NUU GARDEN NG-5PC-ODS 5-Piece Outdoor Dining Set Instruction Manual

1. Introduction

Thank you for choosing the NUU GARDEN NG-5PC-ODS 5-Piece Outdoor Dining Set. This set is designed to enhance your outdoor living space with its durable construction and comfortable features. Please read this manual thoroughly before assembly and use to ensure proper installation, operation, and maintenance.

2. Safety Information

Always follow basic safety precautions when using this product to reduce the risk of injury or damage. Keep all parts and tools out of reach of children. Ensure all fasteners are securely tightened before use. Do not stand on the table or chairs. Use on a flat, stable surface.

3. Parts List

Before beginning assembly, ensure all parts are present and undamaged. If any parts are missing or damaged, do not proceed with assembly. Contact customer service for assistance.

Package Contents:

1 x Dining Table (Slatted Tabletop)
4 x Swivel Chairs (Textilene Seating)
Assembly Hardware (Bolts, Washers, Wrenches)

Visual Reference:

Diagram showing dimensions of the dining table and swivel chair — Figure 3.1: Detailed dimensions of the NUU GARDEN dining table and swivel chair components.

4. Setup and Assembly

Assembly is required for this dining set. It is recommended to have two adults for assembly. Please follow the steps below carefully.

Tools Required:

Included Allen Wrench

Assembly Steps:

Unpack Components: Carefully remove all parts from the packaging. Lay them out on a soft, clean surface to prevent scratches.
Assemble Table Legs: Attach the table legs to the tabletop using the provided bolts and washers. Do not fully tighten the bolts until all legs are in place.
Attach Chair Bases: Secure the swivel mechanism to the chair seat frame using the appropriate hardware.
Attach Chair Backrests: Connect the backrest to the seat frame and armrests. Ensure all connections are aligned before tightening.
Final Tightening: Once all components are loosely assembled, gradually tighten all bolts on both the table and chairs. Ensure the furniture is stable and level.
Insert Umbrella Hole Cover: If not using an umbrella, insert the provided lid into the umbrella hole on the tabletop.

Assembly Video:

Video 4.1: A seller-provided video demonstrating the assembly and features of the NUU GARDEN Patio Dining Set.

5. Operating Instructions

The NUU GARDEN dining set is designed for comfortable outdoor use. Here are key features and how to use them:

360-Degree Swivel Chairs: The chairs feature a smooth 360-degree swivel mechanism, allowing for easy rotation and flexible movement. Simply push off the ground with your feet to rotate.
Ergonomic Design: The chairs are ergonomically designed with a high backrest and wide seat to promote comfort and a healthier seating position.
Umbrella Hole: The table includes a 1.57-inch umbrella hole with a removable lid. Insert a standard patio umbrella (not included) into the hole for shade. Ensure the umbrella is securely fastened in a base (not included) for stability.

Product Features:

Detailed view of the table features including slatted tabletop, umbrella hole, reinforced edges, fixed holder, bowed legs, and adjustable knobs — Figure 5.1: Key design elements of the NUU GARDEN dining table, highlighting the slatted tabletop, umbrella hole, and sturdy construction.

Image showing a person comfortably seated in the ergonomic chair, highlighting the humanized backrest and curved armrests — Figure 5.2: The ergonomic design of the swivel chair, featuring a humanized backrest and curved armrests for optimal comfort.

Close-up of the breathable and weather-resistant Textilene fabric of the chair — Figure 5.3: The breathable and weather-resistant Textilene fabric used in the chair seating, designed for quick drying and durability.

6. Maintenance

Proper care and maintenance will extend the life of your outdoor dining set.

Cleaning: Wipe with a dry cloth to remove dust and debris. For deeper cleaning, use a mild soap and water solution with a soft cloth. Rinse thoroughly and dry completely to prevent water spots or rust.
Weather Protection: While the set features weather-resistant materials, covering it during harsh weather conditions (heavy rain, snow, strong winds) or prolonged periods of non-use is recommended to preserve its appearance and longevity.
Storage: During off-season or extended periods of non-use, store the furniture in a cool, dry place, preferably covered, to protect it from extreme temperatures and moisture.
Fastener Check: Periodically check all bolts and connections to ensure they remain tight. Re-tighten as necessary.

7. Troubleshooting

If you encounter any issues with your dining set, refer to the following common problems and solutions:

Problem	Possible Cause	Solution
Chairs are wobbly.	Loose fasteners. Uneven surface.	Tighten all bolts. Move to a level surface or adjust footcaps if available.
Table is unstable.	Loose fasteners. Uneven surface.	Tighten all bolts. Move to a level surface.
Swivel mechanism is stiff.	Lack of lubrication. Debris in mechanism.	Clean the swivel mechanism and apply a silicone-based lubricant.

8. Specifications

Detailed product specifications for the NUU GARDEN NG-5PC-ODS 5-Piece Outdoor Dining Set:

Brand: NUU GARDEN
Model: NG-5PC-ODS
Color: Upgraded Brown
Size: 5 pieces (1 table, 4 chairs)
Table Shape: Rectangular
Table Material: Metal (Galvanized Iron Slatted Tabletop)
Chair Material: Metal frame with Textilene fabric
Chair Features: 360-Degree Swivel, High Backrest, Wide Seat
Umbrella Hole: 1.57 inches diameter (with lid)
Item Weight: 52.5 Pounds
Style: Modern
Assembly Required: Yes
Product Care: Wipe with Dry Cloth

9. Warranty and Support

For warranty information or customer support, please refer to the product packaging or contact NUU GARDEN customer service directly. Keep your purchase receipt for any warranty claims.
