Vangoa 61-Key Light-Up Keyboard Piano and Kids Electric Guitar Instruction Manual

Introduction

This manual provides essential information for the safe and effective use of your Vangoa 61-Key Light-Up Keyboard Piano and Kids Electric Guitar. Please read these instructions thoroughly before operating the instruments and retain them for future reference.

Safety Information

• Power Supply: Use only the specified power adapter. Ensure the voltage matches your local power supply. Unplug the instruments during lightning storms or when unused for extended periods.
• Water and Moisture: Do not expose the instruments to water or excessive moisture. Avoid placing liquid-filled containers near them.
• Ventilation: Do not block ventilation openings. Ensure adequate airflow around the instruments.
• Placement: Place the instruments on a stable, flat surface. Avoid extreme temperatures, direct sunlight, or heat sources.
• Cleaning: Clean only with a dry, soft cloth. Do not use liquid cleaners or aerosols.
• Children: Adult supervision is recommended for young children operating these instruments. Small parts may pose a choking hazard.

Package Contents

Please check that all items are present in your package:

Image: Vangoa 61-Key Light-Up Keyboard Piano with included microphone, power adapter, audio cable, and owner's manual.

Image: Vangoa 30-inch Kids Electric Guitar in blue with included guitar bag, mini amplifier, tuner, capo, strap, picks, and cable.

Setup

Keyboard Piano Setup

1. Power Connection: Connect the AC power adapter to the DC 9V input jack on the back of the keyboard. Plug the adapter into a standard wall outlet. Alternatively, the keyboard can be powered via USB.
2. Microphone Connection: Insert the microphone plug into the designated microphone input jack.
3. Headphone Connection: For private practice, connect headphones to the headphone output jack.
4. Power On: Press the 'Power' button to turn on the keyboard. The LED display will illuminate.

Image: Close-up of the Vangoa 61-Key Light-Up Keyboard Piano's control panel and lighted keys, showing the LED display and various function buttons.

Electric Guitar Setup

1. Strap Attachment: Attach the guitar strap to the strap buttons located on the body of the guitar.
2. Amplifier Connection: Connect one end of the instrument cable to the output jack on the guitar and the other end to the input jack on the mini amplifier.
3. Amplifier Power: Ensure the amplifier has batteries installed or is connected to its power source (if applicable) and turn it on.
4. Tuning: Use the included tuner to accurately tune the guitar strings. Pluck each string individually and adjust the tuning pegs until the tuner indicates the correct pitch.

Image: Diagram illustrating the features of the Vangoa 30-inch Electric Guitar, including tuning pegs, maple fingerboard, C-shape neck, AAA maple neck, 30-inch size, and high gloss finish.

Operating Instructions

Keyboard Piano Operation

• Power On/Off: Press the POWER button to turn the keyboard on or off.
• Volume Control: Use the VOLUME knob or buttons to adjust the overall sound level.
• Lighted Keys: The keyboard features lighted keys to assist beginners in learning melodies. Follow the illuminated keys during demo songs or learning modes.
• Timbres (Voices): Select from 350 built-in timbres to change the instrument sound. Refer to the keyboard's panel for timbre selection buttons or number input.
• Rhythms: Choose from 350 rhythms to add a backing track to your playing. Adjust the tempo as desired.
• Demo Songs: Play one of the 30 demo songs to hear examples or practice along.
• Percussions: Access 61 percussion sounds for rhythmic accompaniment.
• Vibrato & Sustain: Use the dedicated VIBRATO and SUSTAIN buttons to add effects to your sound.
• Recording & Playback: The keyboard allows you to record your performances and play them back. Consult the manual for specific recording and playback button functions.

Image: Diagram showing the rich functions of the Vangoa keyboard, including 350 Timbres, 350 Rhythms, 30 Demo Songs, 8 Percussions, Sustain & Vibrato, Dual Keyboard, Microphone Gift, Headphone Connectable, and Recording & Playback.

Electric Guitar Operation

• Volume Knob: Adjust the output volume of the guitar using the VOLUME knob on the guitar body.
• 3-Way Switch (Pickup Selector): The guitar features S-S (Single-Single) pickups. Use the 3-way switch to select different pickup configurations, which alters the tonal quality of the sound. Experiment with positions to find your preferred tone.
• Playing: Hold the guitar comfortably. Use a pick or your fingers to pluck or strum the strings. Practice basic chords and scales.

Image: Close-up of the Vangoa Electric Guitar's S-S pickups, stable bridge, volume knob, and 3-way switch, highlighting the controls for tone adjustment.

Maintenance

• Cleaning: Wipe down the instruments regularly with a soft, dry, lint-free cloth. For the guitar, clean the strings after each use to prolong their life.
• Storage: Store the instruments in a cool, dry place away from direct sunlight, extreme temperatures, and humidity. Use the provided guitar bag for protection.
• String Replacement (Guitar): Guitar strings will eventually wear out and break. Replace them with appropriate gauge strings when necessary.
• Battery Replacement (Amp/Tuner): If the mini amplifier or tuner uses batteries, replace them when power is low.

Troubleshooting

Keyboard Piano

• No Sound:
  • Ensure the power adapter is securely connected and the keyboard is turned on.
  • Check the volume level.
  • If headphones are connected, sound will only come through them. Disconnect headphones if you want sound from the speakers.
• Keys Not Lighting Up:
  • Ensure the lighted key feature is enabled (if applicable, refer to specific button on keyboard).
  • This feature typically works during learning modes or demo songs.

Electric Guitar

• No Sound from Amplifier:
  • Ensure the guitar and amplifier are both turned on.
  • Check that the instrument cable is securely connected to both the guitar and the amplifier.
  • Verify the amplifier's volume is turned up.
  • Check the amplifier's power source (batteries or power adapter).
• Poor Sound Quality/Buzzing:
  • Ensure all cable connections are tight.
  • Check the guitar's volume and tone knobs.
  • Try a different instrument cable to rule out a faulty cable.
  • Ensure the guitar is properly tuned.

Specifications

Warranty Information

Vangoa products are designed and manufactured to high-quality standards. This product is covered by a manufacturer's warranty against defects in materials and workmanship. Please refer to the specific warranty terms provided with your purchase documentation or contact Vangoa customer support for details. Keep your proof of purchase for warranty claims.

Customer Support

For technical assistance, troubleshooting, or warranty inquiries, please contact Vangoa customer support. You can typically find contact information on the Vangoa official website or through the retailer where you purchased the product.

Visit the Vangoa Store on Amazon for more information and support resources.
