1. Introduction
This manual provides essential information for the safe and effective operation of your SHEHDS 275W 10R Moving Head Light. Please read this manual thoroughly before installation, operation, or maintenance. Retain this manual for future reference.
Image 1.1: The SHEHDS 275W 10R Moving Head Light.
2. Safety Information
Always observe the following safety precautions to prevent injury or damage to the unit:
- Ensure the power supply voltage matches the unit's requirements.
- Disconnect from power before any service or maintenance.
- Do not operate in wet or damp conditions.
- Maintain adequate ventilation around the unit to prevent overheating.
- Avoid direct eye exposure to the light beam.
- Installation should be performed by qualified personnel.
3. Product Features
The SHEHDS 275W 10R Moving Head Light offers advanced features for dynamic lighting effects:
- Super Bright Output: Utilizes a 275W bulb with efficient optics, 8000K color temperature, and a 5-15 degree beam angle.
- Extensive Color and Gobo Options: Features 14 colors (including half-color effects) and 13 gobos for diverse visual patterns.
- Dual Prism and Special Effects: Equipped with an 8-facet circular prism and a 16-facet circular prism, both independently rotating with variable speed. Includes a Frost (soft light) effect and a Rainbow wheel for enhanced visual displays.
- Multiple Operational Modes: Supports DMX512, Auto, Sound Control, Stand Alone, Master/Slave, and Strobe modes with 14/16 DMX channels.
- Smooth Dimming: Features a 0-100% mechanical dimmer for precise light intensity control.
Image 3.1: Detailed view of the light's aperture, gobo wheel, color wheel, and frost/rainbow wheel.
Image 3.2: Visual representation of the 14 gobos and 14 colors available.
4. Setup
- Unpacking: Carefully remove the light from its packaging. Inspect for any damage during transit.
- Mounting: Securely mount the moving head light using appropriate clamps and safety cables to a truss or stable surface. Ensure the mounting location can support the weight of the fixture (17.1 kg).
- Power Connection: Connect the power cable to a suitable power outlet (275V AC).
- DMX Connection (Optional): For DMX control, connect a 3-pin DMX cable from your DMX controller to the light's DMX input. If linking multiple units, connect the DMX output of the first unit to the DMX input of the next.
Image 4.1: The moving head light projecting various beam patterns.
5. Operating Modes
The SHEHDS 275W 10R Moving Head Light supports several operational modes:
- DMX512 Mode: Allows external control via a DMX controller. The unit supports 14 or 16 DMX channels. Refer to the DMX channel map (not provided in this document, typically found in a separate DMX chart) for specific functions.
- Auto Mode: The light runs through pre-programmed sequences automatically.
- Sound Control Mode: The light reacts to ambient sound, changing patterns and colors in sync with music.
- Stand Alone Mode: Operates independently without external control, using internal programs.
- Master/Slave Mode: Link multiple units where one acts as the master, controlling the others (slaves) to synchronize effects.
- Strobe: Activates a flashing light effect.
Use the onboard display and buttons to select and configure the desired operating mode.
Video 5.1: A short demonstration of the SHEHDS 275W Moving Head Light's beam in action.
Video 5.2: A comprehensive demonstration of the SHEHDS 275W 10R Beam Moving Head Light's various effects and capabilities.
Video 5.3: A demonstration showcasing various moving head light effects from the SHEHDS 275W model.
6. Maintenance
Regular maintenance ensures optimal performance and longevity of your moving head light:
- Cleaning: Periodically clean the exterior casing and optical lenses with a soft, lint-free cloth. Do not use harsh chemicals.
- Fan Vents: Ensure fan vents are clear of dust and debris to maintain proper cooling.
- Bulb Replacement: The 275W bulb has a finite lifespan. Refer to the manufacturer's guidelines for bulb replacement procedures. Always use genuine replacement bulbs.
- Inspection: Regularly check all cables, connections, and mounting hardware for wear or damage.
7. Troubleshooting
If you encounter issues, refer to the following common troubleshooting steps:
| Problem | Possible Cause | Solution |
|---|---|---|
| Light does not power on | No power supply; faulty cable | Check power connection; test outlet; replace cable if damaged. |
| No DMX control | Incorrect DMX address; faulty DMX cable; incorrect mode | Verify DMX address and mode setting; check DMX cable connections; try a different DMX cable. |
| Light beam is dim or inconsistent | Bulb nearing end of life; dirty lens; overheating | Replace bulb; clean lenses; ensure proper ventilation. |
| Unusual noise from unit | Fan obstruction; loose internal component | Clear fan vents; if noise persists, contact support. |
8. Specifications
| Feature | Detail |
|---|---|
| Model Number | 275W Moving head DJ Light |
| Light Source Type | 275W Bulb |
| Color Temperature | 8000 Kelvin |
| Beam Angle | 5-15 degrees |
| Gobos | 13 Gobos |
| Colors | 14 Colors (plus half-color effect) |
| Prisms | 8-facet circular prism, 16-facet circular prism (independently rotating) |
| Special Effects | Frost, Rainbow Wheel, Linear Zoom |
| DMX Channels | 14/16 Channels |
| Dimmer | 0-100% mechanical dimmer |
| Power Source | Corded Electric |
| Voltage | 275V AC |
| Material | High temperature resistant plastic |
| Item Weight | 17.1 kg |
| Dimensions (L x W x H) | 11"L x 9"W x 19"H |
Image 8.1: Product dimensions and weight.
9. What's in the Box
Your package should contain the following items:
- 1 x SHEHDS 275W Moving Head Light
- 1 x Power Cable
- 1 x User Manual (this document)
10. Warranty and Support
This SHEHDS product comes with a 1-year manufacturer's warranty. For warranty claims, technical support, or service inquiries, please contact SHEHDS customer service through your purchase platform or the official SHEHDS website.
For additional resources and product information, visit the official SHEHDS store: SHEHDS Store on Amazon.
