1. Introduction
This manual provides essential information for the setup, operation, maintenance, and troubleshooting of your SOYO M2 Pro Mini PC N95. This mini PC is equipped with an Intel Gen 12 Alder-N Lake N95 Processor, 16GB DDR4 RAM, and a 512GB SATA M.2 2280 SSD. It supports dual 4K@60Hz displays via HDMI and DisplayPort and operates on Windows 11.
2. What's in the Box
- SOYO M2 Pro Mini PC
- Power Adapter
- HDMI Cable
- VESA Mount Bracket with Screws
- User Manual
3. Product Overview
Figure 3.1: SOYO M2 Pro Mini PC dimensions and port layout. This image illustrates the compact dimensions of the SOYO M2 Pro Mini PC, measuring 117mm in width, 106mm in depth, and 41mm in height, with a weight of 400g. It also highlights the available ports: two USB ports on the front, two USB ports on the rear, one HDMI port, one DisplayPort, and one Type-C port, along with the power button.
Figure 3.2: SOYO M2 Pro Mini PC key features. This image details the core features of the SOYO M2 Pro Mini PC, including the Intel N95 processor, 8GB or 16GB DDR4 RAM, 256GB or 512GB SSD storage, 2.5G Ethernet, Wi-Fi 6, VESA mount compatibility, silent cooling system, and support for up to three 4K displays.
Figure 3.3: Intel Gen 12 N95 Processor details. This image provides a detailed view of the Intel Gen 12 N95 processor, highlighting its specifications including a maximum turbo frequency of 3.4 GHz and an all-cores turbo frequency of 3.2 GHz. It also indicates performance improvements of 1.4 times for single-core and 2 times for multi-core tasks.
3.1 Physical Features
- Dimensions: Approximately 117mm x 106mm x 41mm
- Weight: Approximately 400g
- Ports: 2x Front USB, 2x Rear USB, 1x HDMI, 1x DisplayPort, 1x Type-C, 1x 2.5G Ethernet, Audio Jack
- Power Button: Located on the front panel.
3.2 Key Features
- Processor: Intel Gen 12 Alder-N Lake N95 (up to 3.4GHz)
- Memory: 16GB DDR4 RAM
- Storage: 512GB SATA M.2 2280 SSD
- Display Support: Dual 4K@60Hz via HDMI and DisplayPort
- Operating System: Windows 11
- Connectivity: Wi-Fi 6, 2.5G Ethernet
- Cooling: Silent cooling system
- Mounting: VESA mount compatible
4. Setup Instructions
- Connect to Power: Connect the power adapter to the DC-in port on the mini PC and then plug it into a power outlet.
- Connect to Display: Connect your monitor(s) to the mini PC using an HDMI or DisplayPort cable. The device supports dual displays.
- Connect Peripherals: Connect your keyboard, mouse, and any other USB devices to the available USB ports.
- Network Connection (Optional): For a wired connection, connect an Ethernet cable from your router or modem to the 2.5G Ethernet port on the mini PC. For Wi-Fi, you will configure it during the initial Windows setup.
- Power On: Press the power button on the front of the mini PC. The system will boot up.
- Initial Windows Setup: Follow the on-screen instructions to complete the Windows 11 setup, including language, region, network, and user account creation.
5. Operating Instructions
5.1 Power On/Off
- To Power On: Press the power button once.
- To Shut Down: Click the Start button in Windows, then select Power > Shut down. Alternatively, press and hold the power button for 4 seconds to force a shutdown (use only if the system is unresponsive).
- To Restart: Click the Start button in Windows, then select Power > Restart.
5.2 Connecting Displays
The SOYO M2 Pro Mini PC supports connecting up to two external displays simultaneously for an extended desktop experience. Use the HDMI and DisplayPort outputs.
Figure 5.1: Dual display support. This image illustrates the SOYO M2 Pro Mini PC's capability to support dual screen displays via its two HDMI 2.0 ports, allowing users to connect two monitors simultaneously for enhanced multitasking and productivity.
Figure 5.2: Example of a multi-display setup. This image depicts a user working with a multi-display setup, featuring a laptop and two external monitors connected to a mini PC. This configuration highlights the SOYO M2 Pro Mini PC's ability to support multiple displays, ideal for tasks requiring an expansive workspace.
5.3 Network Connection
- Wired: Plug an Ethernet cable into the 2.5G Ethernet port. The connection should be established automatically.
- Wireless (Wi-Fi): In Windows, click the network icon in the taskbar, select your Wi-Fi network, enter the password, and connect.
5.4 VESA Mounting
The mini PC can be mounted behind a monitor or on a wall using the included VESA mount bracket to save desk space.
Figure 5.3: Compact size and mounting options. This image demonstrates the SOYO M2 Pro Mini PC's compact size, comparable to a palm, and its flexible placement options. It can be mounted on a wall, placed on a desk, or discreetly hidden behind a monitor using a VESA mount, promoting a tidy workspace.
6. Maintenance
- Cleaning: Use a soft, dry cloth to clean the exterior of the mini PC. Do not use liquid cleaners or aerosols. Ensure ventilation openings are clear of dust.
- Software Updates: Regularly check for and install Windows updates and driver updates to ensure optimal performance and security.
- Ventilation: Ensure the mini PC is placed in a well-ventilated area. Avoid blocking the air vents to prevent overheating.
- Data Backup: Regularly back up important data to an external drive or cloud storage to prevent data loss.
7. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| No power | Power cable not connected; Power outlet issue | Check power cable connection; Try a different power outlet; Ensure power adapter is functional. |
| No display on monitor | Display cable loose or incorrect input selected | Ensure display cable (HDMI/DP) is securely connected; Select correct input source on monitor; Test with a different cable or monitor. |
| Slow performance or system freezes | Overheating; Too many applications running; Insufficient ventilation | Close unnecessary applications; Ensure proper ventilation around the mini PC; Check for background processes; Update drivers. |
| No internet connection | Network cable issue; Wi-Fi disabled or incorrect password | Check Ethernet cable connection; Verify Wi-Fi is enabled and password is correct; Restart router/modem. |
| Fan noise is loud | High CPU load; Dust accumulation in vents | Reduce CPU-intensive tasks; Ensure vents are clear of dust; Place in a well-ventilated area. |
8. Specifications
| Feature | Detail |
|---|---|
| Processor | Intel Gen 12 Alder-N Lake N95 (up to 3.4 GHz) |
| RAM | 16GB DDR4 SDRAM |
| Storage | 512GB SATA M.2 2280 SSD |
| Graphics | Integrated Intel Graphics |
| Operating System | Windows 11 |
| Max Screen Resolution | 3840 x 2160 (4K@60Hz) |
| Video Output Ports | 1x HDMI, 1x DisplayPort |
| USB Ports | 4x USB (2 front, 2 rear), 1x Type-C |
| Ethernet | 2.5G Ethernet |
| Wireless Connectivity | Wi-Fi 6 |
| Dimensions (L x W x H) | 117mm x 106mm x 41mm |
| Weight | Approximately 400g |
| Color | Black |
9. Warranty and Support
For warranty information, please refer to the documentation included with your purchase or contact the seller directly. For technical support, please reach out to the SOYO customer service channels provided at the point of purchase or on the official SOYO website.
