1. Introduction
This manual provides detailed instructions for the installation, operation, and maintenance of your Godrej Smart Lock Catus Touch Plus and Catus Touch digital locks. Please read this manual thoroughly before installation and use to ensure proper functionality and safety. Keep this manual for future reference.
2. Product Overview
The Godrej Smart Lock Catus Touch series offers advanced security and convenience for your home. The Catus Touch Plus is designed for main doors, featuring four access modes, while the Catus Touch is suitable for internal doors with dual access modes.
Image 2.1: Godrej Smart Lock Catus Touch Plus and Catus Touch digital locks.
Image 2.2: Overview of Godrej Catus Touch Plus and Catus Touch features, highlighting access modes for main and internal doors.
Catus Touch Plus (for Main Doors)
- Biometric Access: 360° fingerprint recognition, supporting up to 99 registered fingerprints.
- PIN Code Access: Register up to 99 unique 4 to 9 digit PINs. Includes OTP feature via mobile app.
- RFID Card Access: Register up to 99 RFID cards for multiple users.
- Mechanical Key: Traditional key access for emergency override.
- Additional Features: Anti-prank alarm, adjustable spy code, low battery indication, wrong password indication, emergency Micro USB port, multi-level volume control, one-touch privacy key.
Image 2.3: Detailed features of the Godrej Catus Touch Plus for main doors.
Catus Touch (for Internal Doors)
- PIN Code Access: Secure 4 to 9 digit PIN access.
- Mechanical Key: Traditional key access for emergency override.
- Additional Features: Anti-prank alarm, adjustable spy code, low battery indication, wrong password indication, emergency Micro USB port, multi-level volume control, one-touch privacy key.
Image 2.4: Detailed features of the Godrej Catus Touch for internal doors.
Package Contents
Image 2.5: What's in the box for Catus Touch Plus (left) and Catus Touch (right), including lock bodies, screws, keys, RFID cards (for Plus), and cover plates.
Door Compatibility
These locks are suitable only for wooden doors and wooden door frames with a thickness of 35 mm to 65 mm. They are not suitable for metal doors, double doors, sliding doors, or grill gates.
Image 2.6: Catus Touch Plus door thickness compatibility (35-65mm door thickness, 60mm backset).
Image 2.7: Catus Touch door thickness compatibility (35-65mm door thickness, 50mm backset).
3. Installation
Proper installation is crucial for the optimal performance and security of your Godrej Smart Lock. It is recommended to watch the official installation video and follow the steps carefully.
Video 3.1: Official installation video for Godrej Catus Connect & Catus Touch Plus digital locks. This video demonstrates the step-by-step process for mounting the lock on a wooden door.
Installation Steps Overview:
- Handle Configuration: Adjust the door handle on both the outside and inside bodies according to your door's left-hand or right-hand setup using an Allen key.
- Making Cavities on the Door: Use the provided marker template to accurately mark points on the door. Punch the marked points and drill holes for the lock components, ensuring correct depth and diameter.
- Adding Mortise: Insert the mortise lock body into the prepared cavity on the door edge. Ensure the latch is rotated correctly based on the door's opening direction. Secure it with screws.
- Installing Outside Body: Insert the shank and split pin into the mortise. Connect the wiring and carefully align the outside body with the drilled holes, passing the wires through.
- Installing Inside Body: Connect the wiring from the outside body to the inside body. Secure the inside body to the door using anti-theft screws. Insert the AA batteries into the battery compartment.
- Installing the Striker Plate: Mark the striker plate grooves on the door frame using the lock body level. Create the necessary cavity for the striker box and install the striker box and plate, securing them with screws.
4. Setup and Programming
After installation, you need to program your lock with user credentials.
4.1 Fingerprint Registration (Catus Touch Plus Only)
- Access the programming menu (refer to the lock's on-screen prompts or voice guide).
- Select the fingerprint registration option.
- Place your finger on the sensor multiple times as instructed until registration is complete.
- Test the registered fingerprint to ensure it unlocks the door.
4.2 PIN Code Registration
- Enter the programming mode.
- Select the PIN code registration option.
- Enter your desired 4 to 9 digit PIN code, then re-enter to confirm.
- Test the new PIN code.
- For OTP generation, use the mobile application (Catus Touch Plus only).
4.3 RFID Card Registration (Catus Touch Plus Only)
- Enter the programming mode.
- Select the RFID card registration option.
- Present the RFID card to the designated sensor area on the lock.
- The lock will confirm successful registration.
- Test the registered RFID card.
5. Operating Instructions
To unlock the door using different access methods:
- Fingerprint: Place your registered finger on the fingerprint sensor.
- PIN Code: Enter your registered PIN code on the keypad, followed by the '#' key.
- RFID Card: Present your registered RFID card to the card reader area.
- Mechanical Key: Insert the mechanical key into the hidden keyhole and turn to unlock.
Locking the Door: The lock automatically engages when the door is closed. For enhanced security, activate the one-touch privacy key from the inside.
Advanced Features:
- Anti-prank Alarm: Activates after multiple incorrect access attempts.
- Adjustable Spy Code: Allows entering random digits before or after your actual PIN to prevent onlookers from guessing your code.
- Low Battery Indication: Visual and/or audible alerts when batteries are low.
- Wrong Password Indication: Alerts for incorrect PIN entries.
- Emergency Micro USB: For temporary power supply in case of complete battery drain.
- Multi-Level Volume Control: Adjust the lock's sound alerts and voice prompts.
- One-Touch Privacy Key: Engages an additional security bolt from the inside, preventing external access even with valid credentials.
6. Maintenance
To ensure the longevity and optimal performance of your smart lock:
- Cleaning: Wipe the lock surface with a soft, dry cloth. Avoid using abrasive cleaners, solvents, or harsh chemicals, as these can damage the finish and electronic components.
- Battery Replacement: Replace all four AA batteries when the low battery indicator appears. Use high-quality alkaline batteries for best performance. Do not mix old and new batteries or different types of batteries.
- Mechanical Parts: Periodically check the handle and latch for smooth operation. Do not lubricate with oil; consult a professional if mechanical issues arise.
- Firmware Updates: For Catus Touch Plus, check the mobile application for any available firmware updates to ensure the latest features and security enhancements.
7. Troubleshooting
If you encounter any issues with your Godrej Smart Lock, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Lock not responding | Dead batteries | Replace all AA batteries. Use emergency Micro USB for temporary power. |
| Fingerprint not recognized | Finger not placed correctly, dirty sensor, unregistered fingerprint | Ensure finger is clean and placed centrally. Clean sensor. Re-register fingerprint if necessary. |
| PIN code not working | Incorrect PIN, unregistered PIN | Verify the PIN code. Ensure it is registered. Try using the spy code feature. |
| RFID card not working | Unregistered card, card not presented correctly | Ensure the card is registered. Present the card firmly to the reader. |
| Door not locking automatically | Misalignment of door/frame, obstruction | Check door alignment and ensure no obstructions prevent the latch from engaging. |
If the issue persists after attempting these solutions, please contact customer support.
8. Specifications
| Feature | Detail |
|---|---|
| Brand | Godrej Locking Solutions and Systems |
| Model Name | Catus Touch Plus & Catus Touch |
| Lock Type | Digital Lock |
| Special Feature | Fingerprint (Catus Touch Plus), PIN Access, RFID (Catus Touch Plus), Mechanical Key |
| Material | Alloy Steel |
| Color | Black |
| Item Dimensions (L x W x H) | 20 x 3 x 2.7 Centimeters |
| Item Weight | 4 kg |
| Door Thickness Compatibility | 35 mm to 65 mm (Wooden Doors Only) |
| Controller Type | Finger Print Control, Touch |
| Power Source | 4 x AA Batteries (not included) |
9. Warranty Information
Godrej Locking Solutions and Systems offers a 3-year product warranty on this product. Please retain your purchase receipt as proof of purchase for warranty claims. Conditions apply.
10. Support and Installation Services
For any assistance, installation services, repairs, emergency opening, key duplication, or free home safety check-up, please contact Godrej customer support.
Image 10.1: Map showing free installation service availability in over 350 cities, along with contact details.
- Toll-Free Number: 1800 209 4543
- Mobile: +91 80 6743 6743, +91 9321 6655 11
- Email: glafsescalation@godrej.com
- Website: www.godrejenterprises.com/support/locks-and-security
Free professional installation is available within 72 hours in over 350 cities.
