MIAOKE XHP-90 LED Rechargeable Flashlight User Manual

Introduction

Thank you for choosing the MIAOKE XHP-90 LED Rechargeable Flashlight. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new flashlight. Please read it thoroughly before use and retain it for future reference.

The MIAOKE XHP-90 LED flashlight is designed for high performance, featuring a powerful LED, multiple lighting modes, a zoom function, and a durable, waterproof construction. It is suitable for various applications including outdoor adventures, emergency situations, and daily use.

MIAOKE XHP-90 LED Flashlight, a powerful and durable lighting tool.

Image: The MIAOKE XHP-90 LED Flashlight, showcasing its robust design and powerful illumination capabilities.

Product Overview and Package Contents

Before using your flashlight, please ensure all components are present and undamaged.

MIAOKE XHP-90 LED Flashlight package contents including flashlight, manual, Type-C cable, lanyard, and two 2600mAh Li-ion batteries.

Image: Package contents of the MIAOKE XHP-90 LED Flashlight. This includes the flashlight unit, a user manual, a Type-C charging cable, a wrist lanyard, and two 2600mAh Li-ion rechargeable batteries.

Package Includes:

MIAOKE XHP-90 LED Flashlight
USB Type-C Charging Cable
Wrist Lanyard
2 x 2600mAh Li-ion Rechargeable Batteries
User Manual (this document)

Setup

1. Battery Installation

The MIAOKE XHP-90 flashlight uses two 2600mAh Li-ion rechargeable batteries. Ensure the batteries are inserted with the correct polarity (+/-) as indicated inside the battery compartment. Incorrect installation can damage the device.

MIAOKE 2600mAh Li-ion battery being charged, illustrating its high performance.

Image: A visual representation of the 2600mAh Li-ion battery, highlighting its performance capabilities and indicating it's ready for use.

2. Initial Charge

For optimal performance, fully charge the flashlight before its first use. Refer to the "Charging the Flashlight" section for detailed instructions.

Operating Instructions

Power On/Off and Mode Selection

The flashlight features a single button for power control and mode cycling.

To Turn On: Press the power button once. The flashlight will activate in the last used mode.
To Cycle Modes: While the flashlight is on, press the power button repeatedly to cycle through the available modes: High Light → Low Light → Strobe.
To Turn Off: Press and hold the power button for approximately 2 seconds.

MIAOKE XHP-90 LED Flashlight demonstrating three lighting modes: High, Normal (Low), and Strobe, with example applications.

Image: The MIAOKE XHP-90 LED Flashlight showcasing its three distinct lighting modes: High for outdoor adventure and cycling, Normal (Low) for household and daily lighting, and Strobe for SOS signals and emergency alerts.

Zoom Function

The flashlight features an adjustable zoom function to change the beam from a wide floodlight to a focused spotlight.

Zoom In (Spotlight): Extend the head of the flashlight forward to narrow the beam and increase the throw distance.
Zoom Out (Floodlight): Retract the head of the flashlight backward to widen the beam for broader area illumination.

MIAOKE XHP-90 LED Flashlight demonstrating zoom in and zoom out functions, showing a focused beam and a wide beam.

Image: The MIAOKE XHP-90 LED Flashlight illustrating its zoom capabilities. The "Zoom In" view shows a concentrated beam for long-distance illumination, while the "Zoom Out" view displays a wider beam for illuminating a larger area.

Charging the Flashlight

The MIAOKE XHP-90 flashlight is equipped with a USB Type-C fast charging port and a battery level indicator.

Connect: Insert the provided USB Type-C cable into the flashlight's charging port. Connect the other end to a standard USB power adapter (not included) or a computer USB port.
Battery Indicator: The integrated battery indicator lights (25%, 50%, 75%, 100%) will illuminate to show the current charging status. When all four lights are solid, the flashlight is fully charged.
Charging Time: The Type-C port allows for faster charging compared to conventional ports. Charging time may vary depending on the power source.
Protection: The flashlight features built-in protection against reverse connections, overvoltage, and short circuits to ensure battery longevity and safety.

MIAOKE XHP-90 LED Flashlight connected to a Type-C charger, showing the battery level indicator at 100% and a visual representation of a full battery.

Image: The MIAOKE XHP-90 LED Flashlight being charged via its Type-C port. The battery indicator shows a full charge (100%), and a graphic illustrates the internal battery capacity.

Maintenance

Cleaning: Wipe the flashlight body with a soft, damp cloth. Do not use abrasive cleaners or solvents.
Lubrication: Periodically apply silicone grease to the O-rings and threads to maintain water resistance and smooth operation.
Battery Care: If the flashlight will not be used for an extended period, remove the batteries to prevent leakage. Store batteries in a cool, dry place.
Water Resistance: The flashlight is IPX7 rated, meaning it can withstand immersion in water up to 1 meter for 30 minutes. Ensure the charging port cover is securely closed before exposing the flashlight to water.

MIAOKE XHP-90 LED Flashlight highlighting its carbon steel construction for durability and IPX7 waterproof rating with water being poured over it.

Image: The MIAOKE XHP-90 LED Flashlight demonstrating its robust carbon steel construction and IPX7 waterproof rating, with water flowing over the device.

Troubleshooting

Problem	Possible Cause	Solution
Flashlight does not turn on.	Low or depleted battery. Incorrect battery installation. Loose tail cap.	Charge the battery fully. Check battery polarity and reinsert correctly. Tighten the tail cap securely.
Light output is dim or flickers.	Low battery level. Loose connections. Dirty contacts.	Recharge the battery. Ensure tail cap and head are tightened. Clean battery contacts with a clean cloth.
Flashlight gets hot during use.	Normal operation at high brightness. Prolonged use on High mode.	This is normal for high-power LEDs. Switch to a lower brightness mode or turn off for a short period.
Zoom function is stiff.	Lack of lubrication. Dirt or debris in the mechanism.	Clean the zoom mechanism and apply a small amount of silicone grease.

Specifications

Feature	Detail
Brand	MIAOKE
Model Number	Black dawn flashlight-02
Light Source	XHP-90 LED
Luminosity	Up to 250,000 Lumens
Beam Distance	Up to 1500 meters
Lighting Modes	3 (High, Low, Strobe)
Zoom Function	Adjustable (Zoom In/Out)
Power Source	Rechargeable Li-ion Batteries
Battery Type	2 x 2600mAh 3.7V Li-ion (included)
Charging Port	USB Type-C (Fast Charging)
Battery Indicator	25%/50%/75%/100% display
Material	Durable Metal (Carbon Steel)
Water Resistance	IPX7 (Waterproof)
Dimensions (Approx.)	27.7 cm (Length) x 6 cm (Head Diameter) x 3.4 cm (Body Diameter)
Weight (Approx.)	730 grams
Special Features	Emergency Escape Tool (Tail Stone)

MIAOKE XHP-90 LED Flashlight with detailed dimensions: 27.7cm length, 6cm head diameter, 3.4cm body diameter.

Image: Detailed dimensions of the MIAOKE XHP-90 LED Flashlight, showing its length, head diameter, and body diameter.

Warranty and Support

MIAOKE offers a Lifetime Guarantee on this product, ensuring quality and customer satisfaction. For any questions, technical support, or warranty claims, please contact your retailer or the MIAOKE customer service directly. Please refer to the contact information provided at the point of purchase or on the official MIAOKE website.

Note: Keep your purchase receipt as proof of purchase for warranty purposes.
