ELEMARA Electric Dirt Bike (Model WJL013LAN0X) Instruction Manual

1. Important Safety Information

WARNING: To reduce the risk of injury, adult supervision is required. Never use in roadways, near motor vehicles, on or near steep inclines or steps, swimming pools or other bodies of water. Always wear shoes, helmet, and protective gear (knee & elbow pads) when riding. This product is intended for children aged 13-16 years with a maximum weight capacity of 150 lbs.

• For external use only.
• Avoid contact with eyes.
• Keep away from naked flame or direct heat sources.
• Read and understand all instructions and safety guidelines in the complete manual before use.

2. Setup and Assembly

The ELEMARA Electric Dirt Bike requires assembly before first use. Please follow the steps below and refer to the provided video for visual guidance.

2.1 Unboxing and Initial Check

Carefully remove all components from the packaging. Verify that all parts listed in the packing list are present. The package includes: Electric Dirt Bike*1, Manual*1.

Figure 1: ELEMARA Electric Dirt Bike (Blue model)

2.2 Assembly Steps

For detailed assembly instructions, please watch the official installation video below. It covers shock absorber assembly, front guard and mudguard installation, front wheel assembly, handlebar attachment, and battery connection.

1. Shock Absorber Assembly: Release screws and nuts from the shock absorber. Lift the seat and insert the shock absorber into the car body. Secure with screws and nuts. (Requires two people for installation).
2. Front Guard and Mudguard Assembly: Attach the front guard to the corresponding position on the car body and secure it with screws from the bottom. Insert the mudguard into its position.
3. Front Wheel Assembly: Remove the front axle from the front fork. Remove protective silicone covers, nuts, and washers from the front wheel. Insert the front wheel into the front fork, then re-insert washers and nuts on both sides. Fix nuts with an open spanner.
4. Handlebar Assembly: Attach the handlebar fixing devices to the car body. Insert the handlebar and secure it with screws, ensuring alignment with indentations.
5. Battery Connection: Use a screwdriver to remove two screws from the bottom of the seat. Open the seat and connect the two red plugs to connect the power. Align the snaps on each side of the seat and insert the seat, then secure it with the two screws.

2.3 Initial Battery Charging

It is recommended to charge the battery for 6-8 hours for the first use to ensure it is fully charged. The bike uses 2 x 12V batteries (included).

3. Operating Instructions

3.1 Power On/Off

Press the power button located on the control panel to turn the bike on or off. The control panel also features a light switch and speed switch.

Figure 2: Control panel with power, light, and speed switches.

3.2 Throttle and Speed Control

The bike features a twist-grip throttle for acceleration. Gently twist the throttle to increase speed. The bike has a maximum speed of 15.5 mph.

Use the Speed Switch on the control panel to toggle between different speed modes (e.g., low and high speed) suitable for the rider's experience level.

3.3 Braking

The ELEMARA Electric Dirt Bike is equipped with a hand-operated rear drum brake. Squeeze the brake lever on the handlebar to slow down and stop the bike.

3.4 Music and Bluetooth

The bike includes built-in music and Bluetooth connectivity. Use the controls on the panel to play pre-loaded music or connect your device via Bluetooth to play your own audio.

4. Maintenance

4.1 Battery Care

• After every ride, it is recommended to charge the battery for 8-12 hours.
• When the bike is not used for a long time, it is recommended that the battery is fully charged, the car switch is switched off to ensure that the battery power is disconnected.
• Place the bike and battery in a cool and ventilated environment for storage.
• When not in use, the battery should be charged once a month.

4.2 Tire Maintenance

The bike is equipped with 12" large-size wear-resistant inflatable rubber wheels. Regularly check tire pressure to ensure optimal performance and a smooth ride.

4.3 General Cleaning

Clean the bike regularly with a damp cloth. Avoid using harsh chemicals or abrasive cleaners that could damage the finish or electronic components.

5. Troubleshooting

5.1 Inability to Charge

• Replace the charger or check the wiring for any damage or loose connections.
• Continuously charge for 48 hours and then perform a ride test.
• If the issue persists, the battery may need to be replaced.

5.2 Brake Adjustment

If there is too much travel on the brake lever, it needs tightening. Loosen the white nut on the brake lever in an anticlockwise direction to tighten the brake. If further adjustment is needed, loosen the nut of the brake cable near the rear wheel in an anticlockwise direction, tighten the brake cable, and hold it on. Rotate the wheel to check the degree of tightness. When you feel a little friction on the wheel, tighten the brake cable.

Figure 3: Rear drum brake mechanism.

6. Specifications

7. Warranty and Support

This product comes with a comprehensive instruction manual that includes detailed assembly instructions, safety guidelines, and information regarding product usage. For specific warranty details, technical support, or to inquire about replacement parts, please refer to the contact information provided within the physical manual included with your product or visit the official ELEMARA website.
