customer support for assistance.

Specifications

Model: AC76414T
Brand: AFI
Color: Light Toffee
Size: Queen (U.S. Standard)
Material: Rubberwood, Wood
Assembled Dimensions (Closed): 22.83"L x 62.40"W x 40.75"H
Assembled Dimensions (Open): 79.29"L x 62.40"W x 40.75"H
Storage Drawer Dimensions: 18.74"L x 51.06"W x 4.88"H
Item Weight: 270.6 Pounds
Weight Capacity: 800 lbs
Special Features: Mattress Included, Built-in USB Charger (2 ports, 9-foot cord)
Assembly Required: Yes
Care Instructions: Wipe with Dry Cloth
GTIN/UPC: 782219864443

Warranty and Support

Manufacturer Warranty: Please refer to the product description or the AFI store page for detailed warranty information. Typically, AFI products come with a limited manufacturer's warranty covering defects in materials and workmanship.

Customer Support: For assistance with assembly, missing parts, or any other product-related inquiries, please contact AFI customer service. Contact information can usually be found on the AFI website or on the packaging materials.

You can visit the AFI Store on Amazon for more information.
