Glocusent Wingy Book Light (Model A29) User Manual

Introduction

Thank you for choosing the Glocusent Wingy Book Light. This manual provides detailed instructions for the setup, operation, and maintenance of your new reading light. Designed for comfort and convenience, the Wingy Book Light offers adjustable illumination to enhance your reading experience.

Glocusent Wingy Book Light clipped onto a book, illuminating the pages.

The Glocusent Wingy Book Light, designed for comfortable reading.

Product Overview

The Glocusent Wingy Book Light features a unique 'wingy' design with 48 dual-row LED beads, providing a wide and even light spread. It includes independent control for each wing, multiple brightness levels, three color temperatures, and a built-in timer with a sleep aid function. Its flexible gooseneck and sturdy clip ensure versatile use.

Diagram showing the Glocusent Wingy Book Light's features: 164-degree wingy design, 48 dual row beads, waveform reflector, and polished optical lens for eye-caring light.

Detailed view of the Wingy Book Light's optical design for optimal illumination.

Setup

Charging the Device

Before first use, fully charge your Wingy Book Light. The device is equipped with a 1000mAh battery and charges via a USB-C port. A full charge takes approximately 2.5 hours and provides up to 120 hours of use on the lowest setting.

Connect the provided USB-C charging cable to the charging port on the clip base.
Plug the other end into a compatible USB power source (adapter not included).
The indicator lights on the clip base will show charging status. All four lights indicate a full charge.

Close-up of the Glocusent Wingy Book Light's internal battery, showing 1000mAh capacity and 120 hours of use.

The 1000mAh battery provides extended usage time.

Attaching the Light

The sturdy clip base is designed to securely attach to books, tables, or other surfaces. The clip features silicone pads to protect surfaces and ensure a firm grip.

Open the clip by pressing the rear end.
Attach the clip to your desired surface, ensuring the silicone pads make contact.
Adjust the flexible gooseneck to position the light over your reading material.

Close-up of the Glocusent Wingy Book Light's sturdy clip, highlighting its 2.0-inch opening.

The sturdy clip with silicone pads ensures secure attachment without damage.

Image showing the flexible gooseneck of the Glocusent Wingy Book Light.

The flexible gooseneck allows for precise light positioning.

Operating Instructions

The Glocusent Wingy Book Light features intuitive controls located on the top of each wing.

Diagram illustrating the controls on the Glocusent Wingy Book Light, showing buttons for brightness, color temperature, and independent wing control with timer and sleep aid functions.

Overview of the easy-to-use controls.

Power On/Off & Independent Wing Control

Each wing has an independent power button. Short press the button on the left wing to turn it on/off.
Short press the button on the right wing to turn it on/off.
This allows for focused lighting, preventing disturbance to others, especially during bedtime reading.

A person reading in bed with the Glocusent Wingy Book Light, showing one wing illuminated to avoid disturbing a sleeping partner.

Independent wing control for undisturbed reading.

Brightness Adjustment

Use the brightness control button (usually marked with +/- or light icon) to cycle through 5 preset brightness levels.
For stepless adjustment, long press the brightness button to gradually increase or decrease the light intensity. Release when the desired brightness is reached.

A person reading at a desk with the Glocusent Wingy Book Light, illustrating the 3 color temperatures and 5 brightness levels.

Adjustable brightness levels for various reading conditions.

Color Temperature Adjustment

Press the color temperature button (usually marked with a color icon) to switch between three modes:

2700K (Warm Light): Ideal for bedtime reading, gentle on the eyes.
4000K (Neutral White): Suitable for relaxed reading.
6000K (Cool White): Best for focused work or reading.

A woman reading in bed with the Glocusent Wingy Book Light set to 2700K warm amber light, labeled 'Gentle Amber for Better Night Reading & Eyecaring'.

2700K Warm Light for comfortable night reading.

A woman reading on an airplane with the Glocusent Wingy Book Light set to 4000K soft white light, labeled 'Soft White for More Relaxed'.

4000K Neutral White for relaxed reading.

A person working at a desk with the Glocusent Wingy Book Light set to 6000K cool white light, labeled 'White Bright for Better Focus'.

6000K Cool White for enhanced focus.

Timer and Sleep Aid Function

Timer: Long press the left wing's power button to activate the 30-minute or 45-minute timer. The light will automatically turn off after the set time.
Sleep Aid: When the timer is active, long press the right wing's power button to engage the sleep aid mode. The light will gradually dim, simulating a sunset, to gently guide you to sleep.

Image illustrating the Sleep Aid function with gradual dimming and a 30/45-minute timer, showing a person reading and then sleeping as the light dims.

The timer and sleep aid function promote better sleep habits.

Maintenance

Keep the device clean by wiping it with a soft, dry cloth.
Avoid using abrasive cleaners or solvents.
Store in a cool, dry place when not in use.

Troubleshooting

Light not turning on: Ensure the device is charged. Connect to a power source and check the indicator lights.
Light flickering: This may indicate a low battery. Recharge the device.
Buttons unresponsive: Try resetting the device by fully discharging and then recharging it.

Specifications

Model Name	Wingy Book Light
Item Model Number	A29
Light Source Type	LED
Number of Light Sources	48
Brightness	65 Lumen (Max)
Color Temperature	2700K, 4000K, 6000K
Power Source	Battery Powered (1000mAh Lithium Polymer)
Item Weight	2.4 ounces
Product Dimensions	10.6"D x 1.7"W x 1.3"H
Material	Acrylonitrile Butadiene Styrene
Special Feature	Cordless, Timer, Sleep Aid

What's in the Box

1x Glocusent Wingy Book Light
1x Book Mark
1x User Manual
1x Charging Cable (USB-C)

Warranty and Support

Glocusent products undergo rigorous quality control. We offer:

30-day return service.
24-month warranty.
24/7 customer service from our Customer Experience Team.

For any inquiries or support, please refer to the contact information provided in your product packaging or visit the official Glocusent website.

Official Product Video

Official overview of the Glocusent Wingy Book Light, demonstrating its features and design.
