Graco TrueCoat 360 Cordless Connect Drill Paint Sprayer User Manual

Introduction

The Graco TrueCoat 360 Cordless Connect Drill Paint Sprayer is designed to transform your standard power drill into an efficient paint sprayer for small to medium-sized projects. This innovative attachment provides a smooth, even finish, reducing the need for traditional brushes and rollers. Its cordless design offers flexibility and ease of use for various DIY tasks around the home.

The Graco TrueCoat 360 Cordless Connect Drill Paint Sprayer, ready for use.

Important Safety Information

Always read and understand all safety warnings and instructions before operating this equipment.

• Always wear appropriate safety gear, including gloves and eye protection.
• Avoid inhaling paint fumes and ensure proper ventilation in your work area.
• Do not spray near open flames or sparks.
• Always follow the manufacturer's instructions for safe disposal of paint and materials.
• Always attach the drill securely and follow the manufacturer's guidelines for safe operation of power tools.

Product Overview

The TrueCoat 360 Cordless Connect is designed for versatility and ease of use. It features a vacuum suction feed system for minimal mess and consistent paint flow.

Key Features:

• Cordless Compatibility: Works with most standard drills (minimum 1,400 RPM), eliminating the need for hoses or power outlets.
• Vacuum Suction Feed System: Minimizes mess and ensures consistent paint delivery.
• Adjustable Spray Pattern: Provides flexibility for various project types.
• Flow Control Knob: Allows precise adjustment of paint application.
• Small Project Cup: Ideal for quick touch-ups, furniture, trim, and other small DIY tasks.

The sprayer is designed to finish small projects quickly and efficiently.

Suitable for a range of DIY projects including interior house painting, furniture, cabinets, doors, trim, and fences.

Compatible with 1/4" drill/drivers and 1/4" impact drivers, requiring a minimum of 1,400 RPM.

Tackle various projects with the included paint and stain tips, allowing spraying in any direction, even upside down, thanks to FlexLiner paint bags for easy cleanup.

Experience cordless freedom and the power to spray anywhere, compatible with cordless drill/driver and impact drills.

Spray in any direction with VacuValve technology for consistent coverage.

Setup

1. Attach to Drill: Securely attach the Graco TrueCoat 360 unit to your standard cordless drill. Ensure the drill chuck is tightened firmly around the sprayer's drive shaft.
2. Insert FlexLiner Bag: Place a new FlexLiner paint bag into the paint cup.
3. Fill with Material: Pour your desired paint or stain into the FlexLiner bag. Do not overfill.
4. Secure Lid: Attach the cup lid firmly to the paint cup, ensuring a tight seal.
5. Prime the Sprayer: Turn the Prime Knob to the 'Prime' position. Activate your drill to draw material into the sprayer until it flows smoothly without air bubbles.
6. Select Spray Tip: Choose the appropriate spray tip for your project (paint or stain) and install it.

Operating Instructions

1. Adjust Flow Control: Use the flow control knob to adjust the amount of material being sprayed. Start with a lower setting and increase as needed for desired coverage.
2. Test Spray: Before applying to your project, test the spray pattern on a piece of scrap material. Adjust the flow and pattern until you achieve an even, consistent spray.
3. Maintain Distance: Hold the sprayer approximately 6-12 inches from the surface, depending on the desired finish and material.
4. Even Strokes: Use smooth, overlapping strokes to ensure uniform coverage. Release the trigger at the end of each pass to avoid excessive buildup.
5. Spray in Any Direction: The VacuValve technology allows you to spray in any direction, including overhead or upside down, without losing prime.

Maintenance and Cleaning

Proper cleaning after each use is crucial for the longevity and performance of your sprayer.

1. Empty Excess Material: Remove any remaining paint or stain from the FlexLiner bag.
2. Flush System: Fill the FlexLiner bag with an appropriate cleaning solution (water for latex, mineral spirits for oil-based paints). Spray the solution through the unit until it runs clear.
3. Clean Components: Disassemble the spray tip, guard, and FlexLiner bag. Clean all parts thoroughly with the appropriate cleaning solution and a brush.
4. Lubricate: Apply a small amount of pump armor or lubricant to the pump section as recommended by Graco to prevent corrosion and ensure smooth operation.
5. Storage: Store the sprayer in a clean, dry place.

Troubleshooting

If you encounter issues with your Graco TrueCoat 360, refer to the following common solutions:

• Sprayer Not Priming: Ensure the FlexLiner bag is properly seated and free of air. Check that the prime knob is in the correct position. The material might be too thick; try thinning it according to paint manufacturer recommendations.
• Clogging: Clean the spray tip and filter thoroughly. Ensure paint is properly strained before use to remove any debris.
• Inconsistent Spray Pattern: Adjust the flow control knob. Ensure the spray tip is clean and not worn. Check for proper material consistency.
• Leaking: Verify all connections are tight, especially the cup lid and spray tip. Check for damaged O-rings or seals and replace if necessary.

For more detailed troubleshooting, consult the full owner's manual or contact Graco customer support.

Specifications

Warranty and Support

The Graco TrueCoat 360 Cordless Connect Drill Paint Sprayer comes with a 12-month manufacturer's warranty. For warranty claims, technical support, or replacement parts, please refer to the contact information provided in your product packaging or visit the official Graco website.

It is recommended to register your product upon purchase to facilitate any future support needs.
