1. Introduction
Welcome to the user manual for your BOSGAME M2 Mini PC. This document provides essential information for the proper setup, operation, maintenance, and troubleshooting of your device. Please read this manual thoroughly before using your Mini PC to ensure optimal performance and longevity.
Product Overview
The BOSGAME M2 is a high-performance mini PC designed for various applications, including gaming, design, office work, and entertainment. It features an AMD Ryzen 9 7940HS processor, AMD Radeon 780M graphics, and extensive connectivity options.
Image: Front view of the BOSGAME M2 Mini PC, showcasing its compact design and front ports.
2. Package Contents
Upon unboxing, please verify that all items listed below are present and in good condition.
Image: Display of the BOSGAME M2 Mini PC and its included accessories.
- BOSGAME M2 Mini PC
- Power Adapter
- Power Cable
- HDMI Cable
- VESA Mount with Screws
- User Manual (this document)
- Mouse (as per product details, though not shown in accessory image)
3. Setup Guide
3.1 Connecting Peripherals
- Connect Display: Use the provided HDMI cable or a DisplayPort cable to connect your monitor to the Mini PC's HDMI 2.0 or DP 1.4 port. For USB-C displays, use a compatible USB4 cable.
- Connect Keyboard and Mouse: Plug your USB keyboard and mouse into the available USB 3.2 or USB 2.0 ports.
- Connect Network (Optional): For a wired connection, connect an Ethernet cable from your router to one of the 2.5GbE LAN ports. For wireless, Wi-Fi 6E is built-in.
- Connect Power: Plug the power adapter into the DC-in port on the Mini PC, then connect the power cable to an electrical outlet.
Image: Detailed view of the BOSGAME M2 Mini PC's front and rear ports, including USB, HDMI, DisplayPort, USB-C, and LAN ports.
3.2 Initial Power On
After connecting all necessary peripherals and power, press the power button located on the front of the Mini PC. The system will boot up. Follow the on-screen instructions to complete the operating system setup (e.g., Windows or Linux).
4. Operating Instructions
4.1 Power Management
- Power On: Press the power button.
- Shut Down: Use the operating system's shutdown function.
- Restart: Use the operating system's restart function.
- Sleep Mode: Use the operating system's sleep function.
4.2 Display Configuration
The BOSGAME M2 supports up to four displays simultaneously via its HDMI 2.0, DisplayPort 1.4, and two USB4 (Type-C) ports.
Image: Overview of the BOSGAME M2 Mini PC's features, including its ability to support four screen displays.
- HDMI 2.0: Supports up to 4K resolution at 60Hz.
- DisplayPort 1.4: Supports up to 4K resolution at 144Hz.
- USB4 (Type-C): Each port supports up to 8K resolution at 60Hz, compatible with Thunderbolt accessories.
To configure multiple displays, access your operating system's display settings.
4.3 Network Connectivity
- Wi-Fi 6E: Connect to wireless networks through your operating system's network settings.
- Bluetooth 5.2: Pair Bluetooth devices such as headphones, keyboards, or mice via your operating system's Bluetooth settings.
- 2.5GbE LAN: For wired connections, ensure an Ethernet cable is securely connected to one of the two LAN ports.
4.4 Audio Output
The Mini PC features built-in dual speakers for stereo audio. For external audio, connect headphones or speakers to the 3.5mm audio jack on the front panel. Audio can also be routed through HDMI or DisplayPort to compatible monitors or receivers.
Image: Internal view highlighting the dual 26mm loudspeakers within the BOSGAME M2 Mini PC.
4.5 Storage Expansion
The BOSGAME M2 comes with a 1TB M.2 2280 PCIe 4.0 SSD and supports dual slot expansion for additional M.2 2280 PCIe 4.0 SSDs, up to 8TB total (additional SSDs not included).
Image: Diagram illustrating the expandable M.2 NVMe PCIe 4.0x4 2280 SSD slot for storage upgrades.
5. Maintenance
5.1 Cleaning
Regularly clean the exterior of the Mini PC with a soft, dry cloth. Use compressed air to gently clear dust from ventilation openings to ensure proper airflow and cooling. Do not use liquid cleaners directly on the device.
5.2 Software Updates
Keep your operating system and drivers updated to ensure optimal performance, security, and compatibility. Refer to your operating system's documentation for instructions on checking and installing updates.
5.3 Cooling System
The M2 Mini PC features a dual-layer cooling structure and an advanced VC heat sink solution designed for efficient heat dissipation. Ensure the ventilation areas are not obstructed to maintain effective cooling.
Image: Graph showing CPU temperature changes over 14 hours and noise levels during various software operations, demonstrating efficient cooling and quiet operation.
6. Troubleshooting
- No Power:
- Ensure the power adapter is securely connected to both the Mini PC and a working electrical outlet.
- Verify the power cable is not damaged.
- No Display:
- Check that the HDMI, DisplayPort, or USB-C cable is firmly connected to both the Mini PC and the monitor.
- Ensure the monitor is powered on and set to the correct input source.
- Try a different display cable or monitor if available.
- No Network Connection:
- For wired connections, check the Ethernet cable and router status.
- For Wi-Fi, ensure Wi-Fi is enabled in the operating system and you are connected to the correct network with the correct password.
- No Audio:
- Check the volume settings in your operating system.
- Ensure the correct audio output device is selected (e.g., built-in speakers, headphones, or monitor audio).
- If using external speakers/headphones, ensure they are properly connected to the 3.5mm audio jack.
If you encounter issues not covered here, or if troubleshooting steps do not resolve the problem, please contact BOSGAME customer support.
7. Specifications
| Feature | Detail |
|---|---|
| Model | M2 |
| Processor | AMD Ryzen 9 7940HS (8 Cores, 16 Threads, Max Boost Clock 5.2GHz) |
| Graphics | AMD Radeon 780M (Graphics Frequency: 2800 MHz) |
| RAM | 32GB DDR5 5600MHz (Dual Channel, expandable up to 96GB) |
| Storage | 1TB M.2 2280 PCIe 4.0 SSD (Dual slot expansion up to 8TB) |
| Operating System | Supports Windows and Linux |
| Wireless Connectivity | Wi-Fi 6E (802.11ax), Bluetooth 5.2 |
| Ethernet | Dual 2.5GbE LAN (RJ45) |
| Front Ports | 2x USB 3.2 Gen2, 2x USB 3.2 Gen1, 2x USB4 (Full-featured, 40Gbps, 8K video, PD 3.0), 1x 3.5mm Audio Jack, Power Button |
| Rear Ports | 1x HDMI 2.0 (4K@60Hz), 1x DisplayPort 1.4 (4K@144Hz), 1x USB 2.0, 2x 2.5GbE LAN, DC-in |
| Display Output | Supports 4K Quad-Screen (USB4, DP 1.4, HDMI 2.0) |
| Audio | Built-in Dual 26mm Loudspeakers |
| Cooling System | Dual-layer structure, advanced VC heat sink |
| Item Weight | 3.58 pounds |
| Dimensions | 10.04 x 7.64 x 4.41 inches (Package) |
8. Warranty and Support
8.1 Warranty Information
For detailed warranty information, please refer to the warranty card included with your product or visit the official BOSGAME website. Keep your proof of purchase for warranty claims.
8.2 Customer Support
If you require technical assistance or have questions regarding your BOSGAME M2 Mini PC, please visit the official BOSGAME website for support resources, FAQs, and contact information.
