1. Introduction and Safety Information
This manual provides essential information for the correct installation, safe operation, and effective maintenance of your Candy CI1C7SB1FA integrated dishwasher. Please read all instructions carefully before using the appliance to ensure optimal performance and to prevent damage or injury.
Important Safety Warnings:
- Always disconnect the appliance from the power supply before cleaning or performing any maintenance.
- Do not allow children to play with or operate the dishwasher.
- Use only detergents and rinse aids specifically designed for automatic dishwashers.
- Ensure the appliance is properly earthed.
- Do not open the door during operation, especially during the hot wash cycle.
2. Setup and Installation
The Candy CI1C7SB1FA is an integrated dishwasher designed to be built into kitchen cabinetry. Professional installation is highly recommended to ensure proper fit, water, and electrical connections.
2.1 Unpacking and Positioning
Carefully remove all packaging materials. Inspect the dishwasher for any transport damage. Place the dishwasher in the desired location, ensuring it is level using the adjustable feet. The appliance dimensions are approximately 68.9 cm (depth) x 66.86 cm (width) x 88.73 cm (height).
Figure 1: Front view of the Candy CI1C7SB1FA integrated dishwasher. This image shows the appliance ready for integration into kitchen furniture, highlighting its compact 45 cm width.
2.2 Water and Electrical Connections
Connect the water inlet hose to a cold water supply with a minimum pressure of 0.04 MPa and a maximum of 1 MPa. Connect the drain hose to a suitable drain pipe, ensuring there are no kinks. The dishwasher requires a 220-240 V, 10 A electrical supply. Ensure the electrical outlet is easily accessible after installation.
Note: All connections must comply with local plumbing and electrical codes.
3. Operating Instructions
Your Candy CI1C7SB1FA dishwasher features an integrated display for easy program selection and monitoring.
3.1 Loading the Dishwasher
- Scrape off large food particles from dishes before loading.
- Place larger items in the lower basket and smaller, delicate items in the upper basket.
- Ensure spray arms can rotate freely.
3.2 Adding Detergent and Rinse Aid
Fill the detergent dispenser with the appropriate amount of dishwasher detergent. If using rinse aid, ensure the rinse aid dispenser is filled to the recommended level. The dishwasher can reach a maximum temperature of 75°C during certain cycles.
3.3 Selecting and Starting a Program
- Close the dishwasher door.
- Use the integrated display and control buttons to select your desired wash program.
- Press the Start button to begin the cycle.
- The display will show the remaining time and program status.
4. Maintenance and Cleaning
Regular maintenance ensures the longevity and efficiency of your dishwasher.
4.1 Cleaning the Filters
The filter system, located at the bottom of the wash tub, should be cleaned regularly (e.g., weekly). Remove the coarse filter, fine filter, and microfilter, rinse them under running water, and reassemble them correctly.
4.2 Cleaning the Spray Arms
Check the spray arm nozzles for blockages. If necessary, remove the spray arms and clear any debris from the holes using a thin object like a toothpick.
4.3 Exterior and Interior Cleaning
Wipe the exterior of the dishwasher with a damp cloth. For the interior, run a dishwasher cleaning cycle periodically or use a specialized dishwasher cleaner.
5. Troubleshooting
Before contacting service, refer to the following common issues and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Dishwasher does not start | Power supply issue, door not closed properly, program not selected. | Check power connection, ensure door is latched, select a program and press start. |
| Dishes not clean | Clogged filters, blocked spray arms, incorrect detergent, improper loading. | Clean filters and spray arms, use correct detergent, reload dishes correctly. |
| Water not draining | Clogged drain hose or filter, drain pump issue. | Check and clear drain hose and filter. If problem persists, contact service. |
| Excessive noise | Items interfering with spray arms, improper loading, foreign object in pump. | Rearrange dishes, check for foreign objects. |
6. Specifications
| Brand | CANDY |
| Model | CI1C7SB1FA |
| Model Number | S0456113 |
| Installation Type | Integrated |
| Dimensions (L x W x H) | 68.9 cm x 66.86 cm x 88.73 cm |
| Weight | 51.17 kg |
| Energy Class | C |
| Voltage | 220-240 V |
| Amperage | 10 A |
| Maximum Temperature | 75°C |
| Features | Integrated display, Adjustable feet |
7. Warranty and Support
For warranty information, please refer to the warranty card included with your appliance or visit the official Candy website. For technical support, spare parts, or service requests, please contact Candy customer service. Ensure you have your model number (S0456113) and serial number ready when contacting support.
You can find more information and support on the official Candy website: www.candy-home.com
