1. Introduction
This manual provides essential instructions for the safe and effective use of your Homemate Heated Wearable Blanket Hoodie. Please read this manual thoroughly before first use and retain it for future reference. This product is designed to provide warmth and comfort through integrated heating elements powered by a portable battery pack.
Image 1.1: Homemate Heated Wearable Blanket Hoodie with visible heating elements and included battery pack.
2. Safety Information
To ensure safe operation and prevent injury or damage, please adhere to the following safety guidelines:
- Do not use this product if you have a pacemaker, are pregnant, or have any medical conditions that may be adversely affected by heat. Consult a physician before use if you have concerns.
- Keep the product away from open flames and excessive heat.
- Do not use the product while sleeping or if you are unable to feel heat adequately.
- Avoid folding or creasing the heating elements excessively during use, as this may cause overheating.
- Disconnect the battery pack before cleaning or storing the hoodie.
- Do not puncture, disassemble, or modify the battery pack or heating system.
- Ensure the battery pack is fully charged before first use and regularly thereafter.
- This product is UL and FCC certified, indicating compliance with safety standards for electromagnetic radiation.
Image 2.1: The Homemate Heated Wearable Blanket Hoodie is UL and FCC certified for safety.
3. Package Contents
Verify that all items are present in the package:
- 1 x Homemate Heated Wearable Blanket Hoodie
- 1 x 7.4V 5000mAh Lithium Polymer Battery Pack
- 1 x USB Type-C Charging Cable (for battery pack)
- 1 x User Manual (this document)
4. Product Features
The Homemate Heated Wearable Blanket Hoodie offers several features designed for comfort and warmth:
- Oversized Design: Provides ample coverage and freedom of movement.
- Integrated Heating Elements: Strategically placed heating zones for core body warmth.
- Three Temperature Settings: Adjustable heat levels for personalized comfort.
- Soft Fabric: Constructed from ultra-soft flannel and cozy sherpa materials.
- Built-in Power Pocket: A zippered pocket to securely hold the battery pack.
- Elastic Ribbed Cuffs: For a snug fit and to retain warmth.
- Large Sherpa Hood: Provides additional warmth for the head and neck.
Image 4.1: Key features of the Homemate Heated Wearable Blanket Hoodie.
Image 4.2: Illustration of the heating element placement and coverage area.
5. Setup Guide
5.1. Charging the Battery Pack
- Locate the 7.4V 5000mAh Lithium Polymer battery pack and the USB Type-C charging cable.
- Connect the Type-C charging cable to the battery pack's charging port.
- Plug the other end of the charging cable into a compatible USB power adapter (not included) or a computer's USB port.
- Allow 4-5 hours for the battery pack to fully charge. The indicator lights on the battery pack will show charging status.
5.2. Connecting the Battery Pack
- Locate the zippered pocket inside the Homemate Heated Wearable Blanket Hoodie, typically near the front.
- Inside the pocket, you will find a power cable with a connector.
- Connect the power cable from the hoodie to the output port on the fully charged battery pack.
- Place the battery pack securely into the zippered pocket and close the zipper.
Image 5.1: Battery pack details and connection points.
6. Operating Instructions
The Homemate Heated Wearable Blanket Hoodie features a simple one-button control for its heating functions.
6.1. Powering On/Off
- To turn on: Press and hold the power button on the hoodie for approximately 3 seconds. The indicator light will illuminate, typically starting at the highest heat setting (Red).
- To turn off: Press and hold the power button for approximately 3 seconds until the indicator light turns off.
6.2. Adjusting Heat Levels
Once powered on, short press the power button to cycle through the three available heat settings:
- Red Light: High Level (approximately 130-150°F / 54-65°C)
- White Light: Middle Level (approximately 115-130°F / 46-54°C)
- Blue Light: Low Level (approximately 95-115°F / 35-46°C)
Image 6.1: Heat level indicator lights and corresponding settings.
Image 6.2: Heating performance chart, illustrating temperature increase over time.
7. Care and Maintenance
7.1. Washing Instructions
The Homemate Heated Wearable Blanket Hoodie is machine washable. Follow these steps:
- Ensure the battery pack is disconnected and removed from the hoodie's pocket.
- Close the zipper of the battery pocket.
- Machine wash on a gentle cycle with cold water.
- Do not bleach or iron.
- Tumble dry on low heat or hang to dry. Ensure the hoodie is completely dry before reconnecting the battery pack or storing.
7.2. Battery Care
- Charge the battery pack fully before long-term storage.
- Store the battery pack in a cool, dry place.
- Avoid exposing the battery pack to extreme temperatures.
- If the battery pack will not be used for an extended period, charge it every 3-6 months to maintain its lifespan.
8. Troubleshooting
If you encounter issues with your Homemate Heated Wearable Blanket Hoodie, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Hoodie is not heating. | Battery pack is not connected or is depleted. | Ensure the battery pack is securely connected and fully charged. |
| Indicator light is not turning on. | Battery pack is not connected, depleted, or power button not pressed correctly. | Check battery connection and charge level. Press and hold the power button for 3 seconds. |
| Heat feels too low or inconsistent. | Low heat setting selected or battery charge is low. | Cycle through heat settings to a higher level. Recharge the battery pack. |
| Battery pack does not charge. | Faulty charging cable or power adapter. | Try a different USB Type-C cable and power adapter. Ensure connections are secure. |
If the problem persists after attempting these solutions, please contact Homemate customer support.
9. Specifications
| Feature | Detail |
|---|---|
| Model Number | wearable blanket |
| Power Source | 7.4V Lithium Polymer Battery Pack |
| Battery Capacity | 5000mAh |
| Charging Port | USB Type-C |
| Charging Time | Approximately 4-5 hours |
| Heat Settings | 3 Levels (Low, Medium, High) |
| Fabric Type | Sherpa, Flannel |
| Care Instructions | Machine Washable (remove battery) |
| Item Weight | 3.67 pounds (approx. 1.66 kg) |
| Package Dimensions | 11.69 x 10.55 x 5.83 inches (approx. 29.7 x 26.8 x 14.8 cm) |
| Certifications | UL, FCC |
Image 9.1: Approximate dimensions of the oversized hoodie.
10. Warranty and Support
For warranty information, product support, or to report any issues not covered in this manual, please contact Homemate customer service through the retailer's platform or the official Homemate website. Please have your purchase details and product model number (wearable blanket) available when contacting support.
