1. Introduction
Thank you for purchasing the Oraymin LED Panel Dimmable Ceiling Light. This manual provides essential information for the safe installation, operation, and maintenance of your new lighting fixture. Please read these instructions thoroughly before use and retain them for future reference.
2. Safety Instructions
- Always disconnect power at the main circuit breaker before installation, maintenance, or cleaning.
- Installation should be performed by a qualified electrician in accordance with all local electrical codes.
- Do not modify the fixture or its components. Unauthorized modifications may void the warranty and create safety hazards.
- Ensure the mounting surface can support the weight of the fixture.
- Avoid looking directly into the LED light source when illuminated, as it may cause eye strain.
- Keep the remote control away from water and extreme temperatures.
- This product is designed for indoor use only. Do not expose to moisture or outdoor elements.
3. Package Contents
Verify that all components are present and undamaged before proceeding with installation.
Image: Overview of the Oraymin LED Panel Light, showing its dimensions (120cm x 30cm x 3.9cm), the included remote control, mounting screws, wall plugs, and a small instruction manual. Icons at the bottom indicate features like infinite dimming, RGB backlight, CCT adjustment, memory function, night light, and flicker-free operation.
- Oraymin LED Panel Ceiling Light (1 unit)
- Remote Control (1 unit)
- Mounting Screws (4 units)
- Wall Plugs (4 units)
- User Manual (this document)
4. Installation Instructions
Follow these steps carefully to install your Oraymin LED Panel Light. If you are unsure about any step, consult a qualified electrician.
- Prepare for Installation:
- Turn off the main power supply at the circuit breaker before starting any electrical work.
- Unpack the LED panel light and all accessories. Inspect for any damage.
- Mounting the Fixture:
- Position the mounting bracket (integrated into the light fixture) on the ceiling at the desired location.
- Mark the drilling points for the screws.
- Drill holes at the marked points and insert the wall plugs.
- Secure the light fixture to the ceiling using the provided mounting screws. Ensure it is firmly attached.
- Electrical Connection:
- Connect the household electrical wires to the corresponding terminals on the LED panel light. Use the quick connectors if provided and ensure correct polarity (Live, Neutral, Earth).
- Ensure all connections are secure and properly insulated.
- Final Steps:
- Carefully push the light fixture flush against the ceiling.
- Restore power at the main circuit breaker.
- Test the light using the wall switch and the remote control.
5. Operating Instructions
Your Oraymin LED Panel Light offers various lighting modes and controls via the included remote control.
5.1 Remote Control Functions
Image: Close-up of the remote control, showing buttons for power, brightness adjustment, color temperature adjustment, RGB color selection, night mode, and timer functions.
- Power On/Off: Press the Power button to turn the light on or off.
- Brightness Adjustment: Use the "+" and "-" buttons to increase or decrease the brightness (stepless dimming).
- Color Temperature Adjustment (CCT): Use the "K+" and "K-" buttons to adjust the color temperature from 3000K (Warm White) to 6500K (Cool White).
Image: The LED panel light displaying various color temperatures, including Warm White (>3500K), Neutral White (3500K-5000K), and Cold White (>5000K), demonstrating the CCT adjustment capability.
- RGB Backlight Control:
- Press the RGB button to activate the RGB backlight.
- Use the dedicated RGB color buttons (if available on remote) or cycle through 6 distinct RGB colors and a gradient mode.
- The RGB backlight can be used independently or in conjunction with the main light.
Image: The LED panel light illuminating a room with various RGB backlight colors, demonstrating the 7 available colors and 3 cycle modes for creating different atmospheres.
- Night Mode: Press the Moon icon button to activate a soft, low-brightness night light mode.
- Timer Function: Press the Timer button (often indicated by a clock icon) to set a 30-minute timer, after which the light will automatically turn off.
- Memory Function: The light remembers the last brightness and color temperature setting when turned off via the remote or wall switch. To save a setting with the wall switch, ensure the light is on for at least 60 seconds with your desired settings, then turn it off for at least 10 seconds before turning it back on.
- Group Control: Multiple Oraymin LED Panel Lights can be controlled simultaneously with a single remote control.
5.2 Lighting Scenarios
Image: Three scenarios demonstrating the versatility of the light: main light only for general illumination, backlight only for ambient glow, and RGB cycle mode for dynamic color effects.
Image: Four distinct lighting modes illustrated: Main Light for bright illumination, RGB-Backlight for mood lighting, Main light + RGB-Backlight for combined effects, and Night light for a soft glow.
The Oraymin LED Panel Light offers versatile lighting options to suit various needs:
- Main Light Only: Provides bright, adjustable white light for general illumination.
- RGB Backlight Only: Creates an ambient glow with various colors, ideal for mood setting or decorative purposes.
- Main Light + RGB Backlight: Combines functional white light with a colorful accent.
- Night Light: A very dim, soft light setting for minimal illumination during the night.
6. Maintenance
To ensure the longevity and optimal performance of your LED panel light, follow these simple maintenance guidelines:
- Cleaning:
- Before cleaning, ensure the power supply to the fixture is turned off at the circuit breaker.
- Wipe the fixture with a soft, dry, or slightly damp cloth.
- Do not use abrasive cleaners, solvents, or harsh chemicals, as these can damage the finish or electrical components.
- Bulb Replacement: The LED light source is integrated and not user-replaceable. The fixture has an estimated lifespan of approximately 30,000 hours.
- Inspection: Periodically check the fixture for any signs of damage or loose connections. If any issues are found, disconnect power and consult a qualified electrician.
7. Troubleshooting
If you encounter any issues with your Oraymin LED Panel Light, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Light does not turn on. | No power supply; loose wiring; remote control battery depleted. | Check circuit breaker. Ensure wiring connections are secure. Replace remote control battery. |
| Remote control not working. | Remote control battery depleted; remote not aimed at fixture; interference. | Replace remote control battery. Ensure direct line of sight to the fixture. Remove any obstructions. |
| Light flickers or dims unexpectedly. | Unstable power supply; loose connection; incompatible dimmer (if not using remote). | Check power supply stability. Verify wiring connections. This fixture is designed for remote dimming; avoid external dimmers unless specified. |
| RGB backlight not changing colors. | Incorrect remote button pressed; temporary software glitch. | Ensure you are pressing the correct RGB control buttons. Try turning the light off and on again. |
If the problem persists after trying these solutions, please contact customer support.
8. Specifications
| Feature | Detail |
|---|---|
| Brand | Oraymin |
| Model | LED Panel Dimmable Ceiling Light |
| Dimensions (L x W x H) | 120 x 30 x 3.9 cm |
| Light Source Type | Integrated LED (125 main LEDs, 60 RGB beads) |
| Wattage | 40 Watts |
| Lumen Output | 4800 Lumens |
| Voltage | 230 Volts |
| Color Temperature | 3000K - 6500K (Adjustable) |
| RGB Backlight | 6 Colors + Gradient Mode |
| Color Rendering Index (CRI) | >85 |
| Lifespan | Approx. 30,000 hours |
| Features | Dimmable, Memory Function, Night Mode, 30-min Timer, Flicker-free |
| Energy Efficiency Class | C |
| EPREL Product Registration | 1955685 |
Image: European Union energy label indicating the product's energy efficiency class as C and energy consumption of 40 kWh per 1000 hours.
9. Warranty and Support
The Oraymin LED Panel Light is designed for durability with an estimated lifespan of approximately 30,000 hours.
For any issues, questions, or personalized service, please contact Oraymin customer support through the platform where you purchased the product. Please have your purchase details ready when contacting support.
