Introduction
This manual provides comprehensive instructions for the installation, operation, and maintenance of your Artos ROUND BAR FAUCET, model F501-11. Please read all instructions carefully before installation and use to ensure proper function and to prevent damage.
Safety Information
Always turn off the main water supply before beginning any installation or maintenance. Wear appropriate safety gear, such as safety glasses, during installation. If you are unsure about any part of the installation process, consult a qualified plumber.
Package Contents
Verify that all components are present before beginning installation:
- Artos ROUND BAR FAUCET (F501-11)
- Mounting hardware (gasket, washer, nut)
- Hot and cold water supply lines
- Instruction Manual (this document)
Tools Required for Installation
The following tools are typically required for installation:
- Adjustable wrench
- Phillips head screwdriver
- Plumber's putty or silicone sealant
- Flashlight (optional)
- Safety glasses
Setup and Installation
The Artos F501-11 faucet is designed for single-hole, deck-mount installation. Follow these steps carefully:
- Prepare the Mounting Surface: Ensure the sink or countertop hole is clean and free of debris. The faucet requires a single mounting hole.
- Install the Faucet: Place the rubber gasket onto the base of the faucet. Insert the faucet body through the mounting hole in the sink or countertop.
- Secure the Faucet: From underneath the sink, slide the metal washer and then the mounting nut onto the threaded shank of the faucet. Hand-tighten the nut, then use an adjustable wrench to firmly secure the faucet, ensuring it is straight and stable. Do not overtighten.
- Connect Water Supply Lines: Attach the hot and cold water supply lines to the corresponding inlets on the faucet body. Connect the other ends of the supply lines to your hot and cold water shut-off valves. Use an adjustable wrench to tighten connections, but do not overtighten.
- Check for Leaks: Once all connections are secure, slowly turn on the main water supply. Check all connections for leaks. If leaks are detected, tighten the connections slightly until the leak stops.
- Flush the Faucet: Remove the aerator from the faucet spout. Turn on both hot and cold water to full flow for one minute to flush out any debris from the lines. Turn off the water, reattach the aerator.
Image: Artos ROUND BAR FAUCET F501-11 in chrome finish installed on a white marble countertop next to a sink. This image displays the Artos ROUND BAR FAUCET, model F501-11, in its chrome finish, mounted on a white marble countertop. The faucet features a single handle and a curved spout, positioned over a white sink. A small potted plant is visible to the right of the faucet.
Operating Instructions
The Artos F501-11 bar faucet features a single forward-action handle for controlling both water flow and temperature.
- Water Flow: Lift the handle upwards to increase water flow. Push the handle downwards to decrease or shut off water flow.
- Temperature Control: Move the handle to the left for hot water and to the right for cold water. Adjust the handle position between left and right to achieve the desired water temperature. The forward-action design prevents collision with the backsplash.
Maintenance
Proper care and maintenance will ensure the longevity and appearance of your Artos faucet.
- Cleaning the Finish: Clean the chrome finish regularly with a soft cloth and mild soap and water. Rinse thoroughly and dry with a soft cloth to prevent water spots. Avoid abrasive cleaners, harsh chemicals, or scouring pads, as these can damage the tarnish-resistant finish.
- Aerator Maintenance: If water flow decreases or becomes irregular, the aerator may be clogged. Unscrew the aerator from the spout, clean any debris, and rinse it under running water. Reattach the aerator.
- Ceramic Disc Cartridge: The faucet is equipped with a high-quality ceramic disc cartridge designed for durability and leak-free operation. No regular maintenance is typically required for the cartridge itself. If leaks occur from the handle, consult the troubleshooting section or a professional.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Low Water Flow | Clogged aerator; partially closed shut-off valves; debris in supply lines. | Clean aerator. Ensure shut-off valves are fully open. Flush supply lines. |
| Leaks from Spout | Loose aerator; damaged ceramic cartridge. | Tighten aerator. If problem persists, contact customer support for cartridge replacement. |
| Leaks from Handle Base | Loose connections; damaged O-rings or cartridge. | Check and tighten handle assembly. If problem persists, contact customer support. |
| Water Temperature Issues | Incorrect supply line connection; issues with water heater. | Verify hot and cold supply lines are connected correctly. Check water heater settings. |
Specifications
| Feature | Detail |
|---|---|
| Brand | Artos |
| Model Name | ROUND BAR FAUCET |
| Model Number | F501-11 |
| Color | Chrome |
| Mounting Type | Deck Mount |
| Installation Type | Single Hole |
| Number of Handles | 1 |
| Maximum Flow Rate | 1.8 Gallons Per Minute |
| Item Weight | 5 Pounds |
| Product Dimensions | 8"D x 2"W x 12"H |
| Special Feature | Tarnish Resistant |
| UPC | 799947594023 |
Warranty Information
Artos products are manufactured to high-quality standards. For specific warranty details regarding your ROUND BAR FAUCET (F501-11), please refer to the warranty card included with your purchase or visit the official Artos website. Keep your proof of purchase for warranty claims.
Customer Support
If you have any questions, require assistance with installation, or need to troubleshoot an issue not covered in this manual, please contact Artos customer support. Contact information can typically be found on the manufacturer's website or on your product packaging.
