1. Introduction
The Darmoshark N5 is a high-performance tri-mode wireless gaming mouse designed for versatility and precision. It offers 2.4G wireless, Bluetooth, and wired USB-C connectivity, making it suitable for various platforms including Windows and Mac. Featuring a lightweight design, a PAW3395 optical sensor with up to 26000 DPI, and 7 programmable buttons, the N5 mouse provides a responsive and comfortable gaming experience.
2. Key Features
- Tri-Mode Connectivity: Seamlessly switch between 2.4G wireless, Bluetooth, and wired USB-C connections.
- High-Precision Sensor: Equipped with the PAW3395 optical sensor, offering up to 26000 DPI for accurate tracking and quick response.
- Ultra-Lightweight Design: Weighing approximately 57 grams, designed for comfortable grip and reduced hand fatigue during extended use.
- 7 Programmable Buttons: Customize controls to suit your gaming style using the official software.
- Long Battery Life: Integrated 500mAh battery provides extended usage.
- Versatile Compatibility: Compatible with both Windows and Apple Mac operating systems.
- 8KHz Polling Rate: Supports up to 8KHz return rate for ultra-low latency (requires separate receiver for 8KHz).
Image 1: An exploded view of the Darmoshark N5 mouse, detailing internal components such as the PAW3395 sensor, TTC microswitches, PTFE footbeds, NANO receiver, and the built-in 500mAh lithium battery.
3. Setup Guide
3.1 Unboxing and Initial Preparation
Carefully remove the mouse and all accessories from the packaging. Ensure you have the mouse, USB-C cable, 2.4G USB receiver, and any included anti-slip stickers or spare foot stickers. Remove any protective films from the mouse feet for optimal glide.
Video 1: Unboxing and initial setup of the Darmoshark N5 mouse, showing included accessories like the USB-C cable, adapter, and anti-slip stickers. The video also demonstrates removing the protective film from the mouse feet and locating the USB receiver.
3.2 Connecting the Mouse
The Darmoshark N5 supports three connection modes:
- 2.4G Wireless Mode:
- Locate the 2.4G USB receiver stored in the compartment on the underside of the mouse.
- Plug the USB receiver into an available USB port on your computer.
- Turn on the mouse using the switch on the bottom. The mouse should automatically connect.
- Bluetooth Mode:
- Turn on the mouse and switch it to Bluetooth mode using the selector on the bottom.
- On your computer (Windows or Mac), go to Bluetooth settings and search for new devices.
- Select "Darmoshark N5" from the list of available devices to pair.
- Wired USB-C Mode:
- Connect the provided USB-C cable to the front port of the mouse.
- Connect the other end of the USB-C cable to an available USB port on your computer.
- The mouse will function in wired mode and charge simultaneously.
Image 2: The Darmoshark N5 Tri-Mode Wireless Gaming Mouse in red, showcasing its ergonomic design and smooth finish.
4. Operating the Mouse
4.1 DPI Adjustment
The mouse features a dedicated DPI adjustment button, typically located on the underside or top of the mouse, allowing you to cycle through different sensitivity levels. Refer to the product diagram for the exact location. Each press will change the DPI setting, indicated by an LED light or software interface.
Image 3: A detailed diagram of the Darmoshark N5 mouse, highlighting its dimensions (123mm x 68mm x 40mm) and the location of buttons, including the DPI adjustment key, return rate button, and adapter storage slot.
4.2 Polling Rate (Return Rate)
The N5 mouse supports various polling rates, including an 8KHz return rate for extremely low latency. This feature enhances responsiveness, making cursor movements smoother and more accurate. To utilize the 8KHz polling rate, a separate compatible receiver may be required.
Image 4: Illustration demonstrating the wireless 8KHz return rate capability of the Darmoshark N5 mouse, highlighting its low latency response time of 0.125ms for precise control.
4.3 Programmable Buttons
The mouse features 7 programmable buttons. To customize these buttons, download and install the official Darmoshark software from the manufacturer's website. The software allows you to assign macros, rebind keys, and adjust other performance settings.
5. Battery and Charging
The Darmoshark N5 is equipped with a 500mAh Lithium Ion battery. To charge the mouse, connect it to your computer using the provided USB-C cable. The mouse can be used in wired mode while charging. A full charge provides approximately 125 hours of usage in no-light mode or 83 hours with lights on.
Image 5: The Darmoshark N5 mouse on a charging dock, illustrating its long-lasting 500mAh battery for extended use.
6. Maintenance
- Cleaning: Use a soft, dry cloth to clean the mouse surface. For stubborn dirt, a slightly damp cloth can be used, but ensure no moisture enters the mouse.
- Sensor Care: Keep the optical sensor on the underside of the mouse clean and free from dust or debris to ensure accurate tracking.
- PTFE Feet: The mouse features 100% PTFE feet for smooth gliding. If the feet become worn, replace them with the provided spare foot stickers or purchase new ones.
- Storage: When not in use for extended periods, store the mouse in a dry, cool place.
7. Troubleshooting
- Mouse Not Responding:
- Ensure the mouse is charged.
- Check if the mouse is turned on and in the correct connection mode (2.4G, Bluetooth, or wired).
- For 2.4G, ensure the USB receiver is securely plugged into a working USB port.
- For Bluetooth, ensure the mouse is paired correctly and your computer's Bluetooth is enabled.
- Try connecting the mouse in wired mode to rule out wireless issues.
- Lag or Disconnections:
- Reduce interference by moving the mouse closer to the receiver or computer.
- Ensure other wireless devices are not causing interference.
- Update mouse drivers and firmware (via official software).
- Check battery level; low battery can affect wireless performance.
- Inaccurate Tracking:
- Clean the optical sensor on the underside of the mouse.
- Use the mouse on a clean, uniform surface or a high-quality mouse pad.
- Adjust DPI settings to a comfortable level.
- Buttons Not Working:
- Ensure the mouse is powered on and connected.
- Check for any software conflicts or rebinds in the Darmoshark software.
Video 2: A demonstration of the Darmoshark N5 mouse in use, highlighting its responsiveness and performance during gaming. This video also shows the mouse's lightweight design and ergonomic shape.
8. Specifications
| Feature | Detail |
|---|---|
| Brand | Darmoshark |
| Model | N5 |
| Connectivity Technology | 2.4G Wireless, Bluetooth, USB-C Wired |
| Movement Detection Technology | Optical (PAW3395 Sensor) |
| Max DPI | 26000 DPI |
| Polling Rate | Up to 8KHz (with separate receiver) |
| Programmable Buttons | 7 |
| Battery | 500mAh Lithium Ion (included) |
| Item Weight | Approximately 57 grams (2.01 ounces) |
| Dimensions (L x W x H) | 123mm x 68mm x 40mm |
| Compatibility | Windows, Mac |
Image 6: A close-up view of the PAW3395 optical sensor, emphasizing its high-performance capabilities for gaming with 26000 DPI sensitivity and 650 IPS accuracy.
9. Warranty and Support
The Darmoshark N5 Tri-Mode Wireless Gaming Mouse comes with a manufacturer's warranty. For specific warranty details, please refer to the documentation included with your product or visit the official Darmoshark website. For technical support, troubleshooting assistance, or to download the latest software and drivers, please contact Darmoshark customer service or visit their support page.
Manufacturer: Darmoshark
Official Website: Darmoshark Store on Amazon
