1. Introduction
Thank you for choosing the Geeni Smart Multi-Outlet Surge Protector. This device provides intelligent power management for your electronics, featuring four independently controlled smart AC outlets and two fast-charging USB ports (USB-A and USB-C). It includes robust surge protection and can be controlled remotely via the Geeni app or through voice commands with Amazon Alexa and Google Assistant. This manual provides essential information for setup, operation, and maintenance.
Image 1.1: Geeni Smart Multi-Outlet Surge Protector
2. Safety Information
- Do not exceed the electrical ratings of the device (125V, 15A).
- Use indoors only. This device is not suitable for outdoor use.
- Keep away from water and high humidity environments.
- Do not disassemble or attempt to repair the device. Contact customer support for assistance.
- Ensure proper grounding. Plug the surge protector into a grounded 3-prong outlet.
- This device is a surge protector, but it cannot guarantee protection against all power surges.
3. Package Contents
- Geeni Smart Multi-Outlet Surge Protector (Model GN-SW010-199)
- User Manual
4. Product Features
The Geeni Smart Multi-Outlet Surge Protector offers advanced features for convenient and safe power management:
- 4 Smart Outlets & 2 USB Ports: Independently control four AC outlets and utilize one USB-A and one USB-C port for charging.
- Remote Control & Automation: Manage connected devices from any location using the Geeni app. Set schedules and timers for automated operation.
- Surge Protection: Integrated surge protection up to 1200 joules safeguards electronics from power fluctuations.
- Individual Control: Each AC outlet can be controlled separately for maximum flexibility.
- Voice-Activated Convenience: Compatible with Amazon Alexa and Google Assistant for hands-free control.
Image 4.1: Overview of Key Product Features
5. Setup Guide
5.1 Download the Geeni App
- Search for "Geeni" in the Apple App Store or Google Play Store.
- Download and install the app.
- Register for a new account or log in with an existing one.
5.2 Connect to Power
- Plug the Geeni Smart Multi-Outlet Surge Protector into a standard 125V AC wall outlet.
- Ensure the main power switch (circuit breaker) on the surge protector is in the 'ON' position.
5.3 Wi-Fi Pairing
The device supports 2.4 GHz Wi-Fi networks only. Ensure your router is configured to allow 2.4 GHz connections.
- Open the Geeni app and tap "Add Device" or the "+" icon.
- Select "Power Strip" from the device list.
- Press and hold the small Wi-Fi button on the surge protector for approximately 5 seconds until the Wi-Fi indicator light begins to blink rapidly. This indicates pairing mode.
- Follow the on-screen instructions in the Geeni app to connect the device to your home Wi-Fi network. You will need to enter your Wi-Fi password.
- Once connected, the Wi-Fi indicator light will become solid.
Image 5.1: Geeni App interface for device control
5.4 Voice Assistant Integration (Optional)
To enable voice control with Amazon Alexa or Google Assistant:
- Open your Alexa or Google Home app.
- Navigate to the "Skills & Games" (Alexa) or "Works with Google" (Google Home) section.
- Search for and enable the "Geeni" skill/service.
- Link your Geeni account when prompted.
- Discover devices. Your smart outlets will appear in the voice assistant app, allowing you to assign names and control them.
6. Operating Instructions
6.1 Controlling Outlets via Geeni App
Each of the four AC outlets can be controlled individually:
- Open the Geeni app and select your Smart Multi-Outlet Surge Protector.
- You will see individual controls for each outlet (e.g., Switch 1, Switch 2, etc.).
- Tap the power icon next to an outlet to turn it ON or OFF.
- You can rename outlets within the app for easier identification (e.g., "Lamp," "Fan," "TV").
Image 6.1: Individual outlet control through the Geeni app
6.2 Setting Schedules and Timers
Automate your devices by setting schedules:
- In the Geeni app, select your Smart Multi-Outlet Surge Protector.
- Look for the "Schedule" or "Timer" option.
- Follow the prompts to set specific ON/OFF times for individual outlets or groups of outlets.
- You can also set countdown timers for temporary operation.
Image 6.2: Setting personalized schedules for devices
6.3 Voice Commands
Once integrated with Alexa or Google Assistant, use simple voice commands:
- "Alexa, turn on [Outlet Name]."
- "Hey Google, turn off [Outlet Name]."
- "Alexa, set [Outlet Name] to turn off in 30 minutes."
Image 6.3: Hands-free voice control with smart assistants
6.4 USB Charging Ports
The two USB ports (USB-A and USB-C) provide fast charging for compatible devices. These ports are always active when the surge protector is powered on and cannot be controlled individually via the app or voice commands.
Image 6.4: Powering and charging multiple devices
7. Maintenance
- To clean the device, unplug it from the wall outlet and wipe it with a dry, soft cloth.
- Do not use liquid cleaners or abrasive materials.
- Regularly check the power cord for any signs of damage.
8. Troubleshooting
- Device Offline / Cannot Connect to Wi-Fi:
- Ensure your Wi-Fi network is 2.4 GHz. The device does not support 5 GHz networks.
- Check your Wi-Fi signal strength. Move the surge protector closer to your router if necessary.
- Restart your Wi-Fi router and the surge protector.
- Try resetting the device by holding the Wi-Fi button for 5 seconds until the indicator blinks rapidly, then attempt pairing again.
- Outlets Not Responding:
- Verify the surge protector is plugged in and the main power switch is ON.
- Check the Geeni app to ensure the device is online.
- If using voice control, ensure your voice assistant is properly linked to your Geeni account and the outlet names are recognized.
- Surge Protection Indicator:
- If the surge protection indicator light is off, the surge protection feature may be compromised. Replace the unit.
9. Specifications
| Feature | Specification |
|---|---|
| Model Number | GN-SW010-199 |
| Input Voltage | 125 Volts |
| Amperage Capacity | 15 Amps |
| Total Power Outlets | 4 AC Outlets + 2 USB Ports (USB-A, USB-C) |
| Surge Protection | 1200 Joules |
| Cord Length | 6 ft |
| Connectivity | Wi-Fi (2.4 GHz only) |
| Material | Acrylonitrile Butadiene Styrene |
| Dimensions | 14 x 4.8 x 0.04 inches (Product) |
| Item Weight | 1.48 pounds |
Image 9.1: Product Dimensions and Components
10. Warranty and Support
This Geeni product comes with a 1-Year Limited Warranty from the date of purchase. This warranty covers defects in materials and workmanship under normal use.
For warranty claims, technical support, or further assistance, please visit the official Geeni support website or contact their customer service. Refer to the packaging or the Geeni app for the most current support contact information.
